Vol. I, Ch. 14

DCT Laboratory — Volume I, Chapter 14

Mathematical Analysis of the Unified Enterprise Transformation Architecture

This laboratory demonstrates

Seed 26114 · Companion to Chapter 14 and AXIOM Lab 1.14 (module AXIOM-14) · Mirrored in DCT_V1_Ch14_Lab.xlsx

This laboratory reproduces Worked Example 14.1, Can Meridian Afford the New Link?, with the book's declarations, and works the five steps of AXIOM Lab 1.14, How Close to the Edge Is Meridian?: the stability bench, the sensitivity explorer, the perturbation simulator, the feasible-region visualizer and the diagnostics dashboard, ending with the lab's deliverable, an analysis certificate for the board. The chapter's numbers are computed exactly, without simulation; the lab's seed 26114 is used only for fresh draws, labelled as such. Every Meridian number below is the book's or follows from its declarations (Worked Example 14.1, Table 14.4, Figures 14.1–14.3, Sections 14.4–14.6, Online Appendix 14.B.1–14.B.3); the final cell checks the printed ones. Money is in $ million.

The declarations (Worked Example 14.1, the situation; Section 14.6)

Meridian's feedback core (Worked Example 9.1): Industrial Systems and Digital, each wired both ways to shared engineering and to treasury. The risk committee's register (Section 12.7) caps every link at 0.40: no unit passes on more than 40 percent of a quarter's deviation to a linked unit in the next quarter. Read as the interaction matrix M\mathbf{M}, the register's ceilings bound the true linearized dynamics, ∣A∣≤M|\mathbf{A}| \le \mathbf{M} entrywise (the declared-gain certificate, Equation 14.3). Where the book asks what happens if every link ran at its ceiling, the deviations follow the register itself, xk+1=Mxk\mathbf{x}_{k+1} = \mathbf{M}\mathbf{x}_k: Chapter 12's quarterly echo.

The new link. The second phase of the digital program links Digital and Industrial Systems directly, both ways: Digital's platform is sold into Industrial Systems' installed base, and Industrial Systems' service teams carry Digital's software to the customers who are migrating. In the symmetric register the engineering links carry a gain ee, the treasury links tt and the new link hh; today e=t=0.40e = t = 0.40 and h=0h = 0.

The board's rule. Any deviation must halve within a year: a half-life of at most four quarters, that is, a spectral radius of at most 2−1/4=0.84092^{-1/4} = 0.8409.

The runway (Section 14.6; a unit, not Meridian). A unit holds $120 million of cash above its floor, burns $50 million a quarter, and can cut the burn by at most $10 million a quarter: s′=s−rs' = s - r and r′=max⁡(r−u,0)r' = \max(r - u, 0) with 0≤u≤100 \le u \le 10, on the feasible region 0≤s≤5000 \le s \le 500, 0≤r≤600 \le r \le 60 (Appendix 14.A, proof of Theorem 14.5(iv)).

Python Code
import numpy as np
import scipy.linalg as sla
import matplotlib.pyplot as plt
from math import log, sqrt
plt.rcParams.update({"figure.dpi": 110, "axes.spines.top": False, "axes.spines.right": False})
SEED = 26114          # the lab's seed: fresh draws only, labelled as such

CORE = ["IND", "DIG", "ENG", "TRS"]       # Industrial Systems, Digital, engineering, treasury
G0 = 0.40                                  # the register's ceiling per link (Section 12.7)
RULE = 0.5 ** 0.25                         # the board's rule: a half-life of at most four quarters
SHOCK = 10.0                               # $10 million at Digital: a one-off shock, or a shortfall a quarter

def register(e=G0, t=G0, h=0.0):
    # the symmetric register on CORE: engineering links e, treasury links t, the new link h;
    # entry (i, j) is the share of unit j's deviation that unit i receives in the next quarter
    M = np.zeros((4, 4))
    i, d, g, r = range(4)
    for a, b, w in ((i, g, e), (d, g, e), (i, r, t), (d, r, t), (i, d, h)):
        M[a, b] = M[b, a] = w
    return M

def rho(M):
    return float(max(abs(np.linalg.eigvals(M))))

def rho_closed(e=G0, t=G0, h=0.0):
    # Online Appendix 14.B.1: rho = (h + sqrt(h^2 + 8(e^2 + t^2))) / 2
    return (h + sqrt(h * h + 8 * (e * e + t * t))) / 2

def half_life(r):
    return log(2) / log(1 / r) if r < 1 else float("inf")

def to_tenth(r):
    return log(10) / log(1 / r) if r < 1 else float("inf")

def amplification(r):
    return 1 / (1 - r) if r < 1 else float("inf")

def at(src="DIG", size=SHOCK):
    b = np.zeros(4); b[CORE.index(src)] = size
    return b

def settled(M, b=None):
    # Theorem 14.4(ii): a permanent input b a quarter settles at (I - M)^{-1} b; none when rho >= 1
    b = at() if b is None else b
    return np.linalg.solve(np.eye(4) - M, b) if rho(M) < 1 else None

def echo(M, b=None, quarters=12):
    # the deviation at each unit, quarter by quarter, after a one-off shock b (rows: quarters 0, 1, ...)
    x = at() if b is None else b
    out = [x]
    for _ in range(quarters):
        x = M @ x
        out.append(x)
    return np.array(out)

M0 = register()
print("today's register (rows receive, columns pass on):")
print("          " + "".join(f"{u:>6s}" for u in CORE))
for u, row in zip(CORE, M0):
    print(f"    {u:4s}  " + "".join(f"{v:6.2f}" for v in row))
print(f"the board's rule: half-life <= 4 quarters <=> rho <= 2^(-1/4) = {RULE:.4f}")
today's register (rows receive, columns pass on):
             IND   DIG   ENG   TRS
    IND     0.00  0.00  0.40  0.40
    DIG     0.00  0.00  0.40  0.40
    ENG     0.40  0.40  0.00  0.00
    TRS     0.40  0.40  0.00  0.00
the board's rule: half-life <= 4 quarters <=> rho <= 2^(-1/4) = 0.8409

Panel 1 — Read today's budget (Worked Example 14.1, Step 1; Theorems 14.3(ii), 14.3(iv) and 14.4(iii): 0.80, 3.1 quarters, $50 million)

AXIOM Lab 1.14, step 1, the stability bench. Each core unit has two links, so it passes on at most 0.80 of a deviation in total, and the register's spectral radius is 0.80. By Theorem 14.3(ii) that certifies the core whatever the true gains are, as long as each stays within its ceiling: a deviation halves every 3.1 quarters. Fresh draws of true gains within the ceilings, with the lab's seed, show the certificate at work. Its margin is the gap to the edge, 1−ρ=0.201 - \rho = 0.20, and 0.04 to the board's rule. The Lyapunov bowl of Theorem 14.3(iv), the solution of M⊤PM−P=−I\mathbf{M}^{\top}\mathbf{P}\mathbf{M} - \mathbf{P} = -\mathbf{I}, is positive definite, so the health index V(x)=x⊤PxV(\mathbf{x}) = \mathbf{x}^{\top}\mathbf{P}\mathbf{x} falls every quarter. By Theorem 14.4(iii) the amplification is 1/(1−0.80)=51/(1 - 0.80) = 5: a permanent shortfall of $10 million a quarter at Digital settles at $50 million a quarter across the core, $19 million at Digital, $11 million each at engineering and treasury, and $9 million at Industrial Systems, of which $40 million is knock-on that Digital's own plan never shows.

Python Code
r0 = rho(M0)
print("each unit passes on (column sums):", ", ".join(f"{u} {v:.2f}" for u, v in zip(CORE, M0.sum(axis=0))))
print(f"eigenvalues {np.sort(np.linalg.eigvals(M0).real).round(4)}: spectral radius {r0:.4f}"
      f" (closed form sqrt(8 x 0.32)/2 = {rho_closed():.4f})")
print(f"half-life ln 2 / ln(1/0.80) = {half_life(r0):.2f} quarters; to a tenth {to_tenth(r0):.1f} quarters")
print(f"margin to the edge, 1 - rho = {1 - r0:.2f}; margin to the board's rule, {RULE:.4f} - {r0:.2f} = {RULE - r0:.4f}")

rng = np.random.default_rng(SEED)              # fresh draws, lab seed: true gains within the ceilings, |A| <= M
draws = np.array([rho(M0 * rng.uniform(-1.0, 1.0, size=M0.shape)) for _ in range(10_000)])
print(f"10,000 true Jacobians with |A| <= M (fresh draws, seed {SEED}): largest spectral radius {draws.max():.3f};"
      f" share at or below {r0:.2f}: {(draws <= r0 + 1e-12).mean():.0%}")

