DCT Laboratory — Volume II, Chapter 16
Enterprise Applications and Integrated Transformation Case Studies
This laboratory demonstrates
Seed 26216 · Companion to Chapter 16 and AXIOM Lab 2.16 (module AXIOM-16) · Mirrored in DCT_V2_Ch16_Lab.xlsx
This laboratory reproduces Worked Example 16.1, Can Meridian Run Its Whole Program?, with the book's declarations, and works the five steps of AXIOM Lab 2.16: check jointly, order, price, keep a choice open, and certify. The pieces are those Volume II certified one chapter at a time: the build's law and levers (Volume I's law on Chapter 9's 100,000 paths, drawn from Volume I, Chapter 8's stream with seed 8, and checked on the book's 100,000 fresh paths, seed 26209), the sale with the engineers kept, Chapter 5's automation program, Chapter 11's family of laws (its extra closures from seed 1108) and Volume I's feedback core. The new declarations put them on one account (Online Appendix Remark 16.B.1). The book's full search over 64 schedules of rounds, payouts and packages takes minutes; this notebook evaluates the printed programs exactly, each cheapest package a quantile of the paths' critical depths, and confirms that they are best nearby. The lab's own seed, 26216, draws only Panel 6's 100,000 new paths. The cells take about a minute on two cores. Every Meridian number below is the book's (Tables 16.1 and 16.3, Figures 16.1–16.3, Online Appendix Example 16.B.2); the final cell checks them. Money is in $ million.
The declarations (Worked Example 16.1, Step 1; Table 16.1; Online Appendix Remark 16.B.1)
The pieces, as their chapters declared them (Table 16.1). The build and its package (Volume I, Worked Example 15.1; Chapters 1, 4, 9–11, 13). Volume I's plan of liquidity over the build's twelve quarters is the plan without the draw, , less a draw of depth index points with shape , $6.2 million a point at its deepest, two years in. Execution deviations move it, with spread $50 million a quarter, and funding windows close at 0.10 a year, each removing a gamma-distributed amount (mean $120 million, standard deviation $50 million) that is never recovered. Two levers: a standby line that covers up to of each closure, for fees of over the program, and quarters of committed delay, , at $8 million a quarter. The board's appetite: at most a 5 percent chance that liquidity falls below the $350 million floor in some quarter of the build. Volume I's package, a $170 million line and 0.668 quarter, $10.44 million, keeps it for the build alone. The sale (Volume I, Worked Example 3.1; Chapters 6–7): $112 million with the shared engineering team, $92 million if Meridian keeps it; Chapters 6–7 priced keeping the team at $23.8 million against the buyer's $20 million discount, so the sale keeps the engineers. The automation rounds and payouts (Volume I, Worked Example 6.1; Chapters 2–5, 12): a round costs $120 million at the start of its year and halves the gap from efficiency 71 to the ceiling of 85, each point saving $10 million a year; cash stays at or above $350 million at year ends, $470 million before a round and $470 million at the end of year 6; the program's value is the payouts at the 10 percent hurdle rate plus the year-6 savings forever (Chapter 5). The capability rule and twin (Chapters 6–8, 14–15) keep capability at or above 55, which the build and the rounds need; each round retrains staff and adds a point.
The new declarations (Worked Example 16.1, Step 1). One account (the treasury): liquidity is Volume I's plan for the build plus the automation program's cash and the sale's proceeds, at the end of quarter , where is the closures the line leaves uncovered, the sale's proceeds and the automation program's cash so far. Volume I's Worked Example 6.1 had assumed the rest of Meridian's cash flows left liquidity unchanged. Timing (the COO and the CFO): a round is paid at the start of its year, savings accrue evenly over the year, and a payout is made at the year's end, after the quarter's reading, so it first counts the next quarter. The sale (the board) closes at the start, with the engineers kept: . The appetite (the board) still counts the build's twelve quarters; after the build (years 4–6) the automation program keeps Chapter 5's commitments on the planned path, with Volume I's plan continued by its own shapes and the delayed spending caught up (depth 28 from year 4). The value (the board): Chapter 5's, with and the year-6 savings, less the levers' cost .
