Vol. II, Ch. 15

DCT Laboratory — Volume II, Chapter 15

Enterprise Digital Twins and Autonomous Enterprise Transformation

This laboratory demonstrates

Seed 26215 · Companion to Chapter 15 and AXIOM Lab 2.15 (module AXIOM-15) · Mirrored in DCT_V2_Ch15_Lab.xlsx

This laboratory reproduces Worked Example 15.1, Can a Digital Twin Replace the Engineering Office's Count?, with the book's declarations, and works the five steps of AXIOM Lab 2.15: synchronize, decide, price readings, monitor, and set the envelope. The law, the costs and the hiring rule are Chapter 7's; the new declarations are the skills survey's error and calendar, the twin, its monitor and threshold, the audit on an alarm, and a drift to test the monitor. The seeds are the book's (Online Appendix Remark 15.B.1): 20,000 design paths with seed 1500, 100,000 fresh paths with seed 1501, the program of Figure 15.1(a) seed 1503, the monitor's calibration seed 1505, the drift seed 1507, and the exact filter's check seed 1509. The lab's own seed, 26215, draws only new illustrations: Panel 2's independent paths and Panel 5's ten programs. The book's engine takes about seven and a half minutes; these cells reproduce its numbers in about seventy seconds on two cores, because they draw the same numbers one quarter at a time and search for each design's best target in a window around the book's (Panel 2 says how). Every Meridian number below is the book's (Table 15.3, Figures 15.1–15.3, Online Appendix Example 15.B.2); the final cell checks them. Money is in $ million.

The declarations (Worked Example 15.1, Step 1; Online Appendix Remark 15.B.1)

Chapter 7's model, unchanged. Workforce capability cc moves as c′=0.975c+h−wc' = 0.975c + h - w: hh is the points hired and trained in a quarter, at $4 million a point and at most 2.5 a quarter, and ww the engineering office's swings, 1.5, 0.75, 0, −0.75-0.75 or −1.5-1.5 points lost with chances 0.05, 0.20, 0.50, 0.20 and 0.05 (variance q=0.45q = 0.45). A point short of the floor of 55 for a quarter costs $1.6 million, so a quarter costs 4h+1.6 (55−c)+4h + 1.6\,(55 - c)^{+}, and the board discounts at β=1.1−1/4\beta = 1.1^{-1/4} a quarter. Chapter 7's rule brings planned capability 0.975c+h0.975c + h to a target: 55.75 on the engineering office's count, at $230.755 million of cost from 58 (Worked Example 7.1).

The twin (new declarations). The chief operating officer proposes to retire the count, a manual assessment by team leads, and to run the rule on a twin fed by the skills survey. The program starts from an audited 58. The survey runs twice a year, at the start of quarters 2, 4, 6, …, and reads z=c+vz = c + v, its error vv normal with a standard deviation of 2.5 points (95 percent of readings within ±5\pm 5; Volume I, Table 5.2). The twin knows the law and its own hires but not the swings. It keeps its estimate c^\hat c by the Kalman filter (Equation 15.1) with a=0.975a = 0.975, the swings' mean 0 and variance qq, and a variance of 0 at the audited start, and it hires h=min⁡{max⁡{T−0.975c^,0},2.5}h = \min\{\max\{T - 0.975\hat c, 0\}, 2.5\} for a target TT of planned capability on its estimate. The board's alternatives: the survey read as exact, each reading carried forward by c^′=0.975c^+h\hat c' = 0.975\hat c + h; a quarterly survey; a survey twice as sharp, 1.25 points; both; and no readings after the audit. Costs are present values over 480 quarters, and shares below the floor are taken over quarters 40–479. Each design's target is chosen on 20,000 design paths and valued on 100,000 fresh ones, every design on the same draws of swings and survey errors (common random numbers, Proposition 15.2). The twin's envelope is Chapter 14's guardrail: never plan below 55 unless hiring at the cap.

The monitor and the drift. The monitor is a one-sided cumulative sum (Equation 15.2) of the surveys' standardized innovations z=(reading−c^−)/P−+rz = (\text{reading} - \hat c^{-})/\sqrt{P^{-} + r}, with reference κ=0.5\kappa = 0.5 and the least threshold, on a grid of 0.25 from 1.5, that raises at most one false alarm in 50 surveys. On an alarm the engineering office audits capability: the estimate is set to it with variance 0, the sum restarts, and, once a drift has begun, the law's mean is re-estimated as the drift and the target raised by it. The drift that tests the monitor, a tighter labor market: from the start of quarter 8 each quarter loses an extra half point.

Python Code
import math
import time
import numpy as np
from scipy.stats import norm
import matplotlib.pyplot as plt
plt.rcParams.update({"figure.dpi": 110, "axes.spines.top": False, "axes.spines.right": False})
T_START = time.time()
SEED = 26215            # the lab's seed: new draws only (Panel 2's independent paths, Panel 5's ten programs)
SEED_DESIGN = 1500      # the book's seeds (Online Appendix Remark 15.B.1): the 20,000 design paths,
SEED_FRESH = 1501       #   the 100,000 fresh paths,
SEED_PATH = 1503        #   the program of Figure 15.1(a),
SEED_CAL = 1505         #   the monitor's calibration, 20,000 paths without a drift,
SEED_DRIFT = 1507       #   the drift, 100,000 paths,
SEED_EXACT = 1509       #   the exact filter's check, 300 programs of 40 quarters

# Chapter 7's declared model, unchanged ($ million, points of capability, quarters)
BETA, ALPHA, K, CAP, FLOOR, P_SHORT = 1.1 ** -0.25, 0.975, 4.0, 2.5, 55.0, 1.6
W = np.array([1.5, 0.75, 0.0, -0.75, -1.5])         # swings: points lost in a quarter
PW = np.array([0.05, 0.20, 0.50, 0.20, 0.05])        # their chances
Q = float((PW * W ** 2).sum())                       # a swing's variance, 0.45
C0, T7, CH7 = 58.0, 55.75, 230.755                   # the audited start; Chapter 7's target and its cost from 58 (WE 7.1)

# the twin, its readings and its monitor (new declarations, Chapter 15)
SD_SURVEY = 2.5                                      # the survey's error: 95% of readings within +/-5 points
HORIZON, LONG0 = 480, 40                             # quarters simulated; long-run shares over quarters 40-479
DISC = BETA ** np.arange(HORIZON)
N_DESIGN, N_FRESH = 20000, 100000
KAPPA, DRIFT_START, DRIFT = 0.5, 8, 0.5


def schedule(every, horizon=HORIZON):
    # survey quarters: the start of quarters every, 2 every, ... (none at the audited start)
    s = np.zeros(horizon, dtype=bool)
    if every:
        s[every::every] = True
    return s


def kalman_path(every, sd, horizon=HORIZON, p0=0.0):
    # the twin's error variance by quarter (Equation 15.1 in one dimension): prior a^2 P + q, gain P-/(P- + r) at a
    # survey, posterior (1 - K) P-; it does not depend on the readings
    sv, r = schedule(every, horizon), sd ** 2
    prior, post, gain = np.zeros(horizon), np.zeros(horizon), np.zeros(horizon)
    p = p0
    for t in range(horizon):
        pm = p if t == 0 else ALPHA ** 2 * p + Q
        k = (pm / (pm + r) if r > 0 else 1.0) if sv[t] else 0.0
        prior[t], gain[t] = pm, k
        p = (1 - k) * pm
        post[t] = p
    return prior, post, gain


def reset_path(every, sd, horizon=HORIZON):
    # the survey read as exact and carried forward by the hires and the decay: its error variance by quarter
    sv, v, p = schedule(every, horizon), np.zeros(horizon), 0.0
    for t in range(horizon):
        p = p if t == 0 else ALPHA ** 2 * p + Q
        if sv[t]:
            p = sd ** 2
        v[t] = p
    return v


def fixed_point(every, sd):
    # Theorem 15.1(iii): the one positive fixed point of the every-quarter map, the variance just after a survey
    r = sd ** 2
    x = r
    for _ in range(10000):
        pm = x
        for _ in range(every):
            pm = ALPHA ** 2 * pm + Q
        x2 = pm * r / (pm + r)
        if abs(x2 - x) < 1e-14:
            break
        x = x2
    return x


def stream(seed, n, horizon=HORIZON):
    # the engine's draws(n, seed): rng.random((horizon, n)) for the swings, then rng.standard_normal((horizon, n)) for the
    # survey errors. Generated a quarter at a time from two copies of the generator, the second advanced past the
    # uniforms: the same numbers, in a quarter's memory instead of a whole program's
    ru = np.random.default_rng(seed)
    rn = np.random.default_rng(seed)
    rn.bit_generator.advance(horizon * n)
    cum = np.cumsum(PW)
    for t in range(horizon):
        yield t, W[np.minimum(np.searchsorted(cum, ru.random(n), side="right"), len(W) - 1)], rn.standard_normal(n)


class Program:
    # Target rules run on common draws, one quarter at a time: the engine's simulate(), transcribed. est is 'exact' (the
    # engineering office's count), 'twin' (the Kalman filter), 'reset' (the survey read as exact) or 'none' (no readings
    # after the audit); one row of paths per target, on the first n paths of the draws. drift = (start, size): from that
    # quarter each quarter loses size points more. monitor = (kappa, threshold or one per row): on an alarm the audit sets
    # the estimate to the truth with variance 0, the sum restarts, and once the drift has begun the law's mean is
    # re-estimated as the drift. oracle: the twin (or the count) is told of the drift when it begins.
    def __init__(self, targets, est, every=0, sd=0.0, n=N_DESIGN, drift=None, monitor=None, oracle=False,
                 horizon=HORIZON, limits=False, keep=None, trace=0, sample=8):
        self.T = np.asarray(targets, dtype=float)[:, None]
        m = len(self.T)
        self.est, self.sd, self.r, self.n, self.drift, self.oracle = est, sd, sd ** 2, n, drift, oracle
        self.mon = None if monitor is None else (monitor[0], np.resize(np.asarray(monitor[1], float), m)[:, None])
        self.sv = schedule(every, horizon) if est in ("twin", "reset") else np.zeros(horizon, dtype=bool)
        self.c, self.ch = np.full((m, n), C0), np.full((m, n), C0)
        self.p = np.zeros((m, n)) if monitor is not None else 0.0          # without audits, the same on every path
        self.shift = np.zeros((m, n)) if (monitor is not None or oracle) else 0.0   # the extra loss the twin believes
        self.G = np.zeros((m, n)) if monitor is not None else None
        self.cost, self.below = np.zeros((m, n)), np.zeros((m, n))
        self.alarms, self.first = np.zeros((m, n), dtype=np.int32), np.full((m, n), -1, dtype=np.int32)
        self.limits, self.keep, self.trace, self.sample = limits, keep, trace, sample
        self.at0, self.atcap, self.breaks = np.zeros(m), np.zeros(m), np.zeros(m)
        self.kept, self.log, self.zrec, self.zprev = [], [], [], None

    def step(self, t, sw, eps):
        sw, eps = sw[:self.n], eps[:self.n]
        drift_now = self.drift is not None and t >= self.drift[0]
        z = None
        if self.sv[t]:
            z = self.c + self.sd * eps[None, :]                       # the survey's reading
            if self.est == "twin":
                pm = self.p
                k = pm / (pm + self.r)                               # the gain
                innov = z - self.ch                                  # the innovation
                if self.mon is not None:
                    zs = innov / np.sqrt(pm + self.r)                # standardized
                    self.G = np.maximum(0.0, self.G - zs - self.mon[0])
                    hit = self.G > self.mon[1]
                    self.zrec.append((t, zs[0, :self.sample].copy(), self.G[0, :self.sample].copy(), hit[0, :self.sample].copy()))
                    if hit.any():                                    # the audit
                        self.alarms += hit
                        self.first = np.where(hit & (self.first < 0) & (t >= (self.drift[0] if self.drift else 0)), t,
                                              self.first)
                        self.ch = np.where(hit, self.c, self.ch + k * innov)
                        self.p = np.where(hit, 0.0, (1 - k) * pm)
                        if drift_now:
                            self.shift = np.where(hit, self.drift[1], self.shift)
                        self.G = np.where(hit, 0.0, self.G)
                    else:
                        self.ch = self.ch + k * innov
                        self.p = (1 - k) * pm
                else:
                    if self.trace == "z":                    # sums of z, z^2 and z times the previous survey's z
                        zz = innov[0] / math.sqrt(pm + self.r)
                        self.zrec.append((t, float(zz.sum()), float((zz * zz).sum()),
                                          None if self.zprev is None else float((zz * self.zprev).sum()), len(zz)))
                        self.zprev = zz
                    self.ch = self.ch + k * innov
                    self.p = (1 - k) * pm
            elif self.est == "reset":
                self.ch = z
        if self.est == "exact":
            self.ch = self.c
        if self.oracle and drift_now:
            self.shift[:] = self.drift[1]
        # decide: bring planned capability, as estimated, to the target plus the extra loss the twin believes in
        h = np.clip(self.T + self.shift - ALPHA * self.ch, 0.0, CAP)
        self.cost += DISC[t] * (K * h + P_SHORT * np.maximum(FLOOR - self.c, 0.0))
        if t >= LONG0:
            self.below += self.c < FLOOR
        if self.limits:
            if t >= LONG0:
                self.at0 += (h == 0.0).sum(axis=1)
                self.atcap += (h == CAP).sum(axis=1)
            self.breaks += ((ALPHA * self.ch + h - self.shift < FLOOR - 1e-9) & (h < CAP)).sum(axis=1)
        if self.keep and t < self.keep[1]:
            self.kept.append(self.c[0, :self.keep[0]].mean())
        if self.trace and self.trace != "z":
            pp = self.p if np.isscalar(self.p) else self.p[0, :self.trace].copy()
            self.log.append(dict(c=self.c[0, :self.trace].copy(), ch=self.ch[0, :self.trace].copy(), p=pp,
                                 z=None if z is None else z[0, :self.trace].copy(), h=h[0, :self.trace].copy(),
                                 G=None if self.G is None else self.G[0, :self.trace].copy()))
        # move: the truth by the swings (and the drift), the twin by its law
        wt = sw[None, :] + (self.drift[1] if drift_now else 0.0)
        self.c = ALPHA * self.c + h - wt
        self.ch = ALPHA * self.ch + h - self.shift
        if self.est == "twin":
            self.p = ALPHA * ALPHA * self.p + Q

    def mean(self):
        return self.cost.mean(axis=1)

    def share_below(self):
        return (self.below / (HORIZON - LONG0)).mean(axis=1)


def run(programs, seed, n, horizon=HORIZON):
    # one pass over the book's draws for a seed (n paths, the engine's order); each program reads its first paths
    for t, sw, eps in stream(seed, n, horizon):
        for pr in programs:
            pr.step(t, sw, eps)
    return programs


print(f"beta = {BETA:.6f} a quarter (10 percent a year); a swing's variance q = {Q:.2f}, standard deviation "
      f"{math.sqrt(Q):.3f} points")
print(f"the survey's error variance r = {SD_SURVEY ** 2:.2f}; surveys at the start of quarters "
      f"{', '.join(str(int(x)) for x in np.nonzero(schedule(2, 12))[0])}, ...; quarterly: "
      f"{', '.join(str(int(x)) for x in np.nonzero(schedule(1, 6))[0])}, ...")
print(f"{HORIZON} quarters ({HORIZON // 4} years) of present value; long-run shares over quarters {LONG0}-{HORIZON - 1}; "
      f"{N_DESIGN:,} design paths and {N_FRESH:,} fresh paths")
beta = 0.976454 a quarter (10 percent a year); a swing's variance q = 0.45, standard deviation 0.671 points
the survey's error variance r = 6.25; surveys at the start of quarters 2, 4, 6, 8, 10, ...; quarterly: 1, 2, 3, 4, 5, ...
480 quarters (120 years) of present value; long-run shares over quarters 40-479; 20,000 design paths and 100,000 fresh paths