P0 = sla.solve_discrete_lyapunov(M0.T, np.eye(4))          # M'PM - P = -I
print(f"Lyapunov bowl: eigenvalues of P {np.linalg.eigvalsh(P0).round(3)}: positive definite;"
      f" steepest along the Perron direction, 1/(1 - rho^2) = {1 / (1 - r0 ** 2):.3f}")
xs = echo(M0)
V0 = np.einsum("ki,ij,kj->k", xs, P0, xs)
print("health index V(x_k) after a $10 million shock at Digital, quarters 0-6:", V0[:7].round(1),
      "falls every quarter:", bool((np.diff(V0) < 0).all()))

s0 = settled(M0)
print(f"amplification 1/(1 - {r0:.2f}) = {amplification(r0):.0f}")
print("a permanent $10 million a quarter shortfall at Digital settles at",
      ", ".join(f"{u} {v:.1f}" for u, v in zip(CORE, s0)),
      f"-> total {s0.sum():.1f}, of which {s0.sum() - SHOCK:.1f} knock-on")
each unit passes on (column sums): IND 0.80, DIG 0.80, ENG 0.80, TRS 0.80
eigenvalues [-0.8  0.   0.   0.8]: spectral radius 0.8000 (closed form sqrt(8 x 0.32)/2 = 0.8000)
half-life ln 2 / ln(1/0.80) = 3.11 quarters; to a tenth 10.3 quarters
margin to the edge, 1 - rho = 0.20; margin to the board's rule, 0.8409 - 0.80 = 0.0409
10,000 true Jacobians with |A| <= M (fresh draws, seed 26114): largest spectral radius 0.635; share at or below 0.80: 100%
Lyapunov bowl: eigenvalues of P [1.    1.    2.778 2.778]: positive definite; steepest along the Perron direction, 1/(1 - rho^2) = 2.778
health index V(x_k) after a $10 million shock at Digital, quarters 0-6: [188.9  88.9  56.9  36.4  23.3  14.9   9.5] falls every quarter: True
amplification 1/(1 - 0.80) = 5
a permanent $10 million a quarter shortfall at Digital settles at IND 8.9, DIG 18.9, ENG 11.1, TRS 11.1 -> total 50.0, of which 40.0 knock-on

Panel 2 — Add the link at the ceiling (Worked Example 14.1, Step 2; Theorem 14.3(iii); Online Appendix 14.B.3: 1.0246, $12 million, then $15 million)

AXIOM Lab 1.14, step 1, continued: add the new link. Industrial Systems and Digital now have three links each and pass on 1.20 of every deviation. The register's spectral radius rises to 1.02 (1.0246, Online Appendix 14.B.1), and it certifies nothing. If every link ran at its ceiling, a $10 million shock at Digital would echo as $12 million in the next quarter and $15 million after three years, instead of dying out (Figure 14.3). Every link would still pass its own review at 0.40, and each unit alone is inert. Read in Chapter 9's two layers, the divisions (Industrial Systems and Digital) and the corporate center (engineering and treasury), each layer is stable on its own: the failure belongs to the two new loops, through engineering and through treasury. This is Theorem 14.3(iii) at Meridian. The block sizes of part (iii), read layer by layer, certify today's core and not the new one, and no positive definite Lyapunov bowl exists any more (part (iv)).

Python Code
M1 = register(h=G0)
r1 = rho(M1)
print("each unit passes on:", ", ".join(f"{u} {v:.2f}" for u, v in zip(CORE, M1.sum(axis=0))))
print(f"spectral radius {r1:.4f} (closed form (0.40 + sqrt(2.72))/2 = {rho_closed(h=G0):.4f}): above 1, no half-life")
adj0, adj1 = (M0 > 0).astype(int), (M1 > 0).astype(int)
print(f"loops of three links: today {np.trace(adj0 @ adj0 @ adj0) // 6}, with the new link {np.trace(adj1 @ adj1 @ adj1) // 6}"
      " (Industrial Systems-Digital-engineering and Industrial Systems-Digital-treasury)")

DIV, CTR = [0, 1], [2, 3]                  # Chapter 9's layers: the divisions and the corporate center
def block_sizes(M):
    # Theorem 14.3(iii): the size of each block, here the most one unit receives from the other layer (max-norm)
    size = lambda B: float(np.abs(B).sum(axis=1).max())
    return np.array([[size(M[np.ix_(a, b)]) for b in (DIV, CTR)] for a in (DIV, CTR)])
for name, M in (("today", M0), ("new link", M1)):
    Mh = block_sizes(M)
    print(f"{name:9s} divisions alone rho {rho(M[np.ix_(DIV, DIV)]):.2f}, center alone rho {rho(M[np.ix_(CTR, CTR)]):.2f};"
          f" block sizes {Mh.round(2).tolist()} -> rho {rho(Mh):.4f}")

e0, e1 = echo(M0).sum(axis=1), echo(M1).sum(axis=1)
print("echo of a $10 million shock at Digital, summed over the core, quarters 0-12")
print("  today   ", " ".join(f"{v:4.1f}" for v in e0))
print("  new link", " ".join(f"{v:4.1f}" for v in e1))
P1 = sla.solve_discrete_lyapunov(M1.T, np.eye(4))
print(f"Lyapunov equation with the new link: eigenvalues of P {np.linalg.eigvalsh(P1).round(2)}: indefinite, no bowl")
each unit passes on: IND 1.20, DIG 1.20, ENG 0.80, TRS 0.80
spectral radius 1.0246 (closed form (0.40 + sqrt(2.72))/2 = 1.0246): above 1, no half-life
loops of three links: today 0, with the new link 2 (Industrial Systems-Digital-engineering and Industrial Systems-Digital-treasury)
today     divisions alone rho 0.00, center alone rho 0.00; block sizes [[0.0, 0.8], [0.8, 0.0]] -> rho 0.8000
new link  divisions alone rho 0.40, center alone rho 0.00; block sizes [[0.4, 0.8], [0.8, 0.0]] -> rho 1.0246
echo of a $10 million shock at Digital, summed over the core, quarters 0-12
  today    10.0  8.0  6.4  5.1  4.1  3.3  2.6  2.1  1.7  1.3  1.1  0.9  0.7
  new link 10.0 12.0 11.2 12.2 12.0 12.6 12.7 13.2 13.4 13.8 14.1 14.5 14.8
Lyapunov equation with the new link: eigenvalues of P [-20.06   1.     1.19   1.64]: indefinite, no bowl

Panel 3 — Re-budget under the board's rule (Worked Example 14.1, Step 3; Table 14.4; Online Appendix 14.B.1: 0.08, 0.16, 0.30)

AXIOM Lab 1.14, step 1, last part: find a set of trims that meets the board's rule. A half-life of at most four quarters means a spectral radius of at most r∗=2−1/4=0.8409r^{*} = 2^{-1/4} = 0.8409. Because the core is symmetric, the register's radius has a closed form in the engineering links ee, the treasury links tt and the new link hh, ρ=12(h+h2+8(e2+t2))\rho = \tfrac{1}{2}\bigl(h + \sqrt{h^{2} + 8(e^{2} + t^{2})}\bigr), and ρ≤r∗\rho \le r^{*} exactly when h r∗+2(e2+t2)≤r∗2h\,r^{*} + 2(e^{2} + t^{2}) \le r^{*2} (Online Appendix 14.B.1): one frontier prices every repair. Running the new link at no more than 0.08 keeps everything else but gives up most of the synergy. Ring-fencing treasury allows the link at full strength if treasury's links fall to 0.16. Trimming every existing link by a quarter, from 0.40 to 0.30, does the same while spreading the cost across four offices. The radius sees the existing links only through e2+t2e^{2} + t^{2}, so the last two repairs have the same radius; they differ in where the settled deviation lands.

Python Code
def h_max(e=G0, t=G0, r=RULE):
    return (r * r - 2 * (e * e + t * t)) / r                  # largest new link within the rule
def t_max(h=G0, e=G0, r=RULE):
    return sqrt((r * r - h * r) / 2 - e * e)                  # treasury's links that make room for h
def even_trim(h=G0, r=RULE):
    return sqrt((r * r - h * r) / 4)                          # one gain on all four existing links

OPTIONS = [("Today", G0, G0, 0.0), ("New link at the ceiling", G0, G0, G0),
           ("Run the new link light", G0, G0, h_max()), ("Ring-fence treasury", G0, t_max(), G0),
           ("Trim every existing link", even_trim(), even_trim(), G0)]
TABLE = []
print(f"Table 14.4                 {'eng.':>6s} {'treas.':>6s} {'new':>6s} {'rho':>7s} {'closed':>7s} {'half-life':>9s}"
      f" {'settled':>8s}")
for name, e, t, h in OPTIONS:
    M = register(e, t, h); r = rho(M); s = settled(M)
    TABLE.append(dict(name=name, e=e, t=t, h=h, M=M, rho=r, settled=s))
    hl = "none" if r >= 1 else f"{half_life(r):.1f}"
    st = "no limit" if s is None else f"{s.sum():.1f}"
    print(f"{name:26s} {e:6.3f} {t:6.3f} {h:6.3f} {r:7.4f} {rho_closed(e, t, h):7.4f} {hl:>9s} {st:>8s}")
print(f"the frontier h r* + 2(e^2 + t^2) <= r*^2, with r* = {RULE:.4f}:")
print(f"  e = t = 0.40:      h <= ({RULE ** 2:.4f} - 0.64)/{RULE:.4f} = {h_max():.3f}")
print(f"  h = e = 0.40:      t <= {t_max():.3f}")
print(f"  h = 0.40, e = t:   e <= {even_trim():.3f}, a trim of {1 - even_trim() / G0:.0%}")
print("  the new link allowed as treasury's links fall (engineering at 0.40):",
      ", ".join(f"t {t:.2f}: h {h_max(G0, t):.3f}" for t in (0.40, 0.30, 0.20, t_max(), 0.10, 0.0)))
ring, trim = TABLE[3]["settled"], TABLE[4]["settled"]
print("same radius, different landing: ring-fence", ", ".join(f"{u} {v:.1f}" for u, v in zip(CORE, ring)),
      "| trim", ", ".join(f"{u} {v:.1f}" for u, v in zip(CORE, trim)))
print("echo with every existing link trimmed, quarters 0-12:", " ".join(f"{v:.1f}" for v in echo(TABLE[4]["M"]).sum(axis=1)))