How a program is checked (Remark 16.B.1). For a line and a program's cash , a path keeps the floor in every quarter exactly when the draw is no deeper than the path's critical depth, . The chance of a breach is a count over the paths, and the least delay that meets an appetite is a quantile of the critical depths, as in Chapter 9. The cheapest package tries lines every $20 million up to $400 million, then every $5 million within $15 million of the best.
Python Code
import itertools
import math
import time
import numpy as np
from scipy import stats
import matplotlib.pyplot as plt
plt.rcParams.update({"figure.dpi": 110, "axes.spines.top": False, "axes.spines.right": False})
T_START = time.time()
SEED = 26216 # the lab's seed: it draws only Panel 6's 100,000 new paths
BOOK_SEED = 8 # Volume I, Chapter 8's stream: the book's 100,000 paths (Chapter 9)
FRESH_SEED = 26209 # the book's 100,000 fresh paths, on which every answer is checked
EXTRA_SEED = 1108 # Chapter 11's family on the book's paths: the extra closures and the thinning uniforms
N, Q = 100_000, 12 # paths; quarters of the build
# Volume I's law (Chapter 8) in USD billion, exactly as its engine draws it; every result is reported in $ million
A_E, SD_W = 0.6, 0.05 # execution deviations E' = 0.6 E + w, w with spread $50m a quarter
LAM, J_MEAN, J_SD = 0.10, 0.12, 0.05 # funding-window closures a year; gamma sizes, mean $120m and sd $50m
GAMMA = ((J_MEAN / J_SD) ** 2, J_SD ** 2 / J_MEAN) # the sizes' shape and scale
LAM_MAX = 0.40 # Chapter 11: the rate ceiling of the extra closures
# the build's levers and the board's appetite (Volume I, Worked Example 15.1; Chapter 9)
FLOOR, LIQ0 = 350.0, 620.0 # the floor; liquidity today
ROOM = LIQ0 - FLOOR # the room above the floor
DEPTH0, DPQ = 28.0, 4.0 # the draw's depth (index points); a quarter of delay makes it 4 points shallower
FEE, VQ, ALPHA = 0.03, 8.0, 0.05 # line fees over the program; a quarter of delay; the appetite
PKG_VOL1 = (170.0, 0.667576361426625) # Volume I's package, as Chapter 9 designed it on the book's paths
# the sale (Volume I, Worked Example 3.1; Chapters 6-7) and Chapter 5's automation program
SALE = 112.0 - 20.0 # the sale's proceeds with the engineers kept
ROUND, E0, CEIL, VAL = 120.0, 71.0, 85.0, 10.0 # a round's cost; efficiency today; its ceiling; savings a point a year
PRE, END = 470.0, 470.0 # cash before a round; cash at the end of year 6
R = 0.10 # the board's hurdle rate
BY = 1.0 / (1.0 + R) # a year's discount
CAP_PRICE = 0.975 * 4.0 # Chapter 7: a point of capability on the floor, in hiring
CLOSURE_P90 = 1000.0 * stats.gamma.ppf(0.9, GAMMA[0], scale=GAMMA[1]) # Volume I's closure buffer, the 90th percentile
def relax(x0, x_inf, k, t):
return x_inf + (x0 - x_inf) * np.exp(-k * t)
def trough(depth, tau, t):
return depth * (t / tau) * np.exp(1.0 - t / tau)
TQ = np.arange(1, Q + 1) / 4.0 # the twelve quarters, in years
BASE = (0.62 * relax(100.0, 112.0, 0.35, TQ) / 100.0) * 1000.0 # Volume I's plan without the draw (index 100 = $620m)
SHAPE = (0.62 * trough(1.0, 2.0, TQ) / 100.0) * 1000.0 # the draw per index point of depth
INV_SHAPE = 1.0 / SHAPE
def plan_level(t, depth=DEPTH0):
# Volume I's planned liquidity t years from now, continued by its own shapes
return 1000.0 * 0.62 * (relax(100.0, 112.0, 0.35, t) - trough(depth, 2.0, t)) / 100.0
B_YEARS = [plan_level(float(j)) for j in range(7)] # year ends 0-6 on the planned path, depth 28 after the build
def draws(seed, n=N):
# Volume I's stream in its order: each quarter the execution shocks, the closure counts, then the sizes path by path
rng = np.random.default_rng(seed)
W, events = np.empty((n, Q)), []
for k in range(Q):
W[:, k] = rng.normal(0.0, SD_W, n)
count = rng.poisson(LAM / 4.0, n)
events.append((np.repeat(np.arange(n), count), rng.gamma(*GAMMA, int(count.sum()))))
E, e = np.zeros((n, Q)), np.zeros(n)
for k in range(Q):
e = A_E * e + W[:, k]
E[:, k] = e
return E, events
def cost(line, phi):
return FEE * line + VQ * phi
class Paths:
# The paths of one law, with the one-account check of Remark 16.B.1. For a line and a program's cash G + A_k a path
# keeps the floor in every quarter exactly when the depth is at most its critical depth, so chances are exact counts
# and the least delay meeting an appetite is a quantile of the critical depths.
def __init__(self, E, events, seed):
self.E, self.events, self.seed, self.n = E, events, seed, E.shape[0]
@classmethod
def draw(cls, seed, n=N):
return cls(*draws(seed, n), seed)
def lost(self, line): # cumulative closures the line does not cover (USD bn), quarter by quarter
J, j = np.zeros((self.n, Q)), np.zeros(self.n)
for k, (path, size) in enumerate(self.events):
j = j + np.bincount(path, np.maximum(size - line / 1000.0, 0.0), self.n)
J[:, k] = j
return J
def ratio(self, line): # (plan without the draw + deviations - uncovered closures - floor) / shape
return (BASE[None, :] + 1000.0 * (self.E - self.lost(line)) - FLOOR) * INV_SHAPE[None, :]
def crit(self, line, A, G): # each path's critical depth with the program's cash G + A_k
return np.min(self.ratio(line) + ((A + G) * INV_SHAPE)[None, :], axis=1)
def depth_for(self, line, A, G, p=ALPHA):
c = self.crit(line, A, G)
j = int(np.floor(p * c.size + 1e-9))
return min(DEPTH0, float(np.partition(c, j)[j]))
def chance(self, line, phi, A, G): # the chance of a breach in some quarter of the build
return float(np.mean(self.crit(line, A, G) < DEPTH0 - DPQ * phi))
def liquidity(self, line, phi, A, G): # every path's liquidity at each quarter end ($m)
return BASE[None, :] - (DEPTH0 - DPQ * phi) * SHAPE[None, :] + 1000.0 * (self.E - self.lost(line)) + G + A[None, :]
def cheapest(self, A, G, p=ALPHA, coarse=20.0, fine=5.0):
# the cheapest committed package keeping the appetite p: (cost, line, delay), or None
best = None
def try_line(line):
nonlocal best
d = self.depth_for(line, A, G, p)
if d < 0:
return
phi = (DEPTH0 - d) / DPQ
if best is None or cost(line, phi) < best[0] - 1e-12:
best = (float(cost(line, phi)), float(line), float(phi))
for line in np.arange(0.0, 400.01, coarse):
try_line(line)
if best is None:
return None
l0 = best[1]
for line in np.arange(max(0.0, l0 - coarse + fine), min(400.0, l0 + coarse - fine) + 1e-9, fine):
try_line(line)
return best
# Chapter 5's automation program
def efficiency(z):
e, out = E0, []
for zk in z:
if zk:
e = e + 0.5 * (CEIL - e)
out.append(e)
return np.array(out)
def savings(z):
return VAL * (efficiency(z) - E0)
def war_chest(z, S):
# the least year-end cash from which the rest of the schedule keeps every commitment with no further payout
T = len(z)
W_ = np.empty(T + 1)
W_[T] = max(END, FLOOR)
for j in range(T, 0, -1):
need = W_[j] + ROUND * z[j - 1] - S[j - 1]
if z[j - 1]:
need = max(need, PRE)
if j - 1 >= 1:
need = max(need, FLOOR)
W_[j - 1] = need
return W_
def ch5_plan(z, q0=LIQ0):
# Chapter 5 on its own account: pay out everything above the war chest
S = savings(z)
W_ = war_chest(z, S)
q, pays, qs, ok = q0, [], [], q0 >= W_[0] - 1e-9
for j in range(1, len(z) + 1):
if z[j - 1] and q < PRE - 1e-9:
ok = False
q = q - ROUND * z[j - 1] + S[j - 1]