Panel 1 — Synchronize: the error the twin settles at (Theorem 15.1(iii)–(iv); Proposition 15.1; Worked Example 15.1, Step 2; Figure 15.1; Online Appendix Example 15.B.2: the twin's error 1.333 points just after a survey, 1.463 a quarter later and 1.576 just before the next, gain 0.284; a quarterly survey 1.169–1.323, gain 0.219; twice as sharp 0.888–1.261; both 0.791–1.022; the survey read as exact 2.500–2.528; no readings a limit of 3.019; the exact posterior's mean within 0.012 points of the twin's in all 5,700 surveys, mean difference 0.0013, its standard deviation within 0.011)

AXIOM Lab 2.15, step 1. The twin's error variance follows the filter's recursion, which does not involve the readings: it rises by the law between surveys, P−=a2P+qP^{-} = a^{2}P + q, and each survey lowers it to P−r/(P−+r)P^{-}r/(P^{-} + r) with the gain K=P−/(P−+r)K = P^{-}/(P^{-} + r). Theorem 15.1(iii): just after a survey it converges, from any start, to the one positive fixed point of the two-quarter map; part (iv): with no readings it tends to q/(1−a2)q/(1 - a^{2}). Proposition 15.1(i): the survey and the law's prediction combine by their precisions. Then a check that the best linear estimate is, here, as good as the best estimate: the exact posterior for the swings' discrete law, computed on a grid of 0.01 points from 40 to 72 with the mass split linearly between grid points, on 300 programs of 40 quarters run by the twin at its best target, 56.70 (seed 1509). Last, Figure 15.1: one program from the audited 58 (seed 1503), and the error by quarter for each design.

Python Code
def errors(every, sd):
    # just after a survey, a quarter later (twice a year), just before the next, and the steady gain
    fp = fixed_point(every, sd)
    before2 = ALPHA ** (2 * every) * fp + Q * sum(ALPHA ** (2 * j) for j in range(every))
    return dict(after=math.sqrt(fp), mid=math.sqrt(ALPHA ** 2 * fp + Q) if every == 2 else None,
                before=math.sqrt(before2), gain=before2 / (before2 + sd ** 2), fp=fp)

ERR = {"twin": errors(2, SD_SURVEY), "twin_quarterly": errors(1, SD_SURVEY), "twin_sharp": errors(2, SD_SURVEY / 2),
       "twin_quarterly_sharp": errors(1, SD_SURVEY / 2)}
ERR["reset"] = dict(after=SD_SURVEY, before=math.sqrt(ALPHA ** 2 * SD_SURVEY ** 2 + Q))
ERR["none"] = dict(limit=math.sqrt(Q / (1 - ALPHA ** 2)))
names = {"twin": "twin, survey twice a year", "twin_quarterly": "twin, quarterly survey", "twin_sharp":
         "twin, survey twice as sharp", "twin_quarterly_sharp": "twin, both", "reset": "survey read as exact"}
print("error of the estimate (sd, points)   just after  a quarter later  just before   gain")
for key, lab in names.items():
    e = ERR[key]
    mid = f"{e['mid']:15.3f}" if e.get("mid") else " " * 15
    gain = f"{e['gain']:7.3f}" if "gain" in e else ""
    print(f"  {lab:34s} {e['after']:10.3f} {mid} {e['before']:12.3f} {gain}")
print(f"  {'no readings after the audit':34s} tends to sqrt(q/(1 - a^2)) = {ERR['none']['limit']:.3f}")
_, post2, gain2 = kalman_path(2, SD_SURVEY)
_, post2b, _ = kalman_path(2, SD_SURVEY, p0=10.0)
CONVERGE = max(abs(post2[-2] - ERR["twin"]["fp"]), abs(post2b[-2] - ERR["twin"]["fp"]))
print("from the audit (variance 0), just after the surveys of quarters 2, 4, 6, 8, 12, 20: "
      + ", ".join(f"{math.sqrt(post2[q]):.3f}" for q in (2, 4, 6, 8, 12, 20))
      + f"; from a variance of 10 the same fixed point (gap {CONVERGE:.0e}); last gain {gain2[-2]:.4f}")
pm_ = ERR["twin"]["before"] ** 2
PRECISION = 1 / (1 / pm_ + 1 / SD_SURVEY ** 2)
print(f"Proposition 15.1(i): just before a survey the law says {pm_:.4f} (precision {1 / pm_:.4f}) and the survey "
      f"{SD_SURVEY ** 2:.2f} ({1 / SD_SURVEY ** 2:.4f}); precisions add: 1/({1 / pm_:.4f} + {1 / SD_SURVEY ** 2:.4f}) = "
      f"{PRECISION:.4f} = {ERR['twin']['after']:.3f}^2")
print(f"Theorem 15.1(iv): a twin that stopped reading after the audit settles at {ERR['none']['limit']:.2f} points; the "
      f"survey read as exact is good to {ERR['reset']['after']:.2f}-{ERR['reset']['before']:.2f}")


def exact_filter_check(target, n_paths=300, quarters=40, seed=SEED_EXACT, dx=0.01, lo=40.0, hi=72.0):
    # the exact posterior on a grid (Bayes' rule; Theorem 15.1(i)) against the Kalman filter, on the same programs
    rng = np.random.default_rng(seed)
    xs = np.arange(lo, hi + dx / 2, dx)
    nx, cum = len(xs), np.cumsum(PW)
    diffs, sdd = [], []
    for _ in range(n_paths):
        c, ch, p = C0, C0, 0.0
        post = np.zeros(nx)
        post[int(round((C0 - lo) / dx))] = 1.0
        for t in range(quarters):
            if t > 0 and t % 2 == 0:
                z = c + SD_SURVEY * rng.standard_normal()
                pm = p
                k = pm / (pm + SD_SURVEY ** 2)
                ch, p = ch + k * (z - ch), (1 - k) * pm
                post = post * np.exp(-0.5 * ((z - xs) / SD_SURVEY) ** 2)
                post /= post.sum()
                mu = float((post * xs).sum())
                diffs.append(ch - mu)
                sdd.append(math.sqrt(p) - float(np.sqrt((post * (xs - mu) ** 2).sum())))
            h = min(max(target - ALPHA * ch, 0.0), CAP)
            w = W[min(int(np.searchsorted(cum, rng.random(), side="right")), len(W) - 1)]
            c, ch, p = ALPHA * c + h - w, ALPHA * ch + h, ALPHA * ALPHA * p + Q
            new = np.zeros(nx)                       # predict the grid posterior: 0.975x + h, less each swing
            for wm, pw in zip(W, PW):
                pos = (np.clip(ALPHA * xs + h - wm, lo, hi) - lo) / dx
                j = np.minimum(np.floor(pos).astype(int), nx - 2)
                f = pos - j
                new += np.bincount(j, pw * post * (1 - f), nx) + np.bincount(j + 1, pw * post * f, nx)
            post = new
    d, s = np.abs(np.array(diffs)), np.array(sdd)
    return dict(max_abs=float(d.max()), mean_abs=float(d.mean()), sd_max=float(np.abs(s).max()), n=len(d))

t0 = time.time()
EXACT = exact_filter_check(56.70)
print(f"\nthe exact posterior against the Kalman filter, {EXACT['n']:,} survey updates on 300 programs (seed {SEED_EXACT}): "
      f"means within {EXACT['max_abs']:.4f} points (mean difference {EXACT['mean_abs']:.4f}); standard deviations within "
      f"{EXACT['sd_max']:.4f} ({time.time() - t0:.0f} s)")

# Figure 15.1: one program from the audited 58 (seed 1503) and the error by quarter
one = run([Program([56.70], "twin", 2, SD_SURVEY, n=1, horizon=25, trace=1)], SEED_PATH, 1, horizon=25)[0]
cpath = np.array([x["c"][0] for x in one.log])
twin_est = np.array([x["ch"][0] for x in one.log])
twin_sd = np.sqrt(np.array([x["p"] for x in one.log], dtype=float))
reads = [None if x["z"] is None else float(x["z"][0]) for x in one.log]
hires = np.clip(56.70 - ALPHA * twin_est, 0.0, CAP)
as_exact = np.zeros(25)
as_exact[0] = C0
for t in range(1, 25):                           # the survey read as exact, on the same readings and hires
    as_exact[t] = ALPHA * as_exact[t - 1] + hires[t - 1]
    if reads[t] is not None:
        as_exact[t] = reads[t]
print(f"Figure 15.1(a), the program of seed {SEED_PATH}: capability {cpath.min():.2f} to {cpath.max():.2f}; the twin's "
      f"largest error {np.abs(twin_est - cpath).max():.2f}, the survey read as exact {np.abs(as_exact - cpath).max():.2f}")
CURVES = dict(none=np.sqrt(kalman_path(0, SD_SURVEY)[1][:25]), reset2=np.sqrt(reset_path(2, SD_SURVEY)[:25]),
              twin2=np.sqrt(post2[:25]), twin1=np.sqrt(kalman_path(1, SD_SURVEY)[1][:25]),
              sharp2=np.sqrt(kalman_path(2, SD_SURVEY / 2)[1][:25]))

fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6))
q_ = np.arange(25)
ax.fill_between(q_, twin_est - 2 * twin_sd, twin_est + 2 * twin_sd, color="#1F4E79", alpha=0.15, lw=0)
ax.plot(q_, cpath, color="#333333", lw=1.3, label="capability")
ax.plot(q_, twin_est, color="#1F4E79", lw=1.3, label="twin (2 sd band)")
ax.plot(q_, as_exact, color="#E65100", lw=1.1, ls="--", label="survey as exact")
zt = [t for t in range(25) if reads[t] is not None]
ax.plot(zt, [reads[t] for t in zt], "o", ms=3.5, mfc="white", mec="#E65100", mew=1.0, label="survey reading")
ax.axhline(FLOOR, color="#999999", lw=0.8, ls=":")
ax.set(xlim=(0, 24), ylim=(40, 63), xticks=[0, 4, 8, 12, 16, 20, 24], xlabel="quarter", ylabel="capability (points)")
ax.set_title("(a) one program from an audited 58", fontsize=9)
ax.legend(frameon=False, fontsize=7.5, loc="lower left")
for key, col, ls, lab in (("none", "#999999", ":", "no readings"), ("reset2", "#E65100", "--", "survey as exact"),
                          ("twin2", "#1F4E79", "-", "twin, twice a year"), ("twin1", "#2E7D32", "-.", "twin, quarterly"),
                          ("sharp2", "#6A1B9A", (0, (2, 1)), "twin, sharper survey")):
    bx.step(q_, CURVES[key], where="post", color=col, ls=ls, lw=1.3, label=lab)
bx.set(xlim=(0, 24), ylim=(0, 5), xticks=[0, 4, 8, 12, 16, 20, 24], xlabel="quarter", ylabel="error of the estimate (sd, points)")
bx.set_title("(b) the estimate's error by quarter", fontsize=9)
bx.legend(frameon=False, fontsize=7.5, loc="upper right")
fig.suptitle("The twin settles at 1.33 to 1.58 points (book seed 1503)", fontsize=10.5)
plt.tight_layout(); plt.show()
error of the estimate (sd, points)   just after  a quarter later  just before   gain
  twin, survey twice a year               1.333           1.463        1.576   0.284
  twin, quarterly survey                  1.169                        1.323   0.219
  twin, survey twice as sharp             0.888           1.095        1.261   0.504
  twin, both                              0.791                        1.022   0.401
  survey read as exact                    2.500                        2.528
  no readings after the audit        tends to sqrt(q/(1 - a^2)) = 3.019
from the audit (variance 0), just after the surveys of quarters 2, 4, 6, 8, 12, 20: 0.877, 1.121, 1.234, 1.287, 1.323, 1.333; from a variance of 10 the same fixed point (gap 1e-14); last gain 0.2844
Proposition 15.1(i): just before a survey the law says 2.4842 (precision 0.4025) and the survey 6.25 (0.1600); precisions add: 1/(0.4025 + 0.1600) = 1.7776 = 1.333^2
Theorem 15.1(iv): a twin that stopped reading after the audit settles at 3.02 points; the survey read as exact is good to 2.50-2.53

the exact posterior against the Kalman filter, 5,700 survey updates on 300 programs (seed 1509): means within 0.0119 points (mean difference 0.0013); standard deviations within 0.0111 (4 s)
Figure 15.1(a), the program of seed 1503: capability 53.48 to 58.55; the twin's largest error 3.22, the survey read as exact 7.27
The twin settles at 1.33 to 1.58 points (book seed 1503)

Panel 2 — Decide on the twin: a margin sized to its error (Theorem 15.2(iii); Proposition 15.2; Worked Example 15.1, Step 3; Table 15.3; Figure 15.2(a); Online Appendix Example 15.B.2: best targets 55.75 on the count, 56.70 on the twin, 57.35 on the survey read as exact, 57.80 with no readings; from 58 on the fresh paths $230.844m on the count (standard error 0.040), $241.944m on the twin (0.042), $11.101m more, the survey read as exact $15.950m more, no readings $25.433m more (0.063); Chapter 7's target on the twin $16.313m more and 31.3% of quarters below the floor, on the survey read as exact $27.509m and 38.6%, a target of 60.75 $34.396m and 0.2%; on the design paths 241.852 and 230.747)

AXIOM Lab 2.15, step 2. Each design runs Chapter 7's target rule on its estimate. The book searched every target on a grid of 0.05 from 55 to 61 (to 62 with no readings) on the 20,000 design paths (seed 1500) and kept the least; here each design searches seven targets, 0.15 either side of the book's best, on the same paths, which reproduces the book's design-path costs exactly and confirms the best target locally (it lies inside the window, not at its edge). For the count, the twin, the survey read as exact and no readings, a coarser grid of 0.25 across the whole range draws Figure 15.2(a) and shows that the window holds the least cost. Each best target is then valued on the 100,000 fresh paths (seed 1501), with Chapter 7's 55.75 on the twin and on the survey read as exact, and 60.75, the survey's whole error guarded, on the survey. Theorem 15.2(iii) explains the margins, and Proposition 15.2 why the choice is made on design paths and valued on fresh ones, all on common random numbers. The cell takes about forty seconds.