q = np.arange(13)
STYLE = {"Today": ("#1F4E79", "-", 2.0), "New link at the ceiling": ("#B71C1C", "-", 2.0),
         "Run the new link light": ("#616161", ":", 1.3), "Ring-fence treasury": ("#616161", "-.", 1.3),
         "Trim every existing link": ("#E65100", "--", 2.0)}
fig, ax = plt.subplots(figsize=(7.6, 3.6))
for row in TABLE:
    col, ls, lw = STYLE[row["name"]]
    ax.plot(q, echo(row["M"]).sum(axis=1), color=col, ls=ls, lw=lw, marker="o", ms=2.5,
            label=f"{row['name'].lower()}: ρ = {row['rho']:.2f}")
ax.set(xlabel="quarter after the shock", ylabel="deviation in the core (\\$ million)", xlim=(0, 12), ylim=(0, 16),
       title="A \\$10 million shock at Digital: the new link makes it grow (seed 26114)")
ax.legend(frameon=False, fontsize=8, loc="center right", bbox_to_anchor=(1.0, 0.5)); plt.tight_layout(); plt.show()

tt = np.linspace(0.0, G0, 201)
fig, ax = plt.subplots(figsize=(7.6, 3.6))
ax.plot(tt, [h_max(G0, t) for t in tt], color="#1F4E79", lw=2, label="trim treasury's two links (engineering at 0.40)")
ax.plot(tt, [h_max(t, t) for t in tt], color="#E65100", lw=2, ls="--", label="trim all four existing links alike")
ax.axhline(G0, color="#999999", lw=0.8)
ax.text(0.175, G0 + 0.012, "the new link at full strength, 0.40", fontsize=8, color="#616161")
for x, y, txt, col, dx, dy in ((G0, h_max(), f"run the link light: {h_max():.2f}", "#616161", -0.012, -0.065),
                               (t_max(), G0, f"ring-fence: {t_max():.2f}", "#1F4E79", -0.012, -0.075),
                               (even_trim(), G0, f"trim: {even_trim():.2f}", "#E65100", 0.008, 0.045)):
    ax.plot([x], [y], "o", color=col, ms=5, zorder=5)
    ax.text(x + dx, y + dy, txt, fontsize=8, color=col, ha="right" if dx < 0 else "left")
ax.set(xlabel="gain kept on the trimmed links (share passed on per link)", ylabel="largest new link within the rule",
       xlim=(0, 0.42), ylim=(0, 0.9), title="Every repair is a point on one frontier (seed 26114)")
ax.legend(frameon=False, fontsize=8, loc="upper right"); plt.tight_layout(); plt.show()
Table 14.4                   eng. treas.    new     rho  closed half-life  settled
Today                       0.400  0.400  0.000  0.8000  0.8000       3.1     50.0
New link at the ceiling     0.400  0.400  0.400  1.0246  1.0246      none no limit
Run the new link light      0.400  0.400  0.080  0.8409  0.8409       4.0     64.2
Ring-fence treasury         0.400  0.159  0.400  0.8409  0.8409       4.0     68.0
Trim every existing link    0.304  0.304  0.400  0.8409  0.8409       4.0     70.2
the frontier h r* + 2(e^2 + t^2) <= r*^2, with r* = 0.8409:
  e = t = 0.40:      h <= (0.7071 - 0.64)/0.8409 = 0.080
  h = e = 0.40:      t <= 0.159
  h = 0.40, e = t:   e <= 0.304, a trim of 24%
  the new link allowed as treasury's links fall (engineering at 0.40): t 0.40: h 0.080, t 0.30: h 0.246, t 0.20: h 0.365, t 0.16: h 0.400, t 0.10: h 0.437, t 0.00: h 0.460
same radius, different landing: ring-fence IND 18.2, DIG 25.4, ENG 17.4, TRS 6.9 | trim IND 18.2, DIG 25.4, ENG 13.3, TRS 13.3
echo with every existing link trimmed, quarters 0-12: 10.0 10.1 7.7 6.8 5.6 4.8 4.0 3.4 2.8 2.4 2.0 1.7 1.4
A $10 million shock at Digital: the new link makes it grow (seed 26114)
Every repair is a point on one frontier (seed 26114)

Panel 4 — Price the nervousness (Worked Example 14.1, Step 4; Theorem 14.4(ii)–(iii); Figure 14.1: 5 to 6.3, $64–70 million)

AXIOM Lab 1.14, step 2, the sensitivity explorer. The steady-state multiplier (I−M)−1B=B+MB+M2B+⋯(\mathbf{I} - \mathbf{M})^{-1}\mathbf{B} = \mathbf{B} + \mathbf{M}\mathbf{B} + \mathbf{M}^{2}\mathbf{B} + \cdots splits the settled deviation into the direct effect that the parameter's owner sees and the knock-on effects along walks of one, two, three links. Each repair, taken as far as the rule allows, sits on its edge: the amplification rises from 5 to 6.3, and the same permanent $10 million shortfall at Digital now settles at $64–70 million a quarter, depending on the repair. What does not depend on the repair is the Perron-weighted response, exactly the Perron-weighted direct effect divided by 1−ρ1 - \rho (Theorem 14.4(iii)). The elasticity table gives the unit-free sensitivities (θj/xi) Sij(\theta_j/x_i)\,S_{ij} that offices should compare rather than raw derivatives. Then turn the blow-up dial: scale today's gains toward a radius of 1 and record how fast the multipliers grow, like 1/(1−ρ)1/(1 - \rho), while the half-life stretches (Figure 14.1). The gap that slows recovery amplifies every recalibration: near its edge a company is slow and nervous at once.

Python Code
B = at()
x, cum = B.copy(), np.zeros(4)
print("today's settled deviation, walk by walk (B, MB, M^2 B, ...): walks of n links")
print(f"  {'n':>3s} " + "".join(f"{u:>8s}" for u in CORE) + f"{'core':>8s}   cumulative core")
for n in range(9):
    cum += x
    print(f"  {n:3d} " + "".join(f"{v:8.3f}" for v in x) + f"{x.sum():8.3f}   {cum.sum():8.3f}")
    x = M0 @ x
print(f"  all  " + "".join(f"{v:8.3f}" for v in s0) + f"{s0.sum():8.3f}   direct {SHOCK:.0f}, knock-on {s0.sum() - SHOCK:.0f}")

print("\neach repair at the limit of the rule (Theorem 14.4(iii)):")
for row in TABLE[2:]:
    M, r, s = row["M"], row["rho"], row["settled"]
    vals, vecs = np.linalg.eig(M.T)
    w = np.abs(vecs[:, np.argmax(vals.real)].real); w = w / w[1]          # Perron weights, Digital = 1
    row["perron"] = float(w @ s)
    print(f"  {row['name']:26s} amplification {amplification(r):.2f}; settled total {s.sum():.1f};"
          f" Perron-weighted {w @ s:.2f} = {w @ B:.0f} / (1 - {r:.4f}); ||(I - M)^-1||_2 = {np.linalg.norm(np.linalg.inv(np.eye(4) - M), 2):.2f}")

def settled_closed(e, t, h, size=SHOCK):
    # by the IND-DIG symmetry: S = x_IND + x_DIG = size/(1 - h - 2(e^2 + t^2)), x_DIG - x_IND = size/(1 + h)
    S, d = size / (1 - h - 2 * (e * e + t * t)), size / (1 + h)
    return np.array([(S - d) / 2, (S + d) / 2, e * S, t * S])
def elasticities(e, t, h, eps=1e-6):
    x0, out = settled_closed(e, t, h), []
    for k, th in enumerate((e, t, h)):
        p, m = [e, t, h], [e, t, h]; p[k] += eps; m[k] -= eps
        dx = (settled_closed(*p) - settled_closed(*m)) / (2 * eps)
        out.append(np.append(th * dx / x0, th * dx.sum() / x0.sum()))
    return np.array(out).T
def rho_elasticities(e, t, h, eps=1e-6):
    out = []
    for k, th in enumerate((e, t, h)):
        p, m = [e, t, h], [e, t, h]; p[k] += eps; m[k] -= eps
        out.append(th * (rho_closed(*p) - rho_closed(*m)) / (2 * eps) / rho_closed(e, t, h))
    return np.array(out)
for row in (TABLE[0], TABLE[4]):
    el = elasticities(row["e"], row["t"], row["h"]); row["elasticities"] = el
    print(f"\nelasticities of the settled deviation, {row['name'].lower()} (percent per percent)")
    print(f"  {'':6s} {'engineering e':>14s} {'treasury t':>11s} {'new link h':>11s}")
    for name, line in zip(CORE + ["core"], el):
        print(f"  {name:6s} {line[0]:14.2f} {line[1]:11.2f} {line[2]:11.2f}")
    re = rho_elasticities(row["e"], row["t"], row["h"]); row["rho_elasticities"] = re
    print(f"  of the radius: {re[0]:.3f}, {re[1]:.3f}, {re[2]:.3f} (sum {re.sum():.2f}: the radius is homogeneous in the gains)")

print("\nthe blow-up dial: today's gains scaled by c")
print(f"  {'rho':>7s} {'c':>6s} {'amplification':>14s} {'half-life':>10s} {'settled total':>14s} {'at Digital':>11s}")
DIAL = []
for r in (0.80, RULE, 0.90, 0.95, 0.97, 0.99):
    c = r / r0; s = settled(c * M0)
    DIAL.append((r, amplification(r), half_life(r), s.sum()))
    print(f"  {r:7.4f} {c:6.3f} {amplification(r):14.2f} {half_life(r):10.1f} {s.sum():14.1f} {s[1]:11.1f}")