p = max(0.0, q - W_[j])
q -= p
pays.append(p); qs.append(q)
ok = ok and q >= FLOOR - 1e-9
ok = ok and q >= END - 1e-9
val = sum(BY ** (k + 1) * pays[k] for k in range(len(z))) + BY ** len(z) * S[-1] / R
return ok, np.array(pays), np.array(qs), W_, float(val)
# the program on one account
def automation_profile(z, p1, p2):
# the automation program's cash at the end of quarters 1-12: rounds at year starts, savings evenly over the year,
# payouts at year ends after the reading (they count from the next quarter)
S = savings(z)
A, cum, pays = np.zeros(Q), 0.0, (p1, p2, 0.0)
for j in range(3):
for mq in range(4):
A[4 * j + mq] = cum - ROUND * z[j] + (mq + 1) * S[j] / 4.0
cum = cum - ROUND * z[j] + S[j] - pays[j]
return A
def post_window(z, p1, p2, G, G_late=0.0):
# years 3-6 on the planned path: the war chest and the payouts p3..p6; None if a commitment fails
S, B = savings(z), B_YEARS
W_ = np.zeros(7)
W_[6] = END
for j in range(6, 3, -1):
need = W_[j] + ROUND * z[j - 1] - S[j - 1] - (B[j] - B[j - 1]) - (G_late if j == 4 else 0.0)
if z[j - 1]:
need = max(need, PRE)
W_[j - 1] = max(need, FLOOR)
cash = B[3] + G + sum(-ROUND * z[i] + S[i] for i in range(3)) - p1 - p2
pays, qs = [], []
for j in range(3, 7):
if j > 3:
if z[j - 1] and cash < PRE - 1e-9:
return None
cash = cash - ROUND * z[j - 1] + S[j - 1] + (B[j] - B[j - 1]) + (G_late if j == 4 else 0.0)
pj = max(0.0, cash - W_[j])
cash -= pj
pays.append(pj); qs.append(cash)
if cash < FLOOR - 1e-9:
return None
if cash < END - 1e-9:
return None
return pays, qs, W_
def value(z, p1, p2, levers, G, G_late=0.0):
# the program's value: payouts at 10 percent plus the year-6 savings forever, less the levers; (value, payouts)
S = savings(z)
pw = post_window(z, p1, p2, G, G_late)
if pw is None:
return None
pays = [p1, p2] + pw[0]
return float(sum(BY ** (j + 1) * pays[j] for j in range(6)) + BY ** 6 * S[-1] / R - levers), pays
def margins(z, p1, p2, G, phi):
# planned margin above the floor by quarter: no deviations, no closures
return BASE - (DEPTH0 - DPQ * phi) * SHAPE + G + automation_profile(z, p1, p2) - FLOOR
def claims(z, p1, p2, line, phi, G):
# the deterministic joint check at the binding quarter: the claims on the room above the floor
mg = margins(z, p1, p2, G, phi)
k = int(np.argmin(mg))
build = LIQ0 - (BASE[k] - (DEPTH0 - DPQ * phi) * SHAPE[k])
paid = (p1 if k >= 4 else 0.0) + (p2 if k >= 8 else 0.0)
rounds = -(automation_profile(z, p1, p2)[k] + paid)
buffer = max(CLOSURE_P90 - line, 0.0)
return dict(quarter=k + 1, build=build, rounds=rounds, payouts=paid, buffer=buffer, room=ROOM + G,
left=ROOM + G - build - rounds - paid - buffer)
def rounds_of(z):
return ", ".join(str(k + 1) for k in range(6) if z[k])
BOOK, FRESH = Paths.draw(BOOK_SEED), Paths.draw(FRESH_SEED)
NO_CASH = np.zeros(Q)
print(f"Volume I's plan without the draw: {BASE[0]:.1f} at quarter 1 rising to {BASE[-1]:.1f} at quarter 12, relaxing "
f"toward {1000 * 0.62 * 112 / 100:.1f}; the draw {SHAPE.max():.2f} a point at its deepest (quarter {SHAPE.argmax() + 1})")
print(f"the book's paths (seed {BOOK_SEED}): {sum(len(p) for p, _ in BOOK.events):,} closures on 100,000 paths; the fresh "