Python Code
DESIGNS = [("exact", "exact", 0, 0.0), ("twin", "twin", 2, SD_SURVEY), ("reset", "reset", 2, SD_SURVEY),
           ("twin_quarterly", "twin", 1, SD_SURVEY), ("twin_sharp", "twin", 2, SD_SURVEY / 2),
           ("twin_quarterly_sharp", "twin", 1, SD_SURVEY / 2), ("none", "none", 0, 0.0)]
LABEL = {"exact": "count (Chapter 7)", "twin": "twin, survey twice a year", "reset": "survey read as exact",
         "twin_quarterly": "twin, quarterly survey", "twin_sharp": "twin, twice as sharp", "twin_quarterly_sharp":
         "twin, both", "none": "no readings after the audit"}
CENTRE = {"exact": 55.75, "twin": 56.70, "reset": 57.35, "twin_quarterly": 56.50, "twin_sharp": 56.40,
          "twin_quarterly_sharp": 56.20, "none": 57.80}           # the book's best targets: the windows' centres
CURVED = ("exact", "twin", "reset", "none")                         # drawn across the whole range in Figure 15.2(a)
t0 = time.time()
DES = {}
for key, est, every, sd in DESIGNS:
    win = np.round(CENTRE[key] + 0.05 * np.arange(-3, 4), 2)
    grid = np.round(np.arange(55.0, (62.0 if key == "none" else 61.0) + 1e-9, 0.25), 2) if key in CURVED else np.array([])
    tg = np.unique(np.concatenate([win, grid]))
    DES[key] = dict(est=est, every=every, sd=sd, targets=tg, window=win,
                    prog=Program(tg, est, every, sd, n=N_DESIGN))
run([d["prog"] for d in DES.values()], SEED_DESIGN, N_DESIGN)
for key, d in DES.items():
    mean = d["prog"].mean()
    iw = np.isin(d["targets"], d["window"])
    jw = int(np.argmin(np.where(iw, mean, np.inf)))
    d.update(mean=mean, best=float(d["targets"][jw]), design=float(mean[jw]),
             interior=bool(d["window"][0] < d["targets"][jw] < d["window"][-1]),
             grid_in_window=bool(d["targets"][int(np.argmin(mean))] in d["window"]) if key in CURVED else None,
             costs=d["prog"].cost[jw].copy())
print(f"design paths, {N_DESIGN:,} (seed {SEED_DESIGN}): {time.time() - t0:.0f} s")
print("design                         window searched      best   margin  design-path cost  inside the window")
for key, d in DES.items():
    print(f"  {LABEL[key]:30s} {d['window'][0]:.2f} to {d['window'][-1]:.2f}  {d['best']:8.2f} {d['best'] - FLOOR:7.2f} "
          f"{d['design']:15.3f}   {d['interior']}" + ("" if d["grid_in_window"] is None else
                                                    f"; the 0.25 grid's least cost is in it: {d['grid_in_window']}"))

# valued on the fresh paths, with the board's fixed targets
t0 = time.time()
FR = {key: Program([d["best"]] + ([T7] if key == "twin" else [T7, T7 + 5.0] if key == "reset" else []), d["est"],
                   d["every"], d["sd"], n=N_FRESH, limits=True) for key, d in DES.items()}
run(list(FR.values()), SEED_FRESH, N_FRESH)
COUNT = float(FR["exact"].mean()[0])
for key, pr in FR.items():
    d = DES[key]
    d.update(cost=float(pr.mean()[0]), se=float(pr.cost[0].std() / math.sqrt(N_FRESH)), below=float(pr.share_below()[0]),
             at0=pr.at0[0] / (N_FRESH * (HORIZON - LONG0)), atcap=pr.atcap[0] / (N_FRESH * (HORIZON - LONG0)),
             breaks=int(pr.breaks.sum()))
    d["excess"] = d["cost"] - COUNT
FIXED = {}
for name, key, row in (("twin at Chapter 7's 55.75", "twin", 1), ("survey as exact at Chapter 7's 55.75", "reset", 1),
                       ("survey as exact at 60.75, the whole error guarded", "reset", 2)):
    pr = FR[key]
    FIXED[name] = dict(target=float(pr.T[row, 0]), cost=float(pr.mean()[row]), below=float(pr.share_below()[row]),
                       excess=float(pr.mean()[row]) - COUNT)
print(f"\nfresh paths, {N_FRESH:,} (seed {SEED_FRESH}): {time.time() - t0:.0f} s")
print("design                         target   cost from 58 (se)   above the count   below floor   decisions at 0 / at the cap")
for key, d in DES.items():
    print(f"  {LABEL[key]:30s} {d['best']:6.2f} {d['cost']:10.3f} ({d['se']:.3f}) {d['excess']:13.3f} {100 * d['below']:12.1f}% "
          f"{100 * d['at0']:13.1f}% / {100 * d['atcap']:.1f}%")
print("the board's fixed targets                          target   cost from 58   above the count   below floor")
for name, f in FIXED.items():
    print(f"  {name:50s} {f['target']:6.2f} {f['cost']:12.3f} {f['excess']:15.3f} {100 * f['below']:12.1f}%")
print(f"the twin costs {DES['twin']['excess']:.2f} more than the count and {DES['reset']['excess'] - DES['twin']['excess']:.2f} "
      f"less than the survey read as exact (the abstract's $4.8m); the count is worth "
      f"{4 * (1 - BETA) * DES['twin']['excess']:.3f} a year against the twin (Panel 3)")

# Theorem 15.2(iii): the margin is the (1 - k/b)-quantile of the swing less the twin's error
k_hold, b_short = K * (1 - ALPHA * BETA), P_SHORT * BETA
RATIO = k_hold / b_short
Z = float(norm.ppf(1 - RATIO))
cdf = np.cumsum(PW[::-1])[::-1]                       # P(w >= w_j), swings from the largest loss
QUANT = float(W[::-1][np.argmax(np.cumsum(PW[::-1]) >= 1 - RATIO)])
print(f"\nTheorem 15.2(iii): holding a planned point costs k = 4(1 - 0.975 beta) = {k_hold:.5f} a quarter; a point short next "
      f"quarter b = 1.6 beta = {b_short:.4f}; critical ratio k/b = {RATIO:.4f}")
print(f"  on the count the margin is the swing's {1 - RATIO:.4f}-quantile: {QUANT:.2f} (P(w > 0.75) = 0.05 <= {RATIO:.4f} <= "
      f"P(w >= 0.75) = 0.25), Chapter 7's margin")
print(f"  with normal swings and errors, z = {Z:.4f} and the margin z sqrt(q + (0.975 s)^2): the twin's planned level is off "
      f"by 0.975 times its error s, so the margin is z times the error a quarter later")
MARGINS = {}
for key, s_list in (("exact", [0.0]), ("twin", [ERR["twin"]["after"], ERR["twin"]["mid"]]),
                    ("twin_quarterly", [ERR["twin_quarterly"]["after"]]),
                    ("twin_sharp", [ERR["twin_sharp"]["after"], math.sqrt(ALPHA ** 2 * ERR["twin_sharp"]["fp"] + Q)]),
                    ("twin_quarterly_sharp", [ERR["twin_quarterly_sharp"]["after"]]),
                    ("reset", [ERR["reset"]["after"], ERR["reset"]["before"]]), ("none", [ERR["none"]["limit"]])):
    MARGINS[key] = [Z * math.sqrt(Q + (ALPHA * s) ** 2) for s in s_list]
    lim = DES[key]["at0"] + DES[key]["atcap"]
    print(f"  {LABEL[key]:30s} normal margin {' to '.join(f'{x:.2f}' for x in MARGINS[key]):12s} simulated best "
          f"{DES[key]['best'] - FLOOR:.2f}; a hiring limit binds in {100 * lim:4.1f}% of quarters")
print("  the formula holds one quarter at a time; it sizes the count's and the twins' margins, where the limits seldom bind,")
print("  but not the survey read as exact, whose readings swing hires to 0 or to the cap in over half the quarters, nor no")
print("  readings, whose error grows from 0 after the audit")

# Proposition 15.2: choose on design paths, value on fresh ones; common random numbers
print(f"\nProposition 15.2(i): the twin's best target costs {DES['twin']['design']:.3f} on the design paths where it was chosen "
      f"and {DES['twin']['cost']:.3f} on fresh paths; the count {DES['exact']['design']:.3f} and {DES['exact']['cost']:.3f}")
indep = run([Program([56.75], "twin", 2, SD_SURVEY, n=N_DESIGN)], SEED, N_DESIGN)[0]
tw = DES["twin"]
j75 = int(np.nonzero(tw["targets"] == 56.75)[0][0])
common = tw["prog"].cost[j75] - tw["costs"]
indiff = indep.cost[0] - tw["costs"]
CRN = dict(diff=float(common.mean()), sd_common=float(common.std()), sd_indep=float(indiff.std()))
print(f"Proposition 15.2(ii): 56.75 against 56.70 on the twin, path by path: on the common design paths the difference has "
      f"mean {CRN['diff']:.4f} and standard deviation {CRN['sd_common']:.3f}; against new independent paths (the lab's seed "
      f"{SEED}) {CRN['sd_indep']:.3f}: common numbers need {(CRN['sd_indep'] / CRN['sd_common']) ** 2:,.0f} times fewer paths "
      f"to tell the targets apart")
design paths, 20,000 (seed 1500): 26 s
design                         window searched      best   margin  design-path cost  inside the window
  count (Chapter 7)              55.60 to 55.90     55.75    0.75         230.747   True; the 0.25 grid's least cost is in it: True
  twin, survey twice a year      56.55 to 56.85     56.70    1.70         241.852   True; the 0.25 grid's least cost is in it: True
  survey read as exact           57.20 to 57.50     57.35    2.35         246.696   True; the 0.25 grid's least cost is in it: True
  twin, quarterly survey         56.35 to 56.65     56.50    1.50         239.371   True
  twin, twice as sharp           56.25 to 56.55     56.40    1.40         237.761   True
  twin, both                     56.05 to 56.35     56.20    1.20         235.668   True
  no readings after the audit    57.65 to 57.95     57.80    2.80         256.145   True; the 0.25 grid's least cost is in it: True

fresh paths, 100,000 (seed 1501): 12 s
design                         target   cost from 58 (se)   above the count   below floor   decisions at 0 / at the cap
  count (Chapter 7)               55.75    230.844 (0.040)         0.000          6.0%           4.7% / 5.1%
  twin, survey twice a year       56.70    241.944 (0.042)        11.101         13.4%           2.1% / 4.9%
  survey read as exact            57.35    246.793 (0.041)        15.950         13.3%          22.5% / 33.2%
  twin, quarterly survey          56.50    239.478 (0.040)         8.634         13.0%           1.0% / 3.8%
  twin, twice as sharp            56.40    237.849 (0.040)         7.005         12.1%           2.7% / 5.6%
  twin, both                      56.20    235.765 (0.040)         4.921         12.2%           1.3% / 4.4%
  no readings after the audit     57.80    256.277 (0.063)        25.433         17.6%           0.0% / 0.0%
the board's fixed targets                          target   cost from 58   above the count   below floor
  twin at Chapter 7's 55.75                           55.75      247.157          16.313         31.3%
  survey as exact at Chapter 7's 55.75                55.75      258.352          27.509         38.6%
  survey as exact at 60.75, the whole error guarded   60.75      265.240          34.396          0.2%
the twin costs 11.10 more than the count and 4.85 less than the survey read as exact (the abstract's $4.8m); the count is worth 1.045 a year against the twin (Panel 3)

Theorem 15.2(iii): holding a planned point costs k = 4(1 - 0.975 beta) = 0.19183 a quarter; a point short next quarter b = 1.6 beta = 1.5623; critical ratio k/b = 0.1228
  on the count the margin is the swing's 0.8772-quantile: 0.75 (P(w > 0.75) = 0.05 <= 0.1228 <= P(w >= 0.75) = 0.25), Chapter 7's margin
  with normal swings and errors, z = 1.1612 and the margin z sqrt(q + (0.975 s)^2): the twin's planned level is off by 0.975 times its error s, so the margin is z times the error a quarter later
  count (Chapter 7)              normal margin 0.78         simulated best 0.75; a hiring limit binds in  9.8% of quarters
  twin, survey twice a year      normal margin 1.70 to 1.83 simulated best 1.70; a hiring limit binds in  7.0% of quarters
  twin, quarterly survey         normal margin 1.54         simulated best 1.50; a hiring limit binds in  4.7% of quarters
  twin, twice as sharp           normal margin 1.27 to 1.46 simulated best 1.40; a hiring limit binds in  8.3% of quarters
  twin, both                     normal margin 1.19         simulated best 1.20; a hiring limit binds in  5.7% of quarters
  survey read as exact           normal margin 2.94 to 2.97 simulated best 2.35; a hiring limit binds in 55.7% of quarters
  no readings after the audit    normal margin 3.51         simulated best 2.80; a hiring limit binds in  0.0% of quarters
  the formula holds one quarter at a time; it sizes the count's and the twins' margins, where the limits seldom bind,
  but not the survey read as exact, whose readings swing hires to 0 or to the cap in over half the quarters, nor no
  readings, whose error grows from 0 after the audit

Proposition 15.2(i): the twin's best target costs 241.852 on the design paths where it was chosen and 241.944 on fresh paths; the count 230.747 and 230.844
Proposition 15.2(ii): 56.75 against 56.70 on the twin, path by path: on the common design paths the difference has mean 0.0103 and standard deviation 0.268; against new independent paths (the lab's seed 26215) 18.507: common numbers need 4,758 times fewer paths to tell the targets apart

Panel 3 — Price readings (Theorem 15.2(i); Worked Example 15.1, Step 4; Figure 15.2(b); Table 15.3; Online Appendix Example 15.B.2: a quarterly survey $8.634m above the count, one twice as sharp $7.005m, both $4.921m; the count worth about $1.0m a year against the twin, a quarterly survey up to $0.23m, a sharper one $0.39m and both $0.58m; the readings study, twice a year and quarterly, by the survey's error 0.5 to 5: best targets 56.10 to 57.10 and 55.90 to 56.90, costs above the count $3.90m to $16.12m and $2.01m to $13.47m)

AXIOM Lab 2.15, step 3. Theorem 15.2(i): a rule on the true state costs no more than a rule on the twin's readings, which costs no more than one on coarser readings or none, and each gap is the value of the information it adds. Panel 2's fresh paths price the better surveys; a present value VV is worth 4(1−β)V4(1 - \beta)V a year, forever. The readings study varies the survey's error, twice a year and quarterly, on the first 10,000 design paths and the first 40,000 fresh paths, as the book did (Online Appendix Remark 15.B.1): the book searched targets from 55.5 to 59.5, and each of the eighteen cases here searches seven targets around the book's best. The cell takes about twenty seconds.