rr = np.linspace(0.30, 0.962, 400)
MARK = [(0.80, "today", "#1F4E79"), (RULE, "the board's limit", "#E65100"), (0.95, "near the edge", "#B71C1C")]
fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6))
ax.plot(rr, [half_life(v) for v in rr], color="#616161", lw=1.6)
bx.plot(rr, [amplification(v) for v in rr], color="#616161", lw=1.6)
short = lambda v: f"{v:.1f}".rstrip("0").rstrip(".")
for (v, lab, col), dy in zip(MARK, (-0.7, 0.7, 0.0)):
    ax.plot([v], [half_life(v)], "o", color=col, ms=5, zorder=5)
    bx.plot([v], [amplification(v)], "o", color=col, ms=5, zorder=5)
    if lab == "today":                      # below and right of its point, clear of the curve
        ax.text(v + 0.012, half_life(v) - 0.5, f"{lab}:\n{short(half_life(v))} quarters", fontsize=7.5, color=col,
                ha="left", va="top")
    else:
        ax.text(v - 0.03, half_life(v) + dy, f"{lab}: {short(half_life(v))} quarters", fontsize=7.5, color=col,
                ha="right", va="center")
    bx.text(v - 0.03, amplification(v) + dy, f"{lab}: {short(amplification(v))}×", fontsize=7.5, color=col, ha="right",
            va="center")
ax.set(xlabel="share left after a quarter, ρ", ylabel="half-life (quarters)", xlim=(0.3, 1.0), ylim=(0, 16),
       title="Recovery clock")
bx.set(xlabel="share left after a quarter, ρ", ylabel="amplification, 1/(1 − ρ)", xlim=(0.3, 1.0), ylim=(0, 24),
       title="Amplification")
for z in (ax, bx):
    z.tick_params(labelsize=7); z.xaxis.label.set_size(8); z.yaxis.label.set_size(8); z.title.set_size(9)
fig.suptitle("One gap, two clocks: slow and nervous at once (seed 26114)", fontsize=10)
plt.tight_layout(); plt.show()
today's settled deviation, walk by walk (B, MB, M^2 B, ...): walks of n links
    n      IND     DIG     ENG     TRS    core   cumulative core
    0    0.000  10.000   0.000   0.000  10.000     10.000
    1    0.000   0.000   4.000   4.000   8.000     18.000
    2    3.200   3.200   0.000   0.000   6.400     24.400
    3    0.000   0.000   2.560   2.560   5.120     29.520
    4    2.048   2.048   0.000   0.000   4.096     33.616
    5    0.000   0.000   1.638   1.638   3.277     36.893
    6    1.311   1.311   0.000   0.000   2.621     39.514
    7    0.000   0.000   1.049   1.049   2.097     41.611
    8    0.839   0.839   0.000   0.000   1.678     43.289
  all     8.889  18.889  11.111  11.111  50.000   direct 10, knock-on 40

each repair at the limit of the rule (Theorem 14.4(iii)):
  Run the new link light     amplification 6.29; settled total 64.2; Perron-weighted 62.85 = 10 / (1 - 0.8409); ||(I - M)^-1||_2 = 6.29
  Ring-fence treasury        amplification 6.29; settled total 68.0; Perron-weighted 62.85 = 10 / (1 - 0.8409); ||(I - M)^-1||_2 = 6.29
  Trim every existing link   amplification 6.29; settled total 70.2; Perron-weighted 62.85 = 10 / (1 - 0.8409); ||(I - M)^-1||_2 = 6.29

elasticities of the settled deviation, today (percent per percent)
          engineering e  treasury t  new link h
  IND              2.78        2.78        0.00
  DIG              1.31        1.31        0.00
  ENG              2.78        1.78        0.00
  TRS              1.78        2.78        0.00
  core             2.00        2.00        0.00
  of the radius: 0.500, 0.500, 0.000 (sum 1.00: the radius is homogeneous in the gains)

elasticities of the settled deviation, trim every existing link (percent per percent)
          engineering e  treasury t  new link h
  IND              1.93        1.93        2.14
  DIG              1.39        1.39        1.46
  ENG              2.62        1.62        1.74
  TRS              1.62        2.62        1.74
  core             1.81        1.81        1.74
  of the radius: 0.344, 0.344, 0.312 (sum 1.00: the radius is homogeneous in the gains)

the blow-up dial: today's gains scaled by c
      rho      c  amplification  half-life  settled total  at Digital
   0.8000  1.000           5.00        3.1           50.0        18.9
   0.8409  1.051           6.29        4.0           62.9        22.1
   0.9000  1.125          10.00        6.6          100.0        31.3
   0.9500  1.188          20.00       13.5          200.0        56.3
   0.9700  1.213          33.33       22.8          333.3        89.6
   0.9900  1.238         100.00       69.0         1000.0       256.3
One gap, two clocks: slow and nervous at once (seed 26114)

Panel 5 — Treat it as a structural change (Worked Example 14.1, Step 5; Definition 14.7; Theorem 14.4(i))

AXIOM Lab 1.14, step 3, the perturbation simulator. Definition 14.7 classifies a perturbation by what it changes, and the three kinds propagate by different mathematics. A state perturbation, the $10 million shock at Digital, travels along the dynamics, and its echo is linear in its size. A parametric perturbation travels along the sensitivity recursion Sk+1=AkSk+Bk\mathbf{S}_{k+1} = \mathbf{A}_k\mathbf{S}_k + \mathbf{B}_k (Equation 14.4) toward the steady-state multiplier, and a recalibrated ceiling is priced to first order by its derivative. A structural perturbation changes the register itself: the new link is not a parameter of today's model, so no derivative of today's model prices it, and the core must be re-analyzed with the new block. AXIOM preloads an acquisition as its structural case; the book's own, with declared numbers, is the new link. The integration plan therefore becomes a gain-reduction schedule: each milestone that switches on part of the synergy is matched by a recorded trim elsewhere, re-certified against the rule, and checked against measured gains in the gain audit (Panel 7).

Python Code
e10, e20 = echo(M0).sum(axis=1), echo(M0, at(size=20.0)).sum(axis=1)
print("a state perturbation: the echo of $10 million and of $20 million at Digital, quarters 0-4:",
      e10[:5].round(2), e20[:5].round(2), f"-> ratio {(e20 / e10).min():.0f} in every quarter: linear in the shock")

S_k, path = np.zeros(4), {}
for k in range(1, 41):
    S_k = M0 @ S_k + B                                       # Equation 14.4 with A_k = M, B_k = $10 million at Digital
    path[k] = S_k.copy()
print("a parametric perturbation, the permanent shortfall: S_k by quarter (core total)",
      ", ".join(f"{k}: {path[k].sum():.2f}" for k in (1, 2, 4, 8, 16, 40)), f"-> (I - M)^-1 B = {s0.sum():.2f}")

e1_ = 0.39                                                   # recalibrate the engineering links' ceiling 0.40 -> 0.39
d = 1e-6
drho = (rho_closed(G0 + d) - rho_closed(G0 - d)) / (2 * d)
dtot = (settled_closed(G0 + d, G0, 0).sum() - settled_closed(G0 - d, G0, 0).sum()) / (2 * d)
RECAL = dict(drho=drho, dtot=dtot, rho_first=r0 + (e1_ - G0) * drho, rho_exact=rho_closed(e1_),
             tot_first=s0.sum() + (e1_ - G0) * dtot, tot_exact=settled_closed(e1_, G0, 0).sum())
print(f"a recalibration, the engineering links 0.40 -> 0.39: d rho/d e = {drho:.3f}, d total/d e = {dtot:.1f};"
      f" first order rho {RECAL['rho_first']:.4f}, total {RECAL['tot_first']:.2f};"
      f" re-analysis rho {RECAL['rho_exact']:.4f}, total {RECAL['tot_exact']:.2f}")

cum0 = np.cumsum(echo(M0, quarters=40).sum(axis=1)); cum1 = np.cumsum(echo(M1, quarters=40).sum(axis=1))
print("a structural perturbation, the new link: walk sums of the echo (cumulative deviation) after 4, 12 and 40 quarters:"
      f" today {cum0[4]:.1f}, {cum0[12]:.1f}, {cum0[40]:.1f} (limit {s0.sum():.0f});"
      f" with the new link {cum1[4]:.1f}, {cum1[12]:.1f}, {cum1[40]:.1f}, without limit")
dh_rho = (rho_closed(h=d) - rho_closed(h=-d)) / (2 * d)
dh_tot = (settled_closed(G0, G0, d).sum() - settled_closed(G0, G0, -d).sum()) / (2 * d)
TANGENT = dict(rho=r0 + G0 * dh_rho, total=s0.sum() + G0 * dh_tot)
print(f"even with the link written in as a parameter h, which is already the re-analysis, the tangent at h = 0 puts the"
      f" radius at {TANGENT['rho']:.2f} and the settled total at {TANGENT['total']:.1f}; the re-analysis gives"
      f" {r1:.4f} and no settled total: a structural change is not small")
a state perturbation: the echo of $10 million and of $20 million at Digital, quarters 0-4: [10.    8.    6.4   5.12  4.1 ] [20.   16.   12.8  10.24  8.19] -> ratio 2 in every quarter: linear in the shock
a parametric perturbation, the permanent shortfall: S_k by quarter (core total) 1: 10.00, 2: 18.00, 4: 29.52, 8: 41.61, 16: 48.59, 40: 49.99 -> (I - M)^-1 B = 50.00
a recalibration, the engineering links 0.40 -> 0.39: d rho/d e = 1.000, d total/d e = 250.0; first order rho 0.7900, total 47.50; re-analysis rho 0.7901, total 47.63
a structural perturbation, the new link: walk sums of the echo (cumulative deviation) after 4, 12 and 40 quarters: today 33.6, 47.3, 50.0 (limit 50); with the new link 57.4, 166.5, 768.1, without limit
even with the link written in as a parameter h, which is already the re-analysis, the tangent at h = 0 puts the radius at 1.00 and the settled total at 105.6; the re-analysis gives 1.0246 and no settled total: a structural change is not small