f"paths (seed {FRESH_SEED}): {sum(len(p) for p, _ in FRESH.events):,}")
print(f"Volume I's package for the build alone: line {PKG_VOL1[0]:.0f}, delay {PKG_VOL1[1]:.3f}, {cost(*PKG_VOL1):.2f}; "
f"chance of a breach {100 * BOOK.chance(*PKG_VOL1, NO_CASH, 0.0):.2f}% (fresh {100 * FRESH.chance(*PKG_VOL1, NO_CASH, 0.0):.2f}%)")
print(f"Volume I's closure buffer, the 90th-percentile closure: {CLOSURE_P90:.1f}; the room above the floor: {ROOM:.0f}")Volume I's plan without the draw: 626.2 at quarter 1 rising to 668.4 at quarter 12, relaxing toward 694.4; the draw 6.20 a point at its deepest (quarter 8) the book's paths (seed 8): 30,030 closures on 100,000 paths; the fresh paths (seed 26209): 30,181 Volume I's package for the build alone: line 170, delay 0.668, 10.44; chance of a breach 5.00% (fresh 4.91%) Volume I's closure buffer, the 90th-percentile closure: 186.9; the room above the floor: 270
Panel 1 — Declare one program, on one account (Worked Example 16.1, Step 1; Table 16.1; Online Appendix Remark 16.B.1 and Example 16.B.2: Chapter 5's plan alone runs rounds in years 1–3 with payouts 85, 0, 122.5, 122.5, 122.5, 2.5, worth $1,021.93m; the board's price of $5.645 for a dollar a year of savings; the draw $6.2m a point at its deepest, the plan continued toward $694m; the build alone draws $121.6m at quarter 7 against a closure buffer of $16.9m)
Worked Example 16.1, Step 1. Chapter 5's best plan, on its own account, pays out everything above its war chest, the least year-end cash from which the rest of the schedule keeps every commitment with no further payout. On one account the same plan joins Volume I's plan for the build and the sale's proceeds: quarter by quarter, the account holds Volume I's planned liquidity, the automation program's cash so far and the $92 million. After the build the plan continues by its own shapes, toward $694 million. The build alone, with Volume I's package, passes Volume I's joint check at its deepest quarter: the draw and the closure buffer the line leaves uncovered fit the $270 million of room.
Python Code
CH5 = (1, 1, 1, 0, 0, 0) # Chapter 5's best plan: rounds in years 1-3
ok5, PAY5, CASH5, WAR5, V5 = ch5_plan(CH5)
S5 = savings(CH5)
PV5 = sum(BY ** (k + 1) * PAY5[k] for k in range(6))
SAV_PRICE = BY ** 6 / R # the board's price of a dollar a year of savings (Chapter 12)
print("Chapter 5's plan alone, on an account where the rest of Meridian's cash flows leave liquidity unchanged:")
print(" year " + "".join(f"{j:9d}" for j in range(1, 7)))
print(" round " + "".join(f"{'yes' if z else '-':>9s}" for z in CH5))
print(" efficiency " + "".join(f"{x:9.2f}" for x in efficiency(CH5)))
print(" savings " + "".join(f"{x:9.1f}" for x in S5))
print(" war chest " + "".join(f"{x:9.1f}" for x in WAR5[1:]))
print(" payout " + "".join(f"{x:9.1f}" for x in PAY5))
print(" year-end cash " + "".join(f"{x:9.1f}" for x in CASH5))
print(f" value {V5:,.2f} = payouts {PV5:.2f} + the year-6 savings forever {BY ** 6 * S5[-1] / R:.2f} "