Python Code
YEAR = 4 * (1 - BETA)                                  # a present value's yearly equivalent, forever
VALUE = {"count against the twin": DES["twin"]["excess"] * YEAR}
for key, lab in (("twin_quarterly", "a quarterly survey"), ("twin_sharp", "a survey twice as sharp"),
                 ("twin_quarterly_sharp", "both")):
    VALUE[lab] = (DES["twin"]["excess"] - DES[key]["excess"]) * YEAR
print("Theorem 15.2(i), from the cheapest knowledge to the dearest (cost from 58 on the fresh paths):")
for key in ("exact", "twin_quarterly_sharp", "twin_sharp", "twin_quarterly", "twin", "reset", "none"):
    print(f"  {LABEL[key]:30s} {DES[key]['cost']:9.3f}   above the count {DES[key]['excess']:7.3f}")
print("worth a year, forever (present value x 4(1 - beta) = x %.5f):" % YEAR)
for lab, v in VALUE.items():
    print(f"  {lab:24s} {v:.3f}")

READ_CENTRE = {2: (56.10, 56.30, 56.40, 56.45, 56.60, 56.70, 56.80, 57.00, 57.10),
               1: (55.90, 56.10, 56.20, 56.25, 56.40, 56.50, 56.60, 56.75, 56.90)}   # the book's best targets
SDS = (0.5, 1.0, 1.25, 1.5, 2.0, 2.5, 3.0, 4.0, 5.0)
t0 = time.time()
CASES = []
for every in (2, 1):
    for sd, ctr in zip(SDS, READ_CENTRE[every]):
        win = np.round(ctr + 0.05 * np.arange(-3, 4), 2)
        CASES.append(dict(every=every, sd=sd, window=win, prog=Program(win, "twin", every, sd, n=10000)))
run([c_["prog"] for c_ in CASES], SEED_DESIGN, N_DESIGN)
for c_ in CASES:
    mean = c_["prog"].mean()
    j = int(np.argmin(mean))
    c_.update(best=float(c_["window"][j]), interior=bool(0 < j < len(mean) - 1))
fresh = [Program([c_["best"]], "twin", c_["every"], c_["sd"], n=40000) for c_ in CASES]
count40 = Program([T7], "exact", n=40000)
run(fresh + [count40], SEED_FRESH, N_FRESH)
COUNT40 = float(count40.mean()[0])
for c_, pr in zip(CASES, fresh):
    c_["excess"] = float(pr.mean()[0]) - COUNT40
print(f"\nthe readings study: first 10,000 design paths and first 40,000 fresh paths (seeds {SEED_DESIGN}, {SEED_FRESH}); "
      f"the count costs {COUNT40:.3f} on these fresh paths ({time.time() - t0:.0f} s)")
print("survey error (sd)     " + "".join(f"{sd:8.2f}" for sd in SDS))
for every, lab in ((2, "twice a year"), (1, "quarterly")):
    rows = [c_ for c_ in CASES if c_["every"] == every]
    print(f"  {lab:12s} target " + "".join(f"{c_['best']:8.2f}" for c_ in rows))
    print(f"  {'':12s} above  " + "".join(f"{c_['excess']:8.2f}" for c_ in rows))
print(f"every best target inside its window: {all(c_['interior'] for c_ in CASES)}")

fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6))
for key, col, ls, lab in (("exact", "#333333", "-", "count (exact)"), ("twin", "#1F4E79", "-", "twin"),
                          ("reset", "#E65100", "--", "survey read as exact"), ("none", "#999999", ":", "no readings")):
    d = DES[key]
    ax.plot(d["targets"], d["mean"], color=col, ls=ls, lw=1.4, label=lab)
    ax.plot([d["best"]], [d["design"]], "o", color=col, ms=4.5, zorder=5)
ax.set(xlim=(55, 61), ylim=(225, 315), xlabel="target for planned capability (points)", ylabel="cost from 58 ($ million)")
ax.set_title("(a) design paths: cost against the target", fontsize=9)
ax.legend(frameon=False, fontsize=7.5, loc="upper right")
for every, col, ls, lab in ((2, "#1F4E79", "-", "survey twice a year"), (1, "#2E7D32", "-.", "quarterly survey")):
    rows = [c_ for c_ in CASES if c_["every"] == every]
    bx.plot(SDS, [c_["excess"] for c_ in rows], color=col, ls=ls, lw=1.4, marker="o", ms=3.5, label=lab)
today = [c_ for c_ in CASES if c_["every"] == 2 and c_["sd"] == 2.5][0]
bx.annotate("today's survey", xy=(2.5, today["excess"]), xytext=(2.9, today["excess"] - 4.0), fontsize=8, color="#1F4E79",
            arrowprops=dict(arrowstyle="-", lw=0.6, color="#1F4E79"))
bx.set(xlim=(0, 5.2), ylim=(0, 22), xlabel="survey error (sd, points)", ylabel="cost above the count's ($ million)")
bx.set_title("(b) what better readings are worth", fontsize=9)
bx.legend(frameon=False, fontsize=7.5, loc="upper left")
fig.suptitle("The twin needs a 1.70-point margin and costs \\$11.1m more (book seeds 1500 and 1501)", fontsize=10.5)
plt.tight_layout(); plt.show()
Theorem 15.2(i), from the cheapest knowledge to the dearest (cost from 58 on the fresh paths):
  count (Chapter 7)                230.844   above the count   0.000
  twin, both                       235.765   above the count   4.921
  twin, twice as sharp             237.849   above the count   7.005
  twin, quarterly survey           239.478   above the count   8.634
  twin, survey twice a year        241.944   above the count  11.101
  survey read as exact             246.793   above the count  15.950
  no readings after the audit      256.277   above the count  25.433
worth a year, forever (present value x 4(1 - beta) = x 0.09418):
  count against the twin   1.045
  a quarterly survey       0.232
  a survey twice as sharp  0.386
  both                     0.582

the readings study: first 10,000 design paths and first 40,000 fresh paths (seeds 1500, 1501); the count costs 230.838 on these fresh paths (16 s)
survey error (sd)         0.50    1.00    1.25    1.50    2.00    2.50    3.00    4.00    5.00
  twice a year target    56.10   56.30   56.40   56.45   56.60   56.70   56.80   57.00   57.10
               above      3.90    6.00    7.01    7.94    9.63   11.10   12.38   14.47   16.12
  quarterly    target    55.90   56.10   56.20   56.25   56.40   56.50   56.60   56.75   56.90
               above      2.01    4.00    4.92    5.78    7.30    8.63    9.81   11.83   13.47
every best target inside its window: True
The twin needs a 1.70-point margin and costs $11.1m more (book seeds 1500 and 1501)

Panel 4 — Monitor the law (Theorem 15.3; Worked Example 15.1, Step 5; Figure 15.3; Table 15.3; Online Appendix Example 15.B.2: unmonitored under the drift the twin's bias settles at 2.210 points just after a survey and 3.088 just before the next, its innovations' mean at −1.045-1.045 standard deviations; false alarms a survey, by threshold, 0.0471, 0.0347, 0.0258, 0.0192, 0.0145 and 0.0084, one in 10.6 to 59.8 years, the threshold 2.25; under the drift the count $301.992m and 14.1% of quarters below the floor, the twin that never questions its law $358.465m and 79.9%, with the monitor $320.169m and 14.4%, told of the drift $312.285m and 14.6%; detection on every path, after 12 quarters in the median, 4 to 22 from the 10th to the 90th percentile, 12.3 on average; without a drift $241.638m monitored against $241.837m, 4.6 audits in 120 years)

AXIOM Lab 2.15, step 4. Theorem 15.3(i): a correct twin's innovations have mean zero, are uncorrelated, and have the variances the filter computes; when the law's mean shifts by dd, a twin that keeps its law acquires a bias that settles, just after a survey, at b+=(1−K)d(1+a)/(1−(1−K)a2)b^{+} = (1 - K)d(1 + a)/(1 - (1 - K)a^{2}) (two quarters between surveys), and a2b++d(1+a)a^{2}b^{+} + d(1 + a) just before the next, which is the innovations' mean with its sign reversed. Part (ii): the cumulative sum Gk=max⁡{0,Gk−1−zk−κ}G_k = \max\{0, G_{k-1} - z_k - \kappa\} with κ=δ/2\kappa = \delta/2 and H=ln⁡γ/δH = \ln\gamma/\delta detects a shift of δ\delta standard deviations as fast as any test with as few false alarms. The threshold is calibrated on 20,000 paths without a drift (seed 1505), for the six thresholds the book prints; the drift, the count, and the twin unmonitored, monitored and told of the drift run on 100,000 paths (seed 1507). The cell takes about ten seconds.

Python Code
Kss = ERR["twin"]["gain"]
B_AFTER = (1 - Kss) * DRIFT * (1 + ALPHA) / (1 - (1 - Kss) * ALPHA ** 2)
B_BEFORE = ALPHA ** 2 * B_AFTER + DRIFT * (1 + ALPHA)
INNOV = -B_BEFORE / math.sqrt(ERR["twin"]["before"] ** 2 + SD_SURVEY ** 2)
m_, _, gains = 0.0, None, kalman_path(2, SD_SURVEY)[2]
track = []
for t in range(HORIZON):                               # the mean error quarter by quarter, the gains as they come
    m_ *= 1 - gains[t]
    track.append(m_)
    m_ = ALPHA * m_ + (DRIFT if t >= DRIFT_START else 0.0)
print(f"Theorem 15.3(i): the twin that keeps its law under the drift overestimates capability by b+ = {B_AFTER:.3f} just "
      f"after a survey and {B_BEFORE:.3f} just before the next (steady gain {Kss:.4f}); its innovations' mean is "
      f"{INNOV:.3f} standard deviations; the recursion from quarter 8 reaches {track[40]:.3f} at quarter 40 and "
      f"{track[200]:.3f} at quarter 200")

THRESH = [1.5, 1.75, 2.0, 2.25, 2.5, 3.0]
t0 = time.time()
TT = DES["twin"]["best"]
cal = run([Program([TT] * len(THRESH), "twin", 2, SD_SURVEY, n=N_DESIGN, monitor=(KAPPA, THRESH))], SEED_CAL, N_DESIGN)[0]
RATE = cal.alarms.sum(axis=1) / (N_DESIGN * (HORIZON // 2))
H_STAR = THRESH[int(np.argmax(RATE <= 1 / 50))]
print(f"\nthe monitor's calibration, {N_DESIGN:,} paths without a drift (seed {SEED_CAL}), {time.time() - t0:.0f} s:")
print("  threshold                " + "".join(f"{h:8.2f}" for h in THRESH))
print("  false alarms a survey    " + "".join(f"{x:8.4f}" for x in RATE))
print("  one in so many years     " + "".join(f"{1 / x / 2:8.1f}" for x in RATE))
print(f"  the least threshold with at most one false alarm in 50 surveys: {H_STAR}; one in {1 / RATE[THRESH.index(H_STAR)] / 2:.1f} "
      f"years")
GAMMA = math.exp(H_STAR * 1.0)
print(f"Theorem 15.3(ii) with delta = 2 kappa = 1: H = ln(gamma)/delta guarantees at least gamma = e^{H_STAR} = {GAMMA:.1f} "
      f"surveys between false alarms (here {1 / RATE[THRESH.index(H_STAR)]:.0f}), and a delay of about 2 ln(gamma)/delta^2 = "
      f"{2 * math.log(GAMMA):.1f} surveys once the innovations have shifted by a standard deviation")

t0 = time.time()
dr = (DRIFT_START, DRIFT)
DRUNS = dict(count=Program([T7], "exact", n=N_FRESH, drift=dr, oracle=True),
             static=Program([TT], "twin", 2, SD_SURVEY, n=N_FRESH, drift=dr, keep=(2000, 40), trace="z"),
             monitored=Program([TT], "twin", 2, SD_SURVEY, n=N_FRESH, drift=dr, monitor=(KAPPA, H_STAR), keep=(2000, 40)),
             oracle=Program([TT], "twin", 2, SD_SURVEY, n=N_FRESH, drift=dr, oracle=True, keep=(2000, 40)),
             monitored_nd=Program([TT], "twin", 2, SD_SURVEY, n=N_FRESH, monitor=(KAPPA, H_STAR)),
             twin_nd=Program([TT], "twin", 2, SD_SURVEY, n=N_FRESH, trace="z"))
run(list(DRUNS.values()), SEED_DRIFT, N_FRESH)
DR = {k: dict(cost=float(v.mean()[0]), below=float(v.share_below()[0])) for k, v in DRUNS.items()}
fa = DRUNS["monitored"].first[0]
detected = fa >= DRIFT_START
DELAY = (fa[detected] - DRIFT_START).astype(float)
DLY = dict(detected=float(detected.mean()), median=float(np.median(DELAY)), q10=float(np.quantile(DELAY, 0.1)),
           q90=float(np.quantile(DELAY, 0.9)), mean=float(DELAY.mean()))
AUDITS = float(DRUNS["monitored_nd"].alarms.mean())
print(f"\nthe drift from quarter {DRIFT_START}, {N_FRESH:,} paths (seed {SEED_DRIFT}), {time.time() - t0:.0f} s:")
print("                                      cost from 58   above the count   below floor")
for key, lab in (("count", "count, law re-estimated at once"), ("static", "twin, law never questioned"),
                 ("monitored", "twin with the monitor"), ("oracle", "twin told of the drift")):
    print(f"  {lab:34s} {DR[key]['cost']:12.3f} {DR[key]['cost'] - DR['count']['cost']:15.3f} {100 * DR[key]['below']:12.1f}%")
print(f"the monitor detects the drift on {100 * DLY['detected']:.1f}% of paths, after {DLY['median']:.0f} quarters in the "
      f"median ({DLY['q10']:.0f} to {DLY['q90']:.0f} from the 10th to the 90th percentile, {DLY['mean']:.1f} on average)")
print(f"without a drift the monitored twin costs {DR['monitored_nd']['cost']:.3f} against {DR['twin_nd']['cost']:.3f} unmonitored "
      f"and audits {AUDITS:.1f} times in {HORIZON // 4} years")