Panel 6 — Run the viability iteration (Theorem 14.5(iii)–(iv); Figure 14.2; Online Appendix 14.B.2: $150 million to stop, out of cash in quarter 4)

AXIOM Lab 1.14, step 4, the feasible-region visualizer, on the corridor of Section 14.6. A unit holds $120 million of cash above its floor, burns $50 million a quarter, and its commitments let it cut the burn by at most $10 million a quarter. Today is feasible, and so is next quarter whatever it does: cash will be $70 million. Yet stopping the burn takes 50+40+30+20+10=15050 + 40 + 30 + 20 + 10 = 150 of cash, and the unit has 120: with the fastest possible cuts, cash runs out in the fourth quarter. The viability iteration of Theorem 14.5(iii) sees it in advance: start from V0=FV_0 = \mathcal{F} and keep in Vj+1V_{j+1} the states with a decision leading into VjV_j. The cell runs it on a grid of states and decisions and finds each VjV_j to be {s≥Nj(r)}\{s \ge N_j(r)\} with Nj(r)=∑i<jmax⁡(r−ib,0)N_j(r) = \sum_{i<j} \max(r - ib, 0) (Online Appendix 14.B.2): at a burn of 50 the requirement grows quarter by quarter through 50, 90, 120, 140 and 150, the kernel's edge. Two repairs reopen the kernel: $30 million more cash, or faster cuts, since exit clauses that allow $15 million a quarter make $110 million enough (cuts of $12.5 million would need $125 million).

Python Code
CASH0, BURN0, CUT = 120.0, 50.0, 10.0
S_MAX, R_MAX = 500.0, 60.0

def runway_path(s, r, b=CUT, quarters=5, cut=True):
    out = [(0, s, r)]
    for k in range(1, quarters + 1):
        s, r = s - r, (max(r - b, 0.0) if cut else r)
        out.append((k, s, r))
    return out

def need(r, b=CUT, j=None):
    # N_j(r): the cash that j quarters of burn consume at the fastest cuts; N(r) as j grows
    tot, i = 0.0, 0
    while (j is None or i < j) and r - i * b > 1e-12:
        tot += r - i * b; i += 1
    return tot

def viability(b, ds=0.5):
    # Theorem 14.5(iii) on a grid: V_0 = F; V_{j+1} = states with some decision u in [0, b] leading into V_j
    S = np.arange(0.0, S_MAX + ds / 2, ds); R = np.arange(0.0, R_MAX + ds / 2, ds)
    i_s, i_r = np.meshgrid(np.arange(len(S)), np.arange(len(R)), indexing="ij")
    to_s = i_s - i_r                                   # s' = s - r, on the same grid
    V = [np.ones(i_s.shape, bool)]
    while True:
        nxt = np.zeros(i_s.shape, bool)
        for u in np.arange(0.0, b + ds / 2, ds):
            to_r = np.maximum(i_r - int(round(u / ds)), 0)
            nxt |= (to_s >= 0) & V[-1][np.clip(to_s, 0, None), to_r]
        if (nxt == V[-1]).all():
            return S, R, V
        V.append(nxt)

edge = lambda S, V, k: float(S[np.argmax(V[:, k])])     # the least cash in V at burn index k
print("the fastest cuts from 120 cash, 50 burn: quarter, cash, burn:",
      " | ".join(f"{k}: {s:.0f}, {r:.0f}" for k, s, r in runway_path(CASH0, BURN0, quarters=4)))
print(f"every decision this quarter leaves cash at {CASH0 - BURN0:.0f}: feasible now and next quarter")
S, R, V10 = viability(CUT)
ir = int(round(BURN0 / 0.5))
print(f"viability iteration, cuts of at most {CUT:.0f} a quarter: {len(V10) - 1} shrinking steps, then V_j stops changing")
print("  cash needed at a burn of 50 to stay admissible j quarters:",
      ", ".join(f"V_{j}: {edge(S, V, ir):.0f}" for j, V in enumerate(V10)))
gap = max(abs(edge(S, V, k) - need(r, CUT, j)) for j, V in enumerate(V10) for k, r in enumerate(R))
nested = all((V10[j + 1] <= V10[j]).all() for j in range(len(V10) - 1))
print(f"  the grid's edges equal N_j(r) at every burn, largest gap {gap:.1e}; nested V_(j+1) within V_j: {nested}")
member = [j for j, V in enumerate(V10) if V[int(round(CASH0 / 0.5)), ir]]
print(f"  (120, 50) lies in V_0 to V_{max(member)}, not in V_{max(member) + 1}: admissible for {max(member)} quarters, not forever")
print(f"  the kernel's edge N(r) = r(r + b)/(2b) where r is a multiple of b: N(50) = {need(BURN0):.0f}; N(30) = {need(30.0):.0f}")
KERNEL = {}
for b in (15.0, 12.5):
    Sb, Rb, Vb = viability(b)
    KERNEL[b] = edge(Sb, Vb[-1], ir)
    print(f"  cuts of at most {b:g} a quarter: the kernel's edge at a burn of 50 is {KERNEL[b]:.0f}"
          f" ({'enough' if KERNEL[b] <= CASH0 else 'not enough'} for 120)")
print(f"repair by cash: {need(BURN0) - CASH0:.0f} more, to {need(BURN0):.0f}")
print("no cuts at all: cash", ", ".join(f"{s:.0f}" for _, s, _ in runway_path(CASH0, BURN0, quarters=3, cut=False)),
      "-> it leaves the feasible region in the third quarter, from 20")

fig, ax = plt.subplots(figsize=(7.6, 3.6))
grey = ["#C9CED6", "#AEB6C2", "#939DAD", "#78859A", "#5D6C86"]
for j in range(1, len(V10) - 1):
    ax.plot(R, [edge(S, V10[j], k) for k in range(len(R))], color=grey[min(j - 1, 4)], lw=1.0)
    ax.text(R[-1] + 0.4, edge(S, V10[j], len(R) - 1), f"$V_{j}$", fontsize=7, color="#616161", va="center")
ax.plot(R, [edge(S, V10[-1], k) for k in range(len(R))], color="#1F4E79", lw=2.2, label="the kernel's edge: cuts of at most 10")
Sb, Rb, Vb = viability(15.0)
ax.plot(Rb, [edge(Sb, Vb[-1], k) for k in range(len(Rb))], color="#E65100", lw=1.6, ls="--", label="the kernel's edge: cuts of at most 15")
ax.plot(R, R, color="#B71C1C", lw=1.0, label="below: out of cash next quarter")
pts = runway_path(CASH0, BURN0, quarters=4)
ax.plot([r for _, _, r in pts], [s for _, s, _ in pts], color="#000000", lw=1.0, marker="o", ms=3.5, zorder=5,
        label="fastest cuts from 120 cash, 50 burn")
for k, s, r in pts:
    ax.text(r + 1.0, s - 4, f"q{k}", fontsize=7, va="top", bbox=dict(fc="white", ec="none", pad=0.4), zorder=6)
ax.annotate("", xy=(BURN0, need(BURN0) - 2), xytext=(BURN0, CASH0 + 2), arrowprops=dict(arrowstyle="-|>", color="#1F4E79", lw=1.0))
ax.text(BURN0 - 1.0, 160, "+30 cash", fontsize=8, color="#1F4E79", ha="right")
ax.axhline(0, color="#999999", lw=0.6)
ax.set(xlabel="burn rate (\\$ million a quarter)", ylabel="cash above the floor (\\$ million)", xlim=(0, 64), ylim=(-40, 200),
       title="Only the kernel sees the runway trap in advance (seed 26114)")
ax.legend(frameon=False, fontsize=7.5, loc="upper left"); plt.tight_layout(); plt.show()
the fastest cuts from 120 cash, 50 burn: quarter, cash, burn: 0: 120, 50 | 1: 70, 40 | 2: 30, 30 | 3: 0, 20 | 4: -20, 10
every decision this quarter leaves cash at 70: feasible now and next quarter
viability iteration, cuts of at most 10 a quarter: 6 shrinking steps, then V_j stops changing
  cash needed at a burn of 50 to stay admissible j quarters: V_0: 0, V_1: 50, V_2: 90, V_3: 120, V_4: 140, V_5: 150, V_6: 150
  the grid's edges equal N_j(r) at every burn, largest gap 0.0e+00; nested V_(j+1) within V_j: True
  (120, 50) lies in V_0 to V_3, not in V_4: admissible for 3 quarters, not forever
  the kernel's edge N(r) = r(r + b)/(2b) where r is a multiple of b: N(50) = 150; N(30) = 60
  cuts of at most 15 a quarter: the kernel's edge at a burn of 50 is 110 (enough for 120)
  cuts of at most 12.5 a quarter: the kernel's edge at a burn of 50 is 125 (not enough for 120)
repair by cash: 30 more, to 150
no cuts at all: cash 120, 70, 20, -30 -> it leaves the feasible region in the third quarter, from 20
Only the kernel sees the runway trap in advance (seed 26114)

Panel 7 — Read the dashboard and run the gain audit (Table 14.2; Definition 14.11; Theorem 14.6(ii))

AXIOM Lab 1.14, step 5, first part, the diagnostics dashboard. Table 14.2 lists five stability tests; the dashboard runs them on the five registers of Table 14.4, read at their ceilings. The certified budget, the block small gain on Chapter 9's two layers and the Lyapunov bowl agree with the spectral test, except that the block sizes are coarse for the ring-fenced register: they certify its stability but not the board's rule. Contraction, the strongest and rarest test, fails for the trimmed register although its radius meets the rule. The complexity panel of Definition 14.11 reads the register's dimension, sparsity, gap and conditioning. The gain audit of Theorem 14.6(ii) lays measured gains against the register entry by entry and attributes each violation to the channel that exceeds its ceiling. The book declares no measured record, so the measured gains here are those of three states Worked Example 14.1 describes. Against today's register the phase-two link is an undeclared channel, with a ceiling of zero, and the audit flags it; against the re-budgeted register the audit passes only if the trims have actually happened.

Python Code
print("Table 14.2's tests on each register, at its ceilings (rho: spectral radius; L: max row sum)")
print(f"  {'register':26s} {'spectral':>9s} {'blocks':>7s} {'P: least eigenvalue':>20s} {'L':>6s} {'rule':>5s}")
TESTS = []
for row in TABLE:
    M = row["M"]; r = row["rho"]
    rb = rho(block_sizes(M))
    lam = np.linalg.eigvalsh(sla.solve_discrete_lyapunov(M.T, np.eye(4))).min()
    L = float(np.abs(M).sum(axis=1).max())
    TESTS.append(dict(name=row["name"], rho=r, blocks=rb, lyap_min=float(lam), L=L))
    print(f"  {row['name']:26s} {r:9.4f} {rb:7.4f} {lam:20.2f} {L:6.3f} {('yes' if r <= RULE + 1e-12 else 'no'):>5s}")
print("  each test passes below 1 (spectral, blocks, L) or above 0 (Lyapunov: P positive definite); the rule needs rho <= 0.8409")

print("\nthe complexity panel (Definition 14.11), one quarterly clock")
for row in TABLE:
    M = row["M"]; r = row["rho"]
    nz = int((M > 0).sum())
    gap = f"{1 - r:.3f}" if r < 1 else "none"
    cond = f"{amplification(r):.2f}" if r < 1 else "none"
    print(f"  {row['name']:26s} n = 4, channels {nz:2d} of 12, spectral gap {gap:>6s}, conditioning {cond:>5s}")

def audit(measured, ceiling, label):
    viol = [(CORE[i], CORE[j], measured[i, j], ceiling[i, j]) for i in range(4) for j in range(4)
            if abs(measured[i, j]) > ceiling[i, j] + 1e-9]
    print(f"{label}: {len(viol)} violation(s)" + ("; certificate renewed" if not viol else "; certificate suspended"))
    for i, j, m, c in viol:
        print(f"    channel {j} -> {i}: measured {m:.3f} against a ceiling of {c:.3f}")
    return viol

REG_TODAY, REG_NEW = register(), TABLE[4]["M"]          # today's register; the re-budgeted one (trim every link)
LIVE_TRIMMED, LIVE_UNTRIMMED = TABLE[4]["M"], register(h=G0)
print("\nthe gain audit (Theorem 14.6(ii)): measured gains against the register, entry by entry")
v1 = audit(LIVE_UNTRIMMED, REG_TODAY, "phase two switched on, measured against today's register")
reach = (np.linalg.matrix_power(np.eye(4) + adj1, 2) > 0)[:, [CORE.index("IND"), CORE.index("DIG")]].any(axis=1)
print(f"    its consequences travel along walks from that channel: every unit reached within two quarters: {bool(reach.all())}")
v2 = audit(LIVE_TRIMMED, REG_NEW, "the trims recorded and made, measured against the re-budgeted register")
v3 = audit(LIVE_UNTRIMMED, REG_NEW, "the link switched on but the trims never made, against the re-budgeted register")
print(f"    the guarantee fails with the audit: the register promises rho <= {rho(REG_NEW):.4f}; the measured gains give {rho(LIVE_UNTRIMMED):.4f}")
Table 14.2's tests on each register, at its ceilings (rho: spectral radius; L: max row sum)
  register                    spectral  blocks  P: least eigenvalue      L  rule
  Today                         0.8000  0.8000                 1.00  0.800   yes
  New link at the ceiling       1.0246  1.0246               -20.06  1.200    no
  Run the new link light        0.8409  0.8409                 1.00  0.880   yes
  Ring-fence treasury           0.8409  0.8982                 1.00  0.959   yes
  Trim every existing link      0.8409  0.8409                 1.00  1.009   yes
  each test passes below 1 (spectral, blocks, L) or above 0 (Lyapunov: P positive definite); the rule needs rho <= 0.8409

the complexity panel (Definition 14.11), one quarterly clock
  Today                      n = 4, channels  8 of 12, spectral gap  0.200, conditioning  5.00
  New link at the ceiling    n = 4, channels 10 of 12, spectral gap   none, conditioning  none
  Run the new link light     n = 4, channels 10 of 12, spectral gap  0.159, conditioning  6.29
  Ring-fence treasury        n = 4, channels 10 of 12, spectral gap  0.159, conditioning  6.29
  Trim every existing link   n = 4, channels 10 of 12, spectral gap  0.159, conditioning  6.29

the gain audit (Theorem 14.6(ii)): measured gains against the register, entry by entry
phase two switched on, measured against today's register: 2 violation(s); certificate suspended
    channel DIG -> IND: measured 0.400 against a ceiling of 0.000
    channel IND -> DIG: measured 0.400 against a ceiling of 0.000
    its consequences travel along walks from that channel: every unit reached within two quarters: True
the trims recorded and made, measured against the re-budgeted register: 0 violation(s); certificate renewed
the link switched on but the trims never made, against the re-budgeted register: 8 violation(s); certificate suspended
    channel ENG -> IND: measured 0.400 against a ceiling of 0.304
    channel TRS -> IND: measured 0.400 against a ceiling of 0.304
    channel ENG -> DIG: measured 0.400 against a ceiling of 0.304
    channel TRS -> DIG: measured 0.400 against a ceiling of 0.304
    channel IND -> ENG: measured 0.400 against a ceiling of 0.304
    channel DIG -> ENG: measured 0.400 against a ceiling of 0.304
    channel IND -> TRS: measured 0.400 against a ceiling of 0.304
    channel DIG -> TRS: measured 0.400 against a ceiling of 0.304
    the guarantee fails with the audit: the register promises rho <= 0.8409; the measured gains give 1.0246

Panel 8 — Trip an invariant on purpose (Theorem 14.7(iv); Section 14.7: a jump, a drift, a breach)

AXIOM Lab 1.14, step 5, last part. Along any admissible computed trajectory a declared identity holds exactly, and a violation proves a fault (Theorem 14.7(iv)). The time signature of the violation guides the search: a jump suggests an implementation error, a steady drift a mis-declared map, and a violation that arrives with a constraint breach an inadmissible state. The runway's cash identity, cash falls each quarter by that quarter's burn, is tripped here on purpose three ways along the fastest-cuts path: a quarter's burn not posted; cuts booked in the quarter they are decided rather than the next; and a model that never lets cash fall below the floor. The classifier reads only the residuals and the floor.

Python Code
def computed(fault):
    # the fastest-cuts path as a faulty model computes it; returns cash and burn by quarter
    s, r, out = CASH0, BURN0, [(CASH0, BURN0)]
    for k in range(5):
        r_next = max(r - CUT, 0.0)
        if fault == "unposted" and k == 1:
            s_next = s                                    # quarter 1's burn never posted
        elif fault == "early cuts":
            s_next = s - r_next                           # the cut booked in the quarter it is decided
        elif fault == "floored":
            s_next = max(s - r, 0.0)                      # cash never allowed below the floor
        else:
            s_next = s - r
        s, r = s_next, r_next
        out.append((s, r))
    return np.array(out)

def classify(path):
    s, r = path[:, 0], path[:, 1]
    resid = s[1:] - (s[:-1] - r[:-1])                     # the identity: s_(k+1) = s_k - r_k
    hit = np.nonzero(np.abs(resid) > 1e-9)[0]
    if len(hit) == 0:
        return resid, "identity holds"
    if (s[:-1][hit] - r[:-1][hit] < 0).all():
        return resid, "arrives with a breach of the floor: an inadmissible state"
    if len(hit) == 1:
        return resid, "a one-quarter jump: an implementation error"
    return resid, "a steady drift: a mis-declared map"

TRIP = {}
for fault in ("none", "unposted", "early cuts", "floored"):
    p = computed(fault)
    resid, verdict = classify(p)
    TRIP[fault] = dict(cash=p[:, 0].tolist(), resid=resid.tolist(), verdict=verdict)
    print(f"{fault:11s} cash {', '.join(f'{v:.0f}' for v in p[:, 0])}; residuals {', '.join(f'{v:+.0f}' for v in resid)}")
    print(f"{'':11s} -> {verdict}")
print("the unposted burn and the early cuts both hide the trap: the faulty books end above the floor")
none        cash 120, 70, 30, 0, -20, -30; residuals +0, +0, +0, +0, +0
            -> identity holds
unposted    cash 120, 70, 70, 40, 20, 10; residuals +0, +40, +0, +0, +0
            -> a one-quarter jump: an implementation error
early cuts  cash 120, 80, 50, 30, 20, 20; residuals +10, +10, +10, +10, +10
            -> a steady drift: a mis-declared map
floored     cash 120, 70, 30, 0, 0, 0; residuals +0, +0, +0, +20, +10
            -> arrives with a breach of the floor: an inadmissible state
the unposted burn and the early cuts both hide the trap: the faulty books end above the floor

Panel 9 — Write the analysis certificate (AXIOM Lab 1.14, the deliverable)

The lab's deliverable is a one-page analysis certificate for the board: the register's spectral radius and its margin; the half-life and the amplification; the re-budget for the new link, with its cost; the viability check and its repairs; and the audit plan. The cell assembles it from the panels above. The audit plan measures first the channels whose gains move the radius most, by the elasticities of Panel 4.