# Theorem 15.3(i) on the simulated innovations: the correct twin's are white; under the drift they lean one way
zn, zd = DRUNS["twin_nd"].zrec, [x for x in DRUNS["static"].zrec if x[0] >= 40]
n_ = sum(x[4] for x in zn)
m_ = sum(x[1] for x in zn) / n_
WHITE = dict(mean=m_, sd=math.sqrt(sum(x[2] for x in zn) / n_ - m_ ** 2),
             lag1=sum(x[3] for x in zn[1:]) / sum(x[4] for x in zn[1:]), drift_mean=sum(x[1] for x in zd) / sum(x[4] for x in zd))
print(f"the correct twin's standardized innovations over {len(zn)} surveys x {zn[0][4]:,} paths: mean {WHITE['mean']:.4f}, "
      f"sd {WHITE['sd']:.4f}, correlation with the previous survey's {WHITE['lag1']:.4f}; the twin that keeps its law "
      f"under the drift, from quarter 40 on: mean {WHITE['drift_mean']:.4f} (the formula: {INNOV:.4f})")

fa_n = DRUNS["monitored_nd"].first[0]
DETECT = [float(np.mean((fa >= 0) & (fa <= t))) for t in range(41)]
FALSE = [float(np.mean((fa_n >= 0) & (fa_n <= t))) for t in range(41)]
print(f"within 40 quarters {100 * FALSE[40]:.1f}% of monitors raise a false alarm without a drift")
fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6))
q_ = np.arange(41)
ax.step(q_, 100 * np.array(DETECT), where="post", color="#E65100", lw=1.6, label=f"drift from quarter {DRIFT_START}")
ax.step(q_, 100 * np.array(FALSE), where="post", color="#1F4E79", lw=1.4, ls="--", label="no drift")
ax.axvline(DRIFT_START, ymax=0.78, color="#999999", lw=0.8, ls=":")
ax.plot([DRIFT_START + DLY["median"]], [50], "o", color="#E65100", ms=4.5, zorder=6)
ax.text(DRIFT_START + DLY["median"] + 1.0, 47, f"median: {DLY['median']:.0f} quarters\nafter the drift", fontsize=8,
        color="#E65100", va="top")
ax.set(xlim=(0, 40), ylim=(0, 100), xticks=[0, 8, 16, 24, 32, 40], xlabel="quarter", ylabel="monitors that have alarmed (%)")
ax.set_title("(a) alarms, with and without the drift", fontsize=9)
ax.legend(frameon=False, fontsize=7.5, loc="upper left")
for key, col, ls, lab in (("static", "#B71C1C", "--", "twin, law never questioned"), ("monitored", "#1F4E79", "-",
                          "twin with escalation"), ("oracle", "#2E7D32", ":", "twin told of the drift")):
    bx.plot(np.arange(40), DRUNS[key].kept, color=col, ls=ls, lw=1.5, label=lab)
bx.axhline(FLOOR, color="#999999", lw=0.8, ls=":")
bx.axvline(DRIFT_START, ymax=0.6, color="#999999", lw=0.8, ls=":")
bx.text(39.5, 55.1, "floor", fontsize=8, color="#616161", ha="right", va="bottom")
bx.set(xlim=(0, 40), ylim=(51, 61), xticks=[0, 8, 16, 24, 32, 40], xlabel="quarter", ylabel="mean capability (points)")
bx.set_title("(b) mean capability under the drift", fontsize=9)
bx.legend(frameon=False, fontsize=7.5, loc="upper right")
fig.suptitle("The monitor finds the drift in 12 quarters, in the median (book seed 1507)", fontsize=10.5)
plt.tight_layout(); plt.show()
Theorem 15.3(i): the twin that keeps its law under the drift overestimates capability by b+ = 2.210 just after a survey and 3.088 just before the next (steady gain 0.2844); its innovations' mean is -1.045 standard deviations; the recursion from quarter 8 reaches 2.205 at quarter 40 and 2.210 at quarter 200

the monitor's calibration, 20,000 paths without a drift (seed 1505), 2 s:
  threshold                    1.50    1.75    2.00    2.25    2.50    3.00
  false alarms a survey      0.0471  0.0347  0.0258  0.0192  0.0145  0.0084
  one in so many years         10.6    14.4    19.4    26.0    34.5    59.8
  the least threshold with at most one false alarm in 50 surveys: 2.25; one in 26.0 years
Theorem 15.3(ii) with delta = 2 kappa = 1: H = ln(gamma)/delta guarantees at least gamma = e^2.25 = 9.5 surveys between false alarms (here 52), and a delay of about 2 ln(gamma)/delta^2 = 4.5 surveys once the innovations have shifted by a standard deviation

the drift from quarter 8, 100,000 paths (seed 1507), 8 s:
                                      cost from 58   above the count   below floor
  count, law re-estimated at once         301.992           0.000         14.1%
  twin, law never questioned              358.465          56.473         79.9%
  twin with the monitor                   320.169          18.177         14.4%
  twin told of the drift                  312.285          10.293         14.6%
the monitor detects the drift on 100.0% of paths, after 12 quarters in the median (4 to 22 from the 10th to the 90th percentile, 12.3 on average)
without a drift the monitored twin costs 241.638 against 241.837 unmonitored and audits 4.6 times in 120 years
the correct twin's standardized innovations over 239 surveys x 100,000 paths: mean 0.0001, sd 0.9999, correlation with the previous survey's -0.0001; the twin that keeps its law under the drift, from quarter 40 on: mean -1.0449 (the formula: -1.0450)
within 40 quarters 30.8% of monitors raise a false alarm without a drift
The monitor finds the drift in 12 quarters, in the median (book seed 1507)

Panel 5 — Set the envelope (Definition 15.3; Proposition 15.3; Worked Example 15.1, Step 6: the twin hires alone inside Chapter 14's guardrail and escalates on its monitor's alarm; a trigger on its uncertainty would fire twice a year on schedule; its target, chosen on the design paths at $241.85m, costs $241.94m on the fresh ones, within the simulation's error)

AXIOM Lab 2.15, step 5. The envelope declares what the twin may do alone and when it hands a decision back. Proposition 15.3(ii): a guardrail that holds a best decision for every belief costs nothing at the optimum; every target here plans at least 55.75 on the twin's estimate unless hiring is at the cap, so Chapter 14's guardrail holds on every fresh path and quarter. Part (iii): the error variances do not depend on the readings, so a trigger on the twin's uncertainty fires on a calendar fixed in advance; only the innovations can catch a change in the law. Part (i): the loop is stable when the rule and the filter are. Last, the audit committee's certification of the target on fresh paths, and an illustration with new draws from the lab's seed, 26215: ten programs under the drift, each run by the monitored twin, whose errors keep the same calendar until an alarm sends the engineering office to audit.

Python Code
print(f"Proposition 15.3(ii): planned capability on the estimate below 55 without hiring at the cap, on {N_FRESH:,} fresh "
      f"paths x {HORIZON} quarters: {sum(DES[k]['breaks'] for k in DES)} times in all designs")
pr2, po2, _ = kalman_path(2, SD_SURVEY, horizon=40)
sd_dec = np.sqrt(np.where(schedule(2, 40), po2, pr2))          # the error the twin decides with, quarter by quarter
sd_eve = np.sqrt(pr2)
TRIG = 1.5
fires = [t for t in range(40) if schedule(2, 40)[t] and sd_eve[t] > TRIG]
print(f"Proposition 15.3(iii): the twin's error just before each survey, quarters 2-12: "
      + ", ".join(f"{sd_eve[t]:.3f}" for t in range(2, 13, 2)) + f", ... settling at {ERR['twin']['before']:.3f}; just after, "
      f"{ERR['twin']['after']:.3f}")
print(f"  a trigger 'escalate when the error exceeds {TRIG} points' fires on the eve of every survey from quarter {fires[0]} "
      f"on, whatever the surveys say: a calendar the board might as well schedule")
mode_rule = ALPHA - ALPHA                                         # h = T - 0.975 c restores the target in one quarter
mode_filter = (1 - Kss) * ALPHA ** 2                              # the error's mode over the half year between surveys
print(f"Proposition 15.3(i): the rule's mode {mode_rule:.3f} (it restores the target in a quarter, inside the limits) and "
      f"the filter's {mode_filter:.3f} a half year, (1 - K) a^2: both inside the unit circle, so the loop is stable")
se_d = DES["twin"]["costs"].std() / math.sqrt(N_DESIGN)
GAP = DES["twin"]["cost"] - DES["twin"]["design"]
print(f"Worked Example 15.1, Step 6: chosen on the design paths at {DES['twin']['design']:.2f}, the target costs "
      f"{DES['twin']['cost']:.2f} on the fresh ones; the difference {GAP:.3f} is {GAP / math.sqrt(se_d ** 2 + DES['twin']['se'] ** 2):.1f} "
      f"standard errors ({se_d:.3f} on the design paths, {DES['twin']['se']:.3f} on the fresh): within the simulation's error")

# new draws with the lab's seed: ten programs under the drift, run by the monitored twin
ten = run([Program([TT], "twin", 2, SD_SURVEY, n=10, horizon=40, drift=dr, monitor=(KAPPA, H_STAR), trace=10, sample=10)],
          SEED, 10, horizon=40)[0]
P10 = np.sqrt(np.array([x["p"] for x in ten.log]))                  # the error each program decides with: [quarter, program]
GT = np.array([t for t, _, _, _ in ten.zrec])                        # survey quarters
G10 = np.array([G for _, _, G, _ in ten.zrec])                       # the cumulative sum at each survey, before a restart
HIT = np.array([a for _, _, _, a in ten.zrec])
first10 = ten.first[0]
same = bool(np.allclose(P10[:first10.min()], P10[:first10.min(), :1]))
print(f"\nten programs under the drift (seed {SEED}): alarms from quarter {DRIFT_START} at quarters "
      + ", ".join(str(int(x)) for x in first10) + f" ({np.median(first10 - DRIFT_START):.0f} quarters after the drift in the "
      f"median); their errors agree, quarter by quarter, until the first audit: {same}")
fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6))
for i in range(10):
    ax.step(np.arange(40), P10[:, i], where="post", color="#1F4E79", lw=0.9, alpha=0.55)
    ax.plot([first10[i]], [0.0], "o", color="#B71C1C", ms=3.5, zorder=5, clip_on=False,
            label="alarm and audit" if i == 0 else None)
    upto = GT <= first10[i]                                          # each program's sum until its alarm
    bx.plot(GT[upto], G10[upto, i], color="#1F4E79", lw=0.9, alpha=0.55, marker=".", ms=3)
    bx.plot([first10[i]], [G10[GT == first10[i], i][0]], "o", color="#B71C1C", ms=4, zorder=5,
            label="alarm and audit" if i == 0 else None)
ax.axvline(DRIFT_START, color="#999999", lw=0.8, ls=":")
ax.text(DRIFT_START + 0.5, 1.88, "drift begins", fontsize=8, color="#616161")
ax.set(xlim=(0, 40), ylim=(0, 2.0), xticks=[0, 8, 16, 24, 32, 40], xlabel="quarter", ylabel="the twin's error (sd, points)")
ax.set_title("(a) uncertainty keeps a calendar", fontsize=9)
ax.legend(frameon=False, fontsize=7.5, loc="upper right")
bx.axhline(H_STAR, color="#B71C1C", lw=0.9, ls="--")
bx.text(39.5, H_STAR + 0.15, f"threshold {H_STAR}", fontsize=8, color="#B71C1C", ha="right")
bx.axvline(DRIFT_START, color="#999999", lw=0.8, ls=":")
bx.set(xlim=(0, 40), ylim=(0, 5), xticks=[0, 8, 16, 24, 32, 40], xlabel="quarter", ylabel="cumulative sum G at each survey")
bx.set_title("(b) the surprises raise the alarm", fontsize=9)
bx.legend(frameon=False, fontsize=7.5, loc="upper left")
fig.suptitle("Escalate on surprises, not on uncertainty (seed 26215)", fontsize=10.5)
plt.tight_layout(); plt.show()
Proposition 15.3(ii): planned capability on the estimate below 55 without hiring at the cap, on 100,000 fresh paths x 480 quarters: 0 times in all designs
Proposition 15.3(iii): the twin's error just before each survey, quarters 2-12: 0.937, 1.254, 1.419, 1.501, 1.541, 1.560, ... settling at 1.576; just after, 1.333
  a trigger 'escalate when the error exceeds 1.5 points' fires on the eve of every survey from quarter 8 on, whatever the surveys say: a calendar the board might as well schedule
Proposition 15.3(i): the rule's mode 0.000 (it restores the target in a quarter, inside the limits) and the filter's 0.680 a half year, (1 - K) a^2: both inside the unit circle, so the loop is stable
Worked Example 15.1, Step 6: chosen on the design paths at 241.85, the target costs 241.94 on the fresh ones; the difference 0.092 is 0.9 standard errors (0.093 on the design paths, 0.042 on the fresh): within the simulation's error

ten programs under the drift (seed 26215): alarms from quarter 8 at quarters 20, 16, 12, 10, 22, 20, 26, 12, 26, 22 (12 quarters after the drift in the median); their errors agree, quarter by quarter, until the first audit: True
Escalate on surprises, not on uncertainty (seed 26215)

Panel 6 — Table 15.3: designs for knowing capability, from an audited 58 (Worked Example 15.1)

Table 15.3's rows from the panels above. Target: planned capability (points); error: the estimate's standard deviation just after and just before a survey; cost above the count: present value at 10 percent, $ million, on the 100,000 fresh paths (with the drift, on its 100,000 paths, above the count with the drift); below floor: long-run share of quarters below 55.