Python Code
lim = TABLE[4]
print("ANALYSIS CERTIFICATE, Meridian's feedback core (Worked Example 14.1; AXIOM Lab 1.14)")
print(f"1. Register today: spectral radius {r0:.2f}, margin {1 - r0:.2f} to the edge and {RULE - r0:.3f} to the board's rule;"
      f" certified for any true gains within the 0.40 ceilings.")
print(f"2. Clocks today: half-life {half_life(r0):.1f} quarters; amplification {amplification(r0):.0f}:"
      f" a permanent $10 million a quarter at Digital settles at ${s0.sum():.0f} million, ${s0.sum() - SHOCK:.0f} million knock-on.")
print(f"3. The new link at 0.40: radius {r1:.2f}, no certificate. Re-budget at the rule's limit, radius {RULE:.4f}:"
      f" the link at most {h_max():.2f}; or treasury's links to {t_max():.2f}; or every existing link to {even_trim():.2f}.")
print(f"   Cost: amplification {amplification(RULE):.1f} instead of 5; the same shortfall settles at"
      f" ${TABLE[2]['settled'].sum():.0f}-{TABLE[4]['settled'].sum():.0f} million a quarter.")
print(f"4. Viability: $120 million against a $50 million burn cut by at most $10 million a quarter is admissible for"
      f" {max(member)} quarters; stopping needs ${need(BURN0):.0f} million. Repairs: +${need(BURN0) - CASH0:.0f} million,"
      f" or cuts of $15 million a quarter (need ${KERNEL[15.0]:.0f} million).")
re = lim["rho_elasticities"]
print(f"5. Audit plan (trim every existing link): measure the new link first, elasticity of the radius {re[2]:.2f},"
      f" then the four trimmed links, {re[0] / 2:.2f} each, to know that the trims have actually happened; compare each"
      f" with its recorded ceiling every quarter; the risk office, which owns the register, suspends the certificate"
      f" when a channel exceeds its ceiling.")
ANALYSIS CERTIFICATE, Meridian's feedback core (Worked Example 14.1; AXIOM Lab 1.14)
1. Register today: spectral radius 0.80, margin 0.20 to the edge and 0.041 to the board's rule; certified for any true gains within the 0.40 ceilings.
2. Clocks today: half-life 3.1 quarters; amplification 5: a permanent $10 million a quarter at Digital settles at $50 million, $40 million knock-on.
3. The new link at 0.40: radius 1.02, no certificate. Re-budget at the rule's limit, radius 0.8409: the link at most 0.08; or treasury's links to 0.16; or every existing link to 0.30.
   Cost: amplification 6.3 instead of 5; the same shortfall settles at $64-70 million a quarter.
4. Viability: $120 million against a $50 million burn cut by at most $10 million a quarter is admissible for 3 quarters; stopping needs $150 million. Repairs: +$30 million, or cuts of $15 million a quarter (need $110 million).
5. Audit plan (trim every existing link): measure the new link first, elasticity of the radius 0.31, then the four trimmed links, 0.17 each, to know that the trims have actually happened; compare each with its recorded ceiling every quarter; the risk office, which owns the register, suspends the certificate when a channel exceeds its ceiling.

Validation — the book's numbers, and agreement with DCT_V1_Ch14_Lab.xlsx

Each checkpoint is a number printed in Chapter 14 (Worked Example 14.1, Table 14.4, Figures 14.1–14.3, Sections 14.4–14.6, LOS Guidance 14.3–14.4) or in Online Appendix 14.B.1–14.B.3. The workbook recomputes the ones marked workbook with Excel formulas and shows PASS against the same engine values on its Checks sheet.

Python Code
T = {row["name"]: row for row in TABLE}
light, ring_, trim_ = T["Run the new link light"], T["Ring-fence treasury"], T["Trim every existing link"]
e_trim = echo(trim_["M"]).sum(axis=1)
checks = [
    ("today: pass-on per unit (workbook)", M0.sum(axis=0).max(), 0.80, 1e-9),
    ("today: spectral radius (workbook)", r0, 0.80, 5e-5),
    ("today: half-life, quarters (workbook)", half_life(r0), 3.11, 0.005),
    ("today: quarters to a tenth (workbook)", to_tenth(r0), 10.3, 0.05),
    ("today: amplification (workbook)", amplification(r0), 5, 1e-9),
    ("today: settled total, $ million (workbook)", s0.sum(), 50, 0.05),
    ("today: settled at Digital (workbook)", s0[1], 18.89, 0.005),
    ("today: settled at engineering (workbook)", s0[2], 11.11, 0.005),
    ("today: settled at treasury (workbook)", s0[3], 11.11, 0.005),
    ("today: settled at Industrial Systems (workbook)", s0[0], 8.89, 0.005),
    ("today: knock-on, $ million (workbook)", s0.sum() - SHOCK, 40, 0.05),
    ("today: echo in quarter 3 (workbook)", e0[3], 5.1, 0.05),
    ("today: echo in quarter 12 (workbook)", e0[12], 0.7, 0.05),
    ("new link: pass-on of IND and DIG (workbook)", M1.sum(axis=0)[1], 1.20, 1e-9),
    ("new link: spectral radius (workbook)", r1, 1.0246, 5e-5),
    ("new link: new loops of three links", np.trace(adj1 @ adj1 @ adj1) / 6, 2, 0),
    ("new link: echo in quarter 1 (workbook)", e1[1], 12, 0.05),
    ("new link: echo in quarter 3 (workbook)", e1[3], 12.2, 0.05),
    ("new link: echo after three years (workbook)", e1[12], 14.8, 0.05),
    ("board's rule: spectral radius (workbook)", RULE, 0.8409, 5e-5),
    ("run the link light: new link (workbook)", light["h"], 0.080, 5e-4),
    ("ring-fence: treasury links (workbook)", ring_["t"], 0.159, 5e-4),
    ("trim: every existing link (workbook)", trim_["e"], 0.304, 5e-4),
    ("at the limit: half-life, quarters (workbook)", half_life(trim_["rho"]), 4.0, 0.05),
    ("at the limit: quarters to a tenth (workbook)", to_tenth(trim_["rho"]), 13.3, 0.05),
    ("at the limit: amplification (workbook)", amplification(trim_["rho"]), 6.29, 0.005),
    ("run the link light: settled total (workbook)", light["settled"].sum(), 64.2, 0.05),
    ("ring-fence: settled total (workbook)", ring_["settled"].sum(), 68.0, 0.05),
    ("trim: settled total (workbook)", trim_["settled"].sum(), 70.2, 0.05),
    ("trim: echo in quarter 1 (workbook)", e_trim[1], 10.1, 0.05),
    ("trim: echo in quarter 12 (workbook)", e_trim[12], 1.4, 0.05),
    ("near the edge, 0.95: half-life (workbook)", half_life(0.95), 13.5, 0.05),
    ("near the edge, 0.95: amplification (workbook)", amplification(0.95), 20, 1e-9),
    ("runway: cash after one quarter (workbook)", runway_path(CASH0, BURN0)[1][1], 70, 0),
    ("runway: cash in quarter 4, fastest cuts (workbook)", runway_path(CASH0, BURN0)[4][1], -20, 0),
    ("runway: quarter cash runs out, fastest cuts (workbook)", next(k for k, s, _ in runway_path(CASH0, BURN0) if s < 0), 4, 0),
    ("runway: N_3(50), cash for three quarters (workbook)", need(BURN0, j=3), 120, 0),
    ("runway: N_4(50), cash for four quarters (workbook)", need(BURN0, j=4), 140, 0),
    ("runway: cash needed to stop (workbook)", need(BURN0), 150, 0),
    ("runway: more cash needed (workbook)", need(BURN0) - CASH0, 30, 0),
    ("runway: kernel edge, grid iteration", edge(S, V10[-1], ir), 150, 0),
    ("runway: quarters admissible from (120, 50) (workbook)", max(member), 3, 0),
    ("runway: need with cuts of 15 (workbook)", need(BURN0, 15.0), 110, 0),
    ("runway: need with cuts of 12.5 (workbook)", need(BURN0, 12.5), 125, 0),
    ("runway: kernel edge with cuts of 15, grid", KERNEL[15.0], 110, 0),
    ("runway: no cuts, cash after two quarters (workbook)", runway_path(CASH0, BURN0, cut=False)[2][1], 20, 0),
    ("runway: no cuts, quarter it leaves the region (workbook)",
     next(k for k, s, _ in runway_path(CASH0, BURN0, cut=False) if s < 0), 3, 0),
]
ok, width = 0, max(len(name) for name, *_ in checks)
for name, got, want, tol in checks:
    status = "PASS" if abs(got - want) <= tol + 1e-9 else "FAIL"; ok += status == "PASS"
    print(f"{name:{width}s} {got:10.4f}   book {want:9.4f}   {status}")
print(f"\n{ok} of {len(checks)} checkpoints PASS")
today: pass-on per unit (workbook)                           0.8000   book    0.8000   PASS
today: spectral radius (workbook)                            0.8000   book    0.8000   PASS
today: half-life, quarters (workbook)                        3.1063   book    3.1100   PASS
today: quarters to a tenth (workbook)                       10.3189   book   10.3000   PASS
today: amplification (workbook)                              5.0000   book    5.0000   PASS
today: settled total, $ million (workbook)                  50.0000   book   50.0000   PASS
today: settled at Digital (workbook)                        18.8889   book   18.8900   PASS
today: settled at engineering (workbook)                    11.1111   book   11.1100   PASS
today: settled at treasury (workbook)                       11.1111   book   11.1100   PASS
today: settled at Industrial Systems (workbook)              8.8889   book    8.8900   PASS
today: knock-on, $ million (workbook)                       40.0000   book   40.0000   PASS
today: echo in quarter 3 (workbook)                          5.1200   book    5.1000   PASS
today: echo in quarter 12 (workbook)                         0.6872   book    0.7000   PASS
new link: pass-on of IND and DIG (workbook)                  1.2000   book    1.2000   PASS
new link: spectral radius (workbook)                         1.0246   book    1.0246   PASS
new link: new loops of three links                           2.0000   book    2.0000   PASS
new link: echo in quarter 1 (workbook)                      12.0000   book   12.0000   PASS
new link: echo in quarter 3 (workbook)                      12.1600   book   12.2000   PASS
new link: echo after three years (workbook)                 14.8094   book   14.8000   PASS
board's rule: spectral radius (workbook)                     0.8409   book    0.8409   PASS
run the link light: new link (workbook)                      0.0798   book    0.0800   PASS
ring-fence: treasury links (workbook)                        0.1593   book    0.1590   PASS
trim: every existing link (workbook)                         0.3044   book    0.3040   PASS
at the limit: half-life, quarters (workbook)                 4.0000   book    4.0000   PASS
at the limit: quarters to a tenth (workbook)                13.2877   book   13.3000   PASS
at the limit: amplification (workbook)                       6.2852   book    6.2900   PASS
run the link light: settled total (workbook)                64.2407   book   64.2000   PASS
ring-fence: settled total (workbook)                        68.0166   book   68.0000   PASS
trim: settled total (workbook)                              70.1801   book   70.2000   PASS
trim: echo in quarter 1 (workbook)                          10.0889   book   10.1000   PASS
trim: echo in quarter 12 (workbook)                          1.4138   book    1.4000   PASS
near the edge, 0.95: half-life (workbook)                   13.5134   book   13.5000   PASS
near the edge, 0.95: amplification (workbook)               20.0000   book   20.0000   PASS
runway: cash after one quarter (workbook)                   70.0000   book   70.0000   PASS
runway: cash in quarter 4, fastest cuts (workbook)         -20.0000   book  -20.0000   PASS
runway: quarter cash runs out, fastest cuts (workbook)       4.0000   book    4.0000   PASS
runway: N_3(50), cash for three quarters (workbook)        120.0000   book  120.0000   PASS
runway: N_4(50), cash for four quarters (workbook)         140.0000   book  140.0000   PASS
runway: cash needed to stop (workbook)                     150.0000   book  150.0000   PASS
runway: more cash needed (workbook)                         30.0000   book   30.0000   PASS
runway: kernel edge, grid iteration                        150.0000   book  150.0000   PASS
runway: quarters admissible from (120, 50) (workbook)        3.0000   book    3.0000   PASS
runway: need with cuts of 15 (workbook)                    110.0000   book  110.0000   PASS
runway: need with cuts of 12.5 (workbook)                  125.0000   book  125.0000   PASS
runway: kernel edge with cuts of 15, grid                  110.0000   book  110.0000   PASS
runway: no cuts, cash after two quarters (workbook)         20.0000   book   20.0000   PASS
runway: no cuts, quarter it leaves the region (workbook)     3.0000   book    3.0000   PASS