Python Code
def err_txt(key):
    e = ERR.get(key, {})
    if key == "exact":
        return "0"
    if key == "none":
        return f"{e['limit']:.2f}"
    return f"{e['after']:.2f}-{e['before']:.2f}"

T153 = [("Count (Chapter 7)", "--", DES["exact"]["best"], "exact", 0.0, DES["exact"]["below"]),
        ("No readings after the audit", "none", DES["none"]["best"], "none", DES["none"]["excess"], DES["none"]["below"]),
        ("Survey read as exact", "twice a year", T7, "reset", FIXED["survey as exact at Chapter 7's 55.75"]["excess"],
         FIXED["survey as exact at Chapter 7's 55.75"]["below"]),
        ("  whole error guarded", "twice a year", T7 + 5.0, "reset",
         FIXED["survey as exact at 60.75, the whole error guarded"]["excess"],
         FIXED["survey as exact at 60.75, the whole error guarded"]["below"]),
        ("  best target", "twice a year", DES["reset"]["best"], "reset", DES["reset"]["excess"], DES["reset"]["below"]),
        ("Twin, Chapter 7's target", "twice a year", T7, "twin", FIXED["twin at Chapter 7's 55.75"]["excess"],
         FIXED["twin at Chapter 7's 55.75"]["below"]),
        ("Twin, best target", "twice a year", DES["twin"]["best"], "twin", DES["twin"]["excess"], DES["twin"]["below"]),
        ("Twin", "quarterly", DES["twin_quarterly"]["best"], "twin_quarterly", DES["twin_quarterly"]["excess"],
         DES["twin_quarterly"]["below"]),
        ("Twin", "twice as sharp", DES["twin_sharp"]["best"], "twin_sharp", DES["twin_sharp"]["excess"],
         DES["twin_sharp"]["below"]),
        ("Twin", "both", DES["twin_quarterly_sharp"]["best"], "twin_quarterly_sharp", DES["twin_quarterly_sharp"]["excess"],
         DES["twin_quarterly_sharp"]["below"]),
        ("Twin, law never questioned", "twice a year", TT, None, DR["static"]["cost"] - DR["count"]["cost"],
         DR["static"]["below"]),
        ("Twin with monitor", "twice a year", TT, None, DR["monitored"]["cost"] - DR["count"]["cost"], DR["monitored"]["below"]),
        ("Twin told of the drift", "twice a year", TT, None, DR["oracle"]["cost"] - DR["count"]["cost"], DR["oracle"]["below"])]
print(f"{'Design':30s} {'Survey':15s} {'Target':>7s} {'Error (sd)':>11s} {'Cost above the count':>21s} {'Below floor (%)':>16s}")
for i, (name, surv, tgt, key, ex, below) in enumerate(T153):
    if i == 10:
        print("An extra half point lost each quarter from quarter 8 (cost above the count with the drift):")
    print(f"{name:30s} {surv:15s} {tgt:7.2f} {err_txt(key) if key else '--':>11s} {ex:21.2f} {100 * below:16.1f}")
print(f"\nall cells took {time.time() - T_START:.0f} s")
Design                         Survey           Target  Error (sd)  Cost above the count  Below floor (%)
Count (Chapter 7)              --                55.75           0                  0.00              6.0
No readings after the audit    none              57.80        3.02                 25.43             17.6
Survey read as exact           twice a year      55.75   2.50-2.53                 27.51             38.6
  whole error guarded          twice a year      60.75   2.50-2.53                 34.40              0.2
  best target                  twice a year      57.35   2.50-2.53                 15.95             13.3
Twin, Chapter 7's target       twice a year      55.75   1.33-1.58                 16.31             31.3
Twin, best target              twice a year      56.70   1.33-1.58                 11.10             13.4
Twin                           quarterly         56.50   1.17-1.32                  8.63             13.0
Twin                           twice as sharp    56.40   0.89-1.26                  7.01             12.1
Twin                           both              56.20   0.79-1.02                  4.92             12.2
An extra half point lost each quarter from quarter 8 (cost above the count with the drift):
Twin, law never questioned     twice a year      56.70          --                 56.47             79.9
Twin with monitor              twice a year      56.70          --                 18.18             14.4
Twin told of the drift         twice a year      56.70          --                 10.29             14.6

all cells took 69 s

Validation — the book's numbers, and agreement with DCT_V2_Ch15_Lab.xlsx

Each checkpoint is a number printed in Chapter 15 (the abstract, Sections 15.2–15.5, Worked Example 15.1, Table 15.3, Figure 15.3, the Key Takeaways, the LOS Guidance) or in Online Appendix Remark 15.B.1 and Example 15.B.2, with a tolerance of half a unit in its last printed digit; a few check what a theorem or proposition promises (1 = holds), and the simulated innovations are checked within 0.01. Shares are in percent. The workbook recomputes the checkpoints marked workbook with spreadsheet formulas and shows PASS against the same engine values on its Checks sheet.

Python Code
def bk(s):
    # a number as the book prints it: its value and half a unit in its last printed digit
    t = s.replace(",", "").replace("−", "-")
    return float(t), 0.5 * 10.0 ** -(len(t.split(".")[1]) if "." in t else 0) + 1e-9

def c_(name, got, printed):
    v, tol = bk(printed)
    return (name, float(got), v, tol)

def flag(name, ok):
    return (name, float(bool(ok)), 1.0, 0.0)

def count(name, got, n):
    return (name, float(got), float(n), 0.0)