47 of 47 checkpoints PASS

Next. Chapter 15 poses the General Enterprise Optimization Problem on this certified object: its feasible set is the audited region with the viability kernel as its honest core, its gradients are this chapter's sensitivities, and under the board's half-life rule the stability budget is a shared resource with a price: every 0.01 trimmed from both engineering links, or from both treasury links, frees 0.019 of the new link. AXIOM-14 runs the same model interactively (Lab 1.14); this notebook and the workbook are its reproducible record.

Dynamic Corporate Transformation — Volume I: Foundations and Mathematical Framework; Volume II: Enterprise Optimization & Applications
Jump to any chapter

Volume I: Foundations and Mathematical Framework

  1. Ch. 1Introduction to Dynamic Corporate Transformation
  2. Ch. 2Enterprise Systems and Transformation
  3. Ch. 3Mathematical Foundations
  4. Ch. 4Enterprise Modeling Principles
  5. Ch. 5Enterprise State Representation
  6. Ch. 6Enterprise Transformation Operators
  7. Ch. 7Dynamic Enterprise Systems
  8. Ch. 8Stochastic Enterprise Dynamics
  9. Ch. 9Enterprise State Architecture
  10. Ch. 10Enterprise Capital Architecture
  11. Ch. 11Enterprise Performance Architecture
  12. Ch. 12Enterprise Risk, Resilience, and Robustness Architecture
  13. Ch. 13Unified Enterprise Transformation Architecture
  14. Ch. 14Mathematical Analysis of the Unified Enterprise Transformation Architecture
  15. Ch. 15Mathematical Formulation of Enterprise Optimization
  16. Ch. 16Synthesis, Future Directions, and Transition to Volume II

Volume II: Enterprise Optimization & Applications

  1. Ch. 1Introduction to Enterprise Optimization
  2. Ch. 2The General Enterprise Optimization Problem Revisited
  3. Ch. 3Convex Enterprise Optimization
  4. Ch. 4Nonlinear and Mixed-Integer Enterprise Optimization
  5. Ch. 5Dynamic Enterprise Optimization
  6. Ch. 6Optimal Control of Enterprise Systems
  7. Ch. 7Dynamic Programming for Enterprise Systems
  8. Ch. 8Hamilton–Jacobi–Bellman Enterprise Framework
  9. Ch. 9Stochastic Enterprise Optimization
  10. Ch. 10Neuro-Fuzzy Robust Enterprise Optimization
  11. Ch. 11Distributionally Robust Enterprise Optimization
  12. Ch. 12Multi-Objective Enterprise Optimization
  13. Ch. 13Machine Learning for Enterprise Transformation
  14. Ch. 14Artificial Intelligence for Enterprise Optimization
  15. Ch. 15Enterprise Digital Twins and Autonomous Enterprise Transformation
  16. Ch. 16Enterprise Applications and Integrated Transformation Case Studies

Dynamic Corporate Transformation

Springer Nature · Management for Professionals · Forthcoming 2027

  • Volume I — Foundations and Mathematical Framework
  • Volume II — Enterprise Optimization & Applications
Buy Volume I: Dynamic Corporate Transformation: Foundations and Mathematical FrameworkBuy Volume II: Dynamic Corporate Transformation: Enterprise Optimization & Applications
Jump to any chapter

Volume I: Foundations and Mathematical Framework

  1. Ch. 1Introduction to Dynamic Corporate Transformation
  2. Ch. 2Enterprise Systems and Transformation
  3. Ch. 3Mathematical Foundations
  4. Ch. 4Enterprise Modeling Principles
  5. Ch. 5Enterprise State Representation
  6. Ch. 6Enterprise Transformation Operators
  7. Ch. 7Dynamic Enterprise Systems
  8. Ch. 8Stochastic Enterprise Dynamics
  9. Ch. 9Enterprise State Architecture
  10. Ch. 10Enterprise Capital Architecture
  11. Ch. 11Enterprise Performance Architecture
  12. Ch. 12Enterprise Risk, Resilience, and Robustness Architecture
  13. Ch. 13Unified Enterprise Transformation Architecture
  14. Ch. 14Mathematical Analysis of the Unified Enterprise Transformation Architecture
  15. Ch. 15Mathematical Formulation of Enterprise Optimization
  16. Ch. 16Synthesis, Future Directions, and Transition to Volume II

Volume II: Enterprise Optimization & Applications

  1. Ch. 1Introduction to Enterprise Optimization
  2. Ch. 2The General Enterprise Optimization Problem Revisited
  3. Ch. 3Convex Enterprise Optimization
  4. Ch. 4Nonlinear and Mixed-Integer Enterprise Optimization
  5. Ch. 5Dynamic Enterprise Optimization
  6. Ch. 6Optimal Control of Enterprise Systems
  7. Ch. 7Dynamic Programming for Enterprise Systems
  8. Ch. 8Hamilton–Jacobi–Bellman Enterprise Framework
  9. Ch. 9Stochastic Enterprise Optimization
  10. Ch. 10Neuro-Fuzzy Robust Enterprise Optimization
  11. Ch. 11Distributionally Robust Enterprise Optimization
  12. Ch. 12Multi-Objective Enterprise Optimization
  13. Ch. 13Machine Learning for Enterprise Transformation
  14. Ch. 14Artificial Intelligence for Enterprise Optimization
  15. Ch. 15Enterprise Digital Twins and Autonomous Enterprise Transformation
  16. Ch. 16Enterprise Applications and Integrated Transformation Case Studies