pc = lambda x: 100.0 * x
E2, D_ = ERR["twin"], DES
FX = {"twin55": FIXED["twin at Chapter 7's 55.75"], "reset55": FIXED["survey as exact at Chapter 7's 55.75"],
      "reset60": FIXED["survey as exact at 60.75, the whole error guarded"]}
checks = [
    # the declarations and the twin's error (Step 1-2; Section 15.2; Theorem 15.1; Table 15.3; Example 15.B.2)
    c_("a swing's variance q (workbook)", Q, "0.45"),
    c_("a swing's standard deviation, Section 15.2 (workbook)", math.sqrt(Q), "0.67"),
    c_("no readings: the error's limit (workbook)", ERR["none"]["limit"], "3.019"),
    c_("no readings: error, Table 15.3", ERR["none"]["limit"], "3.02"),
    c_("no readings: error, Section 15.2 and Step 2", ERR["none"]["limit"], "3.0"),
    c_("twin: error just after a survey (workbook)", E2["after"], "1.333"),
    c_("twin: error a quarter later (workbook)", E2["mid"], "1.463"),
    c_("twin: error just before the next survey (workbook)", E2["before"], "1.576"),
    c_("twin: the gain (workbook)", E2["gain"], "0.284"),
    c_("twin: the gain, Section 15.2", E2["gain"], "0.28"),
    c_("twin: error just after, Table 15.3 and Step 2", E2["after"], "1.33"),
    c_("twin: error just before, Table 15.3 and Step 2", E2["before"], "1.58"),
    c_("quarterly survey: error just after (workbook)", ERR["twin_quarterly"]["after"], "1.169"),
    c_("quarterly survey: error just before (workbook)", ERR["twin_quarterly"]["before"], "1.323"),
    c_("quarterly survey: the gain (workbook)", ERR["twin_quarterly"]["gain"], "0.219"),
    c_("quarterly survey: Table 15.3, after", ERR["twin_quarterly"]["after"], "1.17"),
    c_("quarterly survey: Table 15.3, before", ERR["twin_quarterly"]["before"], "1.32"),
    c_("twice as sharp: error just after (workbook)", ERR["twin_sharp"]["after"], "0.888"),
    c_("twice as sharp: error just before (workbook)", ERR["twin_sharp"]["before"], "1.261"),
    c_("twice as sharp: Table 15.3, after", ERR["twin_sharp"]["after"], "0.89"),
    c_("twice as sharp: Table 15.3, before", ERR["twin_sharp"]["before"], "1.26"),
    c_("both: error just after (workbook)", ERR["twin_quarterly_sharp"]["after"], "0.791"),
    c_("both: error just before (workbook)", ERR["twin_quarterly_sharp"]["before"], "1.022"),
    c_("both: Table 15.3, after", ERR["twin_quarterly_sharp"]["after"], "0.79"),
    c_("both: Table 15.3, before", ERR["twin_quarterly_sharp"]["before"], "1.02"),
    c_("survey read as exact: error just after (workbook)", ERR["reset"]["after"], "2.500"),
    c_("survey read as exact: error just before (workbook)", ERR["reset"]["before"], "2.528"),
    c_("survey read as exact: Table 15.3 and Step 2, before", ERR["reset"]["before"], "2.53"),
    c_("survey read as exact: good to, Section 15.2", ERR["reset"]["after"], "2.5"),
    flag("Theorem 15.1(iii): from 0 and from 10 the variance reaches the fixed point", CONVERGE < 1e-12),
    flag("Proposition 15.1(i): precisions add at a survey (workbook)", abs(PRECISION - E2["fp"]) < 1e-12),
    c_("exact filter: largest difference of the means", EXACT["max_abs"], "0.012"),
    c_("exact filter: mean difference", EXACT["mean_abs"], "0.0013"),
    c_("exact filter: largest difference of the sds", EXACT["sd_max"], "0.011"),
    count("exact filter: survey updates compared", EXACT["n"], 5700),
    # the designs (Step 3; Section 15.3; Table 15.3; Example 15.B.2)
] + [c_(f"{LABEL[k]}: best target (workbook)", D_[k]["best"], p) for k, p in
     (("exact", "55.75"), ("twin", "56.70"), ("reset", "57.35"), ("twin_quarterly", "56.50"), ("twin_sharp", "56.40"),
      ("twin_quarterly_sharp", "56.20"), ("none", "57.80"))] + [
    flag("every design's best target lies inside its window", all(D_[k]["interior"] for k in D_)),
    flag("the 0.25 grid's least cost lies in the window: count, twin, survey as exact, no readings",
         all(D_[k]["grid_in_window"] for k in CURVED)),
    c_("count: design-path cost (workbook)", D_["exact"]["design"], "230.747"),
    c_("twin: design-path cost (workbook)", D_["twin"]["design"], "241.852"),
    c_("twin: design-path cost, Step 6", D_["twin"]["design"], "241.85"),
    c_("count: cost from 58", D_["exact"]["cost"], "230.844"),
    c_("count: cost from 58, Section 15.3 and Step 3", D_["exact"]["cost"], "230.8"),
    c_("count: standard error", D_["exact"]["se"], "0.040"),
    c_("twin: cost from 58", D_["twin"]["cost"], "241.944"),
    c_("twin: cost from 58, Step 6", D_["twin"]["cost"], "241.94"),
    c_("twin: cost from 58, Section 15.3", D_["twin"]["cost"], "241.9"),
    c_("twin: standard error", D_["twin"]["se"], "0.042"),
    c_("survey read as exact: cost from 58", D_["reset"]["cost"], "246.793"),
    c_("quarterly survey: cost from 58", D_["twin_quarterly"]["cost"], "239.478"),
    c_("twice as sharp: cost from 58", D_["twin_sharp"]["cost"], "237.849"),
    c_("both: cost from 58", D_["twin_quarterly_sharp"]["cost"], "235.765"),
    c_("no readings: cost from 58", D_["none"]["cost"], "256.277"),
    c_("no readings: standard error", D_["none"]["se"], "0.063"),
    c_("twin: above the count (workbook)", D_["twin"]["excess"], "11.101"),
    c_("twin: above the count, Table 15.3", D_["twin"]["excess"], "11.10"),
    c_("twin: above the count, abstract, Step 3, Key Takeaways", D_["twin"]["excess"], "11.1"),
    c_("twin: margin, Section 15.3 and the board (workbook)", D_["twin"]["best"] - FLOOR, "1.70"),
    c_("survey read as exact: above the count (workbook)", D_["reset"]["excess"], "15.950"),
    c_("survey read as exact: above the count, Table 15.3", D_["reset"]["excess"], "15.95"),
    c_("survey read as exact: above the count, Step 3", D_["reset"]["excess"], "15.9"),
    c_("abstract: the twin costs less than the survey read as exact (workbook)", D_["reset"]["excess"] - D_["twin"]["excess"],
       "4.8"),
    c_("quarterly survey: above the count (workbook)", D_["twin_quarterly"]["excess"], "8.634"),
    c_("quarterly survey: above the count, Table 15.3", D_["twin_quarterly"]["excess"], "8.63"),
    c_("quarterly survey: above the count, Step 4", D_["twin_quarterly"]["excess"], "8.6"),
    c_("twice as sharp: above the count (workbook)", D_["twin_sharp"]["excess"], "7.005"),
    c_("twice as sharp: above the count, Table 15.3", D_["twin_sharp"]["excess"], "7.01"),
    c_("twice as sharp: above the count, Step 4", D_["twin_sharp"]["excess"], "7.0"),
    c_("both: above the count (workbook)", D_["twin_quarterly_sharp"]["excess"], "4.921"),
    c_("both: above the count, Table 15.3", D_["twin_quarterly_sharp"]["excess"], "4.92"),
    c_("both: above the count, Step 4", D_["twin_quarterly_sharp"]["excess"], "4.9"),
    c_("no readings: above the count (workbook)", D_["none"]["excess"], "25.433"),
    c_("no readings: above the count, Table 15.3", D_["none"]["excess"], "25.43"),
    c_("no readings: above the count, Step 3", D_["none"]["excess"], "25.4"),
    c_("twin at Chapter 7's 55.75: above the count (workbook)", FX["twin55"]["excess"], "16.313"),
    c_("twin at Chapter 7's 55.75: Table 15.3", FX["twin55"]["excess"], "16.31"),
    c_("twin at Chapter 7's 55.75: Section 15.3 and Step 3", FX["twin55"]["excess"], "16.3"),
    c_("survey as exact at 55.75: above the count (workbook)", FX["reset55"]["excess"], "27.509"),
    c_("survey as exact at 55.75: Table 15.3", FX["reset55"]["excess"], "27.51"),
    c_("survey as exact at 55.75: Step 3", FX["reset55"]["excess"], "27.5"),
    c_("survey as exact at 60.75: above the count (workbook)", FX["reset60"]["excess"], "34.396"),
    c_("survey as exact at 60.75: Table 15.3", FX["reset60"]["excess"], "34.40"),
    c_("survey as exact at 60.75: Step 3", FX["reset60"]["excess"], "34.4"),
    c_("count: below the floor, %", pc(D_["exact"]["below"]), "6.0"),
    c_("twin: below the floor, %", pc(D_["twin"]["below"]), "13.4"),
    c_("survey read as exact: below the floor, %", pc(D_["reset"]["below"]), "13.3"),
    c_("quarterly survey: below the floor, %", pc(D_["twin_quarterly"]["below"]), "13.0"),
    c_("twice as sharp: below the floor, %", pc(D_["twin_sharp"]["below"]), "12.1"),
    c_("both: below the floor, %", pc(D_["twin_quarterly_sharp"]["below"]), "12.2"),
    c_("no readings: below the floor, %", pc(D_["none"]["below"]), "17.6"),
    c_("twin at 55.75: below the floor, %", pc(FX["twin55"]["below"]), "31.3"),
    c_("twin at 55.75: below the floor, %, Section 15.3 and Step 3", pc(FX["twin55"]["below"]), "31"),
    c_("survey as exact at 55.75: below the floor, %", pc(FX["reset55"]["below"]), "38.6"),
    c_("survey as exact at 60.75: below the floor, %", pc(FX["reset60"]["below"]), "0.2"),
    flag("Proposition 15.2(i): the chosen targets cost less on their design paths than on fresh ones",
         D_["twin"]["design"] < D_["twin"]["cost"] and D_["exact"]["design"] < D_["exact"]["cost"]),
    flag("Proposition 15.2(ii): common paths tell neighbouring targets apart better", CRN["sd_common"] < CRN["sd_indep"]),
    flag("Step 6: the design-path cost is within two standard errors of the fresh", abs(GAP) < 2 * math.sqrt(se_d ** 2 + D_["twin"]["se"] ** 2)),
    flag("Theorem 15.2(i): the count, better surveys, the twin, the survey as exact, no readings, in order of cost",
         D_["exact"]["cost"] < D_["twin_quarterly_sharp"]["cost"] < min(D_["twin_sharp"]["cost"], D_["twin_quarterly"]["cost"])
         and max(D_["twin_sharp"]["cost"], D_["twin_quarterly"]["cost"]) < D_["twin"]["cost"] < D_["reset"]["cost"] < D_["none"]["cost"]),
    c_("Theorem 15.2(iii): the count's margin, the swing's quantile (workbook)", QUANT, "0.75"),
    c_("Chapter 7's critical ratio (workbook)", RATIO, "0.1228"),
    # readings (Step 4; Section 15.3; Figure 15.2(b); Example 15.B.2)
    c_("the count is worth a year against the twin, Section 15.3 and Step 4 (workbook)", VALUE["count against the twin"], "1.0"),
    c_("a quarterly survey is worth a year, Step 4 (workbook)", VALUE["a quarterly survey"], "0.23"),
    c_("a survey twice as sharp is worth a year, Step 4 (workbook)", VALUE["a survey twice as sharp"], "0.39"),
    c_("both are worth a year, Step 4 (workbook)", VALUE["both"], "0.58"),
] + [c_(f"readings study, {'twice a year' if c['every'] == 2 else 'quarterly'}, error {c['sd']}: best target", c["best"], p)
     for c, p in zip(CASES, ("56.10", "56.30", "56.40", "56.45", "56.60", "56.70", "56.80", "57.00", "57.10",
                             "55.90", "56.10", "56.20", "56.25", "56.40", "56.50", "56.60", "56.75", "56.90"))] + [
    c_(f"readings study, {'twice a year' if c['every'] == 2 else 'quarterly'}, error {c['sd']}: above the count",
       c["excess"], p)
    for c, p in zip(CASES, ("3.90", "6.00", "7.01", "7.94", "9.63", "11.10", "12.38", "14.47", "16.12",
                            "2.01", "4.00", "4.92", "5.78", "7.30", "8.63", "9.81", "11.83", "13.47"))] + [
    flag("readings study: every best target inside its window", all(c["interior"] for c in CASES)),
    # the monitor (Step 5; Section 15.4; Theorem 15.3; Figure 15.3; Example 15.B.2)
    c_("unmonitored under the drift: bias just after a survey (workbook)", B_AFTER, "2.210"),
    c_("unmonitored under the drift: bias just before the next (workbook)", B_BEFORE, "3.088"),
    c_("unmonitored under the drift: innovations' mean, sd (workbook)", INNOV, "-1.045"),
    c_("Section 15.4: overestimates by about, after", B_AFTER, "2.2"),
    c_("Section 15.4: and before", B_BEFORE, "3.1"),
] + [c_(f"calibration: false alarms a survey at {h}", r_, p) for h, r_, p in
     zip(THRESH, RATE, ("0.0471", "0.0347", "0.0258", "0.0192", "0.0145", "0.0084"))] + [
    c_(f"calibration: one false alarm in so many years at {h} (workbook)", 1 / r_ / 2, p) for h, r_, p in
    zip(THRESH, RATE, ("10.6", "14.4", "19.4", "26.0", "34.5", "59.8"))] + [
    c_("the threshold (workbook)", H_STAR, "2.25"),
    c_("a false alarm about once in so many years, Section 15.4 and Step 5", 1 / RATE[THRESH.index(H_STAR)] / 2, "26"),
    c_("Remark 15.B.1: the count raises its target under the drift to", T7 + DRIFT, "56.25"),
    c_("drift: the count, cost from 58", DR["count"]["cost"], "301.992"),
    c_("drift: the count, Step 5", DR["count"]["cost"], "302.0"),
    c_("drift: the count, below the floor, %", pc(DR["count"]["below"]), "14.1"),
    c_("drift: law never questioned, cost from 58", DR["static"]["cost"], "358.465"),
    c_("drift: law never questioned, above the count (workbook)", DR["static"]["cost"] - DR["count"]["cost"], "56.47"),
    c_("drift: law never questioned, above the count, Step 5", DR["static"]["cost"] - DR["count"]["cost"], "56.5"),
    c_("drift: law never questioned, below the floor, %", pc(DR["static"]["below"]), "79.9"),
    c_("drift: law never questioned, below, %, Section 15.4 and Step 5", pc(DR["static"]["below"]), "80"),
    c_("drift: with the monitor, cost from 58", DR["monitored"]["cost"], "320.169"),
    c_("drift: with the monitor, above the count (workbook)", DR["monitored"]["cost"] - DR["count"]["cost"], "18.18"),
    c_("drift: with the monitor, above the count, Step 5", DR["monitored"]["cost"] - DR["count"]["cost"], "18.2"),
    c_("drift: with the monitor, below the floor, %", pc(DR["monitored"]["below"]), "14.4"),
    c_("drift: told of the drift, cost from 58", DR["oracle"]["cost"], "312.285"),
    c_("drift: told of the drift, above the count (workbook)", DR["oracle"]["cost"] - DR["count"]["cost"], "10.29"),
    c_("drift: told of the drift, above the count, Step 5", DR["oracle"]["cost"] - DR["count"]["cost"], "10.3"),
    c_("drift: told of the drift, below the floor, %", pc(DR["oracle"]["below"]), "14.6"),
    c_("drift: detected on every path, share", DLY["detected"], "1"),
    c_("drift: delay, median quarters (workbook)", DLY["median"], "12"),
    c_("drift: delay, 10th percentile (workbook)", DLY["q10"], "4"),
    c_("drift: delay, 90th percentile (workbook)", DLY["q90"], "22"),
    c_("drift: delay, mean (workbook)", DLY["mean"], "12.3"),
    c_("abstract and Section 15.4: a median of 12 quarters", DLY["median"], "12"),
    c_("no drift: the monitored twin, cost from 58", DR["monitored_nd"]["cost"], "241.638"),
    c_("no drift: the twin without a monitor, cost from 58", DR["twin_nd"]["cost"], "241.837"),
    c_("no drift: audits in 120 years", AUDITS, "4.6"),
    flag("Theorem 15.3(i): the correct twin's innovations, mean 0 (within 0.01)", abs(WHITE["mean"]) < 0.01),
    flag("Theorem 15.3(i): the correct twin's innovations, sd 1 (within 0.01)", abs(WHITE["sd"] - 1) < 0.01),
    flag("Theorem 15.3(i): the correct twin's innovations, uncorrelated (within 0.01)", abs(WHITE["lag1"]) < 0.01),
    flag("Theorem 15.3(i): under the drift the innovations' mean settles at the formula's (within 0.01)",
         abs(WHITE["drift_mean"] - INNOV) < 0.01),
    # the envelope (Step 6; Section 15.5; Proposition 15.3)
    count("Proposition 15.3(ii): the guardrail, breaches on the fresh paths", sum(DES[k]["breaks"] for k in DES), 0),
    c_("Section 15.5: least sure just before a survey", E2["before"], "1.58"),
    c_("Section 15.5: most sure just after it", E2["after"], "1.33"),
    flag("Proposition 15.3(i): the rule's and the filter's modes inside the unit circle (workbook)",
         abs(mode_rule) < 1 and abs(mode_filter) < 1),
    # LOS Guidance and the board
    c_("LOS 15.3: the twin's target", D_["twin"]["best"], "56.70"),
    c_("the board: Chapter 7's margin", T7 - FLOOR, "0.75"),
]
ok = 0
for name, got, want, tol in checks:
    status = "PASS" if abs(got - want) <= tol else "FAIL"
    ok += status == "PASS"
    print(f"{name:88s} {got:11.4f}   book {want:10.4f}   {status}")
print(f"\n{ok} of {len(checks)} checkpoints PASS")
a swing's variance q (workbook)                                                               0.4500   book     0.4500   PASS
a swing's standard deviation, Section 15.2 (workbook)                                         0.6708   book     0.6700   PASS
no readings: the error's limit (workbook)                                                     3.0189   book     3.0190   PASS
no readings: error, Table 15.3                                                                3.0189   book     3.0200   PASS
no readings: error, Section 15.2 and Step 2                                                   3.0189   book     3.0000   PASS
twin: error just after a survey (workbook)                                                    1.3333   book     1.3330   PASS
twin: error a quarter later (workbook)                                                        1.4628   book     1.4630   PASS
twin: error just before the next survey (workbook)                                            1.5761   book     1.5760   PASS
twin: the gain (workbook)                                                                     0.2844   book     0.2840   PASS
twin: the gain, Section 15.2                                                                  0.2844   book     0.2800   PASS
twin: error just after, Table 15.3 and Step 2                                                 1.3333   book     1.3300   PASS
twin: error just before, Table 15.3 and Step 2                                                1.5761   book     1.5800   PASS
quarterly survey: error just after (workbook)                                                 1.1691   book     1.1690   PASS
quarterly survey: error just before (workbook)                                                1.3226   book     1.3230   PASS
quarterly survey: the gain (workbook)                                                         0.2187   book     0.2190   PASS
quarterly survey: Table 15.3, after                                                           1.1691   book     1.1700   PASS
quarterly survey: Table 15.3, before                                                          1.3226   book     1.3200   PASS
twice as sharp: error just after (workbook)                                                   0.8877   book     0.8880   PASS
twice as sharp: error just before (workbook)                                                  1.2609   book     1.2610   PASS
twice as sharp: Table 15.3, after                                                             0.8877   book     0.8900   PASS
twice as sharp: Table 15.3, before                                                            1.2609   book     1.2600   PASS
both: error just after (workbook)                                                             0.7914   book     0.7910   PASS
both: error just before (workbook)                                                            1.0225   book     1.0220   PASS
both: Table 15.3, after                                                                       0.7914   book     0.7900   PASS
both: Table 15.3, before                                                                      1.0225   book     1.0200   PASS
survey read as exact: error just after (workbook)                                             2.5000   book     2.5000   PASS
survey read as exact: error just before (workbook)                                            2.5281   book     2.5280   PASS
survey read as exact: Table 15.3 and Step 2, before                                           2.5281   book     2.5300   PASS
survey read as exact: good to, Section 15.2                                                   2.5000   book     2.5000   PASS
Theorem 15.1(iii): from 0 and from 10 the variance reaches the fixed point                    1.0000   book     1.0000   PASS
Proposition 15.1(i): precisions add at a survey (workbook)                                    1.0000   book     1.0000   PASS
exact filter: largest difference of the means                                                 0.0119   book     0.0120   PASS
exact filter: mean difference                                                                 0.0013   book     0.0013   PASS
exact filter: largest difference of the sds                                                   0.0111   book     0.0110   PASS
exact filter: survey updates compared                                                      5700.0000   book  5700.0000   PASS
count (Chapter 7): best target (workbook)                                                    55.7500   book    55.7500   PASS
twin, survey twice a year: best target (workbook)                                            56.7000   book    56.7000   PASS
survey read as exact: best target (workbook)                                                 57.3500   book    57.3500   PASS
twin, quarterly survey: best target (workbook)                                               56.5000   book    56.5000   PASS
twin, twice as sharp: best target (workbook)                                                 56.4000   book    56.4000   PASS
twin, both: best target (workbook)                                                           56.2000   book    56.2000   PASS
no readings after the audit: best target (workbook)                                          57.8000   book    57.8000   PASS
every design's best target lies inside its window                                             1.0000   book     1.0000   PASS
the 0.25 grid's least cost lies in the window: count, twin, survey as exact, no readings      1.0000   book     1.0000   PASS
count: design-path cost (workbook)                                                          230.7471   book   230.7470   PASS
twin: design-path cost (workbook)                                                           241.8519   book   241.8520   PASS
twin: design-path cost, Step 6                                                              241.8519   book   241.8500   PASS
count: cost from 58                                                                         230.8437   book   230.8440   PASS
count: cost from 58, Section 15.3 and Step 3                                                230.8437   book   230.8000   PASS
count: standard error                                                                         0.0395   book     0.0400   PASS
twin: cost from 58                                                                          241.9443   book   241.9440   PASS
twin: cost from 58, Step 6                                                                  241.9443   book   241.9400   PASS
twin: cost from 58, Section 15.3                                                            241.9443   book   241.9000   PASS
twin: standard error                                                                          0.0416   book     0.0420   PASS
survey read as exact: cost from 58                                                          246.7935   book   246.7930   PASS
quarterly survey: cost from 58                                                              239.4775   book   239.4780   PASS
twice as sharp: cost from 58                                                                237.8491   book   237.8490   PASS
both: cost from 58                                                                          235.7649   book   235.7650   PASS
no readings: cost from 58                                                                   256.2771   book   256.2770   PASS
no readings: standard error                                                                   0.0631   book     0.0630   PASS
twin: above the count (workbook)                                                             11.1006   book    11.1010   PASS
twin: above the count, Table 15.3                                                            11.1006   book    11.1000   PASS
twin: above the count, abstract, Step 3, Key Takeaways                                       11.1006   book    11.1000   PASS
twin: margin, Section 15.3 and the board (workbook)                                           1.7000   book     1.7000   PASS
survey read as exact: above the count (workbook)                                             15.9497   book    15.9500   PASS
survey read as exact: above the count, Table 15.3                                            15.9497   book    15.9500   PASS
survey read as exact: above the count, Step 3                                                15.9497   book    15.9000   PASS
abstract: the twin costs less than the survey read as exact (workbook)                        4.8491   book     4.8000   PASS
quarterly survey: above the count (workbook)                                                  8.6338   book     8.6340   PASS
quarterly survey: above the count, Table 15.3                                                 8.6338   book     8.6300   PASS
quarterly survey: above the count, Step 4                                                     8.6338   book     8.6000   PASS
twice as sharp: above the count (workbook)                                                    7.0054   book     7.0050   PASS
twice as sharp: above the count, Table 15.3                                                   7.0054   book     7.0100   PASS
twice as sharp: above the count, Step 4                                                       7.0054   book     7.0000   PASS
both: above the count (workbook)                                                              4.9212   book     4.9210   PASS
both: above the count, Table 15.3                                                             4.9212   book     4.9200   PASS
both: above the count, Step 4                                                                 4.9212   book     4.9000   PASS
no readings: above the count (workbook)                                                      25.4333   book    25.4330   PASS
no readings: above the count, Table 15.3                                                     25.4333   book    25.4300   PASS
no readings: above the count, Step 3                                                         25.4333   book    25.4000   PASS
twin at Chapter 7's 55.75: above the count (workbook)                                        16.3134   book    16.3130   PASS
twin at Chapter 7's 55.75: Table 15.3                                                        16.3134   book    16.3100   PASS
twin at Chapter 7's 55.75: Section 15.3 and Step 3                                           16.3134   book    16.3000   PASS
survey as exact at 55.75: above the count (workbook)                                         27.5087   book    27.5090   PASS
survey as exact at 55.75: Table 15.3                                                         27.5087   book    27.5100   PASS
survey as exact at 55.75: Step 3                                                             27.5087   book    27.5000   PASS
survey as exact at 60.75: above the count (workbook)                                         34.3961   book    34.3960   PASS
survey as exact at 60.75: Table 15.3                                                         34.3961   book    34.4000   PASS
survey as exact at 60.75: Step 3                                                             34.3961   book    34.4000   PASS
count: below the floor, %                                                                     6.0240   book     6.0000   PASS
twin: below the floor, %                                                                     13.3749   book    13.4000   PASS
survey read as exact: below the floor, %                                                     13.2533   book    13.3000   PASS
quarterly survey: below the floor, %                                                         12.9642   book    13.0000   PASS
twice as sharp: below the floor, %                                                           12.0904   book    12.1000   PASS
both: below the floor, %                                                                     12.2204   book    12.2000   PASS
no readings: below the floor, %                                                              17.6171   book    17.6000   PASS
twin at 55.75: below the floor, %                                                            31.3203   book    31.3000   PASS
twin at 55.75: below the floor, %, Section 15.3 and Step 3                                   31.3203   book    31.0000   PASS
survey as exact at 55.75: below the floor, %                                                 38.6066   book    38.6000   PASS
survey as exact at 60.75: below the floor, %                                                  0.2198   book     0.2000   PASS
Proposition 15.2(i): the chosen targets cost less on their design paths than on fresh ones      1.0000   book     1.0000   PASS
Proposition 15.2(ii): common paths tell neighbouring targets apart better                     1.0000   book     1.0000   PASS
Step 6: the design-path cost is within two standard errors of the fresh                       1.0000   book     1.0000   PASS
Theorem 15.2(i): the count, better surveys, the twin, the survey as exact, no readings, in order of cost      1.0000   book     1.0000   PASS
Theorem 15.2(iii): the count's margin, the swing's quantile (workbook)                        0.7500   book     0.7500   PASS
Chapter 7's critical ratio (workbook)                                                         0.1228   book     0.1228   PASS
the count is worth a year against the twin, Section 15.3 and Step 4 (workbook)                1.0455   book     1.0000   PASS
a quarterly survey is worth a year, Step 4 (workbook)                                         0.2323   book     0.2300   PASS
a survey twice as sharp is worth a year, Step 4 (workbook)                                    0.3857   book     0.3900   PASS
both are worth a year, Step 4 (workbook)                                                      0.5820   book     0.5800   PASS
readings study, twice a year, error 0.5: best target                                         56.1000   book    56.1000   PASS
readings study, twice a year, error 1.0: best target                                         56.3000   book    56.3000   PASS
readings study, twice a year, error 1.25: best target                                        56.4000   book    56.4000   PASS
readings study, twice a year, error 1.5: best target                                         56.4500   book    56.4500   PASS
readings study, twice a year, error 2.0: best target                                         56.6000   book    56.6000   PASS
readings study, twice a year, error 2.5: best target                                         56.7000   book    56.7000   PASS
readings study, twice a year, error 3.0: best target                                         56.8000   book    56.8000   PASS
readings study, twice a year, error 4.0: best target                                         57.0000   book    57.0000   PASS
readings study, twice a year, error 5.0: best target                                         57.1000   book    57.1000   PASS
readings study, quarterly, error 0.5: best target                                            55.9000   book    55.9000   PASS
readings study, quarterly, error 1.0: best target                                            56.1000   book    56.1000   PASS
readings study, quarterly, error 1.25: best target                                           56.2000   book    56.2000   PASS
readings study, quarterly, error 1.5: best target                                            56.2500   book    56.2500   PASS
readings study, quarterly, error 2.0: best target                                            56.4000   book    56.4000   PASS
readings study, quarterly, error 2.5: best target                                            56.5000   book    56.5000   PASS
readings study, quarterly, error 3.0: best target                                            56.6000   book    56.6000   PASS
readings study, quarterly, error 4.0: best target                                            56.7500   book    56.7500   PASS
readings study, quarterly, error 5.0: best target                                            56.9000   book    56.9000   PASS
readings study, twice a year, error 0.5: above the count                                      3.9006   book     3.9000   PASS
readings study, twice a year, error 1.0: above the count                                      6.0042   book     6.0000   PASS
readings study, twice a year, error 1.25: above the count                                     7.0077   book     7.0100   PASS
readings study, twice a year, error 1.5: above the count                                      7.9396   book     7.9400   PASS
readings study, twice a year, error 2.0: above the count                                      9.6302   book     9.6300   PASS
readings study, twice a year, error 2.5: above the count                                     11.0991   book    11.1000   PASS
readings study, twice a year, error 3.0: above the count                                     12.3757   book    12.3800   PASS
readings study, twice a year, error 4.0: above the count                                     14.4745   book    14.4700   PASS
readings study, twice a year, error 5.0: above the count                                     16.1199   book    16.1200   PASS
readings study, quarterly, error 0.5: above the count                                         2.0088   book     2.0100   PASS
readings study, quarterly, error 1.0: above the count                                         4.0025   book     4.0000   PASS
readings study, quarterly, error 1.25: above the count                                        4.9223   book     4.9200   PASS
readings study, quarterly, error 1.5: above the count                                         5.7756   book     5.7800   PASS
readings study, quarterly, error 2.0: above the count                                         7.2992   book     7.3000   PASS
readings study, quarterly, error 2.5: above the count                                         8.6283   book     8.6300   PASS
readings study, quarterly, error 3.0: above the count                                         9.8097   book     9.8100   PASS
readings study, quarterly, error 4.0: above the count                                        11.8254   book    11.8300   PASS
readings study, quarterly, error 5.0: above the count                                        13.4683   book    13.4700   PASS
readings study: every best target inside its window                                           1.0000   book     1.0000   PASS
unmonitored under the drift: bias just after a survey (workbook)                              2.2099   book     2.2100   PASS
unmonitored under the drift: bias just before the next (workbook)                             3.0883   book     3.0880   PASS
unmonitored under the drift: innovations' mean, sd (workbook)                                -1.0450   book    -1.0450   PASS
Section 15.4: overestimates by about, after                                                   2.2099   book     2.2000   PASS
Section 15.4: and before                                                                      3.0883   book     3.1000   PASS
calibration: false alarms a survey at 1.5                                                     0.0471   book     0.0471   PASS
calibration: false alarms a survey at 1.75                                                    0.0347   book     0.0347   PASS
calibration: false alarms a survey at 2.0                                                     0.0258   book     0.0258   PASS
calibration: false alarms a survey at 2.25                                                    0.0192   book     0.0192   PASS
calibration: false alarms a survey at 2.5                                                     0.0145   book     0.0145   PASS
calibration: false alarms a survey at 3.0                                                     0.0084   book     0.0084   PASS
calibration: one false alarm in so many years at 1.5 (workbook)                              10.6107   book    10.6000   PASS
calibration: one false alarm in so many years at 1.75 (workbook)                             14.4150   book    14.4000   PASS
calibration: one false alarm in so many years at 2.0 (workbook)                              19.4109   book    19.4000   PASS
calibration: one false alarm in so many years at 2.25 (workbook)                             26.0010   book    26.0000   PASS
calibration: one false alarm in so many years at 2.5 (workbook)                              34.4719   book    34.5000   PASS
calibration: one false alarm in so many years at 3.0 (workbook)                              59.8041   book    59.8000   PASS
the threshold (workbook)                                                                      2.2500   book     2.2500   PASS
a false alarm about once in so many years, Section 15.4 and Step 5                           26.0010   book    26.0000   PASS
Remark 15.B.1: the count raises its target under the drift to                                56.2500   book    56.2500   PASS
drift: the count, cost from 58                                                              301.9919   book   301.9920   PASS
drift: the count, Step 5                                                                    301.9919   book   302.0000   PASS
drift: the count, below the floor, %                                                         14.0680   book    14.1000   PASS
drift: law never questioned, cost from 58                                                   358.4647   book   358.4650   PASS
drift: law never questioned, above the count (workbook)                                      56.4728   book    56.4700   PASS
drift: law never questioned, above the count, Step 5                                         56.4728   book    56.5000   PASS
drift: law never questioned, below the floor, %                                              79.8706   book    79.9000   PASS
drift: law never questioned, below, %, Section 15.4 and Step 5                               79.8706   book    80.0000   PASS
drift: with the monitor, cost from 58                                                       320.1690   book   320.1690   PASS
drift: with the monitor, above the count (workbook)                                          18.1772   book    18.1800   PASS
drift: with the monitor, above the count, Step 5                                             18.1772   book    18.2000   PASS
drift: with the monitor, below the floor, %                                                  14.4315   book    14.4000   PASS
drift: told of the drift, cost from 58                                                      312.2846   book   312.2850   PASS
drift: told of the drift, above the count (workbook)                                         10.2927   book    10.2900   PASS
drift: told of the drift, above the count, Step 5                                            10.2927   book    10.3000   PASS
drift: told of the drift, below the floor, %                                                 14.5532   book    14.6000   PASS
drift: detected on every path, share                                                          1.0000   book     1.0000   PASS
drift: delay, median quarters (workbook)                                                     12.0000   book    12.0000   PASS
drift: delay, 10th percentile (workbook)                                                      4.0000   book     4.0000   PASS
drift: delay, 90th percentile (workbook)                                                     22.0000   book    22.0000   PASS
drift: delay, mean (workbook)                                                                12.2681   book    12.3000   PASS
abstract and Section 15.4: a median of 12 quarters                                           12.0000   book    12.0000   PASS
no drift: the monitored twin, cost from 58                                                  241.6379   book   241.6380   PASS
no drift: the twin without a monitor, cost from 58                                          241.8370   book   241.8370   PASS
no drift: audits in 120 years                                                                 4.6057   book     4.6000   PASS
Theorem 15.3(i): the correct twin's innovations, mean 0 (within 0.01)                         1.0000   book     1.0000   PASS
Theorem 15.3(i): the correct twin's innovations, sd 1 (within 0.01)                           1.0000   book     1.0000   PASS
Theorem 15.3(i): the correct twin's innovations, uncorrelated (within 0.01)                   1.0000   book     1.0000   PASS
Theorem 15.3(i): under the drift the innovations' mean settles at the formula's (within 0.01)      1.0000   book     1.0000   PASS
Proposition 15.3(ii): the guardrail, breaches on the fresh paths                              0.0000   book     0.0000   PASS
Section 15.5: least sure just before a survey                                                 1.5761   book     1.5800   PASS
Section 15.5: most sure just after it                                                         1.3333   book     1.3300   PASS
Proposition 15.3(i): the rule's and the filter's modes inside the unit circle (workbook)      1.0000   book     1.0000   PASS
LOS 15.3: the twin's target                                                                  56.7000   book    56.7000   PASS
the board: Chapter 7's margin                                                                 0.7500   book     0.7500   PASS

202 of 202 checkpoints PASS

Next. This chapter kept a declared model running: it synchronized the twin with the readings, sized its margin to its error, priced better readings, gave it a monitor, and declared the envelope inside which it acts alone. Chapter 16, Enterprise Applications and Integrated Transformation Case Studies, opens Part V, Applications and Synthesis: its Worked Example 16.1 asks Can Meridian Run Its Whole Program? AXIOM-15 runs the same twin interactively (Lab 2.15); this notebook and the workbook are its reproducible record.

Dynamic Corporate Transformation — Volume I: Foundations and Mathematical Framework; Volume II: Enterprise Optimization & Applications
Jump to any chapter

Volume I: Foundations and Mathematical Framework

  1. Ch. 1Introduction to Dynamic Corporate Transformation
  2. Ch. 2Enterprise Systems and Transformation
  3. Ch. 3Mathematical Foundations
  4. Ch. 4Enterprise Modeling Principles
  5. Ch. 5Enterprise State Representation
  6. Ch. 6Enterprise Transformation Operators
  7. Ch. 7Dynamic Enterprise Systems
  8. Ch. 8Stochastic Enterprise Dynamics
  9. Ch. 9Enterprise State Architecture
  10. Ch. 10Enterprise Capital Architecture
  11. Ch. 11Enterprise Performance Architecture
  12. Ch. 12Enterprise Risk, Resilience, and Robustness Architecture
  13. Ch. 13Unified Enterprise Transformation Architecture
  14. Ch. 14Mathematical Analysis of the Unified Enterprise Transformation Architecture
  15. Ch. 15Mathematical Formulation of Enterprise Optimization
  16. Ch. 16Synthesis, Future Directions, and Transition to Volume II

Volume II: Enterprise Optimization & Applications

  1. Ch. 1Introduction to Enterprise Optimization
  2. Ch. 2The General Enterprise Optimization Problem Revisited
  3. Ch. 3Convex Enterprise Optimization
  4. Ch. 4Nonlinear and Mixed-Integer Enterprise Optimization
  5. Ch. 5Dynamic Enterprise Optimization
  6. Ch. 6Optimal Control of Enterprise Systems
  7. Ch. 7Dynamic Programming for Enterprise Systems
  8. Ch. 8Hamilton–Jacobi–Bellman Enterprise Framework
  9. Ch. 9Stochastic Enterprise Optimization
  10. Ch. 10Neuro-Fuzzy Robust Enterprise Optimization
  11. Ch. 11Distributionally Robust Enterprise Optimization
  12. Ch. 12Multi-Objective Enterprise Optimization
  13. Ch. 13Machine Learning for Enterprise Transformation
  14. Ch. 14Artificial Intelligence for Enterprise Optimization
  15. Ch. 15Enterprise Digital Twins and Autonomous Enterprise Transformation
  16. Ch. 16Enterprise Applications and Integrated Transformation Case Studies

Dynamic Corporate Transformation

Springer Nature · Management for Professionals · Forthcoming 2027

  • Volume I — Foundations and Mathematical Framework
  • Volume II — Enterprise Optimization & Applications
Buy Volume I: Dynamic Corporate Transformation: Foundations and Mathematical FrameworkBuy Volume II: Dynamic Corporate Transformation: Enterprise Optimization & Applications
Jump to any chapter

Volume I: Foundations and Mathematical Framework

  1. Ch. 1Introduction to Dynamic Corporate Transformation
  2. Ch. 2Enterprise Systems and Transformation
  3. Ch. 3Mathematical Foundations
  4. Ch. 4Enterprise Modeling Principles
  5. Ch. 5Enterprise State Representation
  6. Ch. 6Enterprise Transformation Operators
  7. Ch. 7Dynamic Enterprise Systems
  8. Ch. 8Stochastic Enterprise Dynamics
  9. Ch. 9Enterprise State Architecture
  10. Ch. 10Enterprise Capital Architecture
  11. Ch. 11Enterprise Performance Architecture
  12. Ch. 12Enterprise Risk, Resilience, and Robustness Architecture
  13. Ch. 13Unified Enterprise Transformation Architecture
  14. Ch. 14Mathematical Analysis of the Unified Enterprise Transformation Architecture
  15. Ch. 15Mathematical Formulation of Enterprise Optimization
  16. Ch. 16Synthesis, Future Directions, and Transition to Volume II

Volume II: Enterprise Optimization & Applications

  1. Ch. 1Introduction to Enterprise Optimization
  2. Ch. 2The General Enterprise Optimization Problem Revisited
  3. Ch. 3Convex Enterprise Optimization
  4. Ch. 4Nonlinear and Mixed-Integer Enterprise Optimization
  5. Ch. 5Dynamic Enterprise Optimization
  6. Ch. 6Optimal Control of Enterprise Systems
  7. Ch. 7Dynamic Programming for Enterprise Systems
  8. Ch. 8Hamilton–Jacobi–Bellman Enterprise Framework
  9. Ch. 9Stochastic Enterprise Optimization
  10. Ch. 10Neuro-Fuzzy Robust Enterprise Optimization
  11. Ch. 11Distributionally Robust Enterprise Optimization
  12. Ch. 12Multi-Objective Enterprise Optimization
  13. Ch. 13Machine Learning for Enterprise Transformation
  14. Ch. 14Artificial Intelligence for Enterprise Optimization
  15. Ch. 15Enterprise Digital Twins and Autonomous Enterprise Transformation
  16. Ch. 16Enterprise Applications and Integrated Transformation Case Studies