f"(feasible: {ok5}); a dollar a year of savings is worth beta^6/0.10 = {SAV_PRICE:.3f}")
A5 = automation_profile(CH5, PAY5[0], PAY5[1])
D_PKG = DEPTH0 - DPQ * PKG_VOL1[1]
plan_pkg = BASE - D_PKG * SHAPE
print(f"\none account, quarter by quarter: Chapter 5's plan with the sale and Volume I's package (depth {D_PKG:.2f}):")
print(" quarter " + "".join(f"{k:7d}" for k in range(1, 13)))
print(" plan without the draw " + "".join(f"{x:7.1f}" for x in BASE))
print(" draw per point of depth " + "".join(f"{x:7.2f}" for x in SHAPE))
print(" Volume I's planned path " + "".join(f"{x:7.1f}" for x in plan_pkg))
print(" automation cash so far " + "".join(f"{x:7.1f}" for x in A5))
print(" one account, with the sale " + "".join(f"{x:7.1f}" for x in plan_pkg + A5 + SALE))
print(f"Volume I's plan at the year ends 0-6 (depth 28): " + ", ".join(f"{x:.1f}" for x in B_YEARS)
+ f"; it relaxes toward {1000 * 0.62 * 112 / 100:.1f}")
k7 = int(np.argmin(plan_pkg))
BUILD_ALONE = dict(quarter=k7 + 1, draw=LIQ0 - plan_pkg[k7], buffer=max(CLOSURE_P90 - PKG_VOL1[0], 0.0))
print(f"the build alone: its deepest draw {BUILD_ALONE['draw']:.1f} at quarter {BUILD_ALONE['quarter']}, plus the closure "
f"buffer the line leaves uncovered {BUILD_ALONE['buffer']:.1f}, is {BUILD_ALONE['draw'] + BUILD_ALONE['buffer']:.1f} "
f"of the {ROOM:.0f} of room (Volume I's joint check)")Chapter 5's plan alone, on an account where the rest of Meridian's cash flows leave liquidity unchanged: year 1 2 3 4 5 6 round yes yes yes - - - efficiency 78.00 81.50 83.25 83.25 83.25 83.25 savings 70.0 105.0 122.5 122.5 122.5 122.5 war chest 485.0 470.0 350.0 350.0 350.0 470.0 payout 85.0 0.0 122.5 122.5 122.5 2.5 year-end cash 485.0 470.0 350.0 350.0 350.0 470.0 value 1,021.93 = payouts 330.45 + the year-6 savings forever 691.48 (feasible: True); a dollar a year of savings is worth beta^6/0.10 = 5.645 one account, quarter by quarter: Chapter 5's plan with the sale and Volume I's package (depth 25.33): quarter 1 2 3 4 5 6 7 8 9 10 11 12 plan without the draw 626.2 631.9 637.2 642.0 646.4 650.4 654.1 657.5 660.5 663.4 666.0 668.4 draw per point of depth 1.86 3.28 4.34 5.11 5.64 5.97 6.15 6.20 6.16 6.04 5.86 5.64 Volume I's planned path 579.1 548.8 527.2 512.5 503.6 499.2 498.4 500.4 504.6 510.5 517.6 525.5 automation cash so far -102.5 -85.0 -67.5 -50.0 -228.8 -202.5 -176.2 -150.0 -239.4 -208.8 -178.1 -147.5 one account, with the sale 568.6 555.8 551.7 554.5 366.8 388.7 414.1 442.4 357.3 393.8 431.4 470.0 Volume I's plan at the year ends 0-6 (depth 28): 620.0, 498.9, 483.9, 510.4, 548.3, 584.6, 614.8; it relaxes toward 694.4 the build alone: its deepest draw 121.6 at quarter 7, plus the closure buffer the line leaves uncovered 16.9, is 138.5 of the 270 of room (Volume I's joint check)
Panel 2 — Check jointly (Theorem 16.1(i); Worked Example 16.1, Step 2; Figure 16.1; Table 16.3; Online Appendix Example 16.B.2: signed together, Chapter 5's plan and Volume I's package breach the floor on 74.33% of paths with the sale (fresh 74.20%) and 99.58% without it (fresh 99.57%), 87.29% and 99.90% without levers; the planned margin at quarter 9 is $7.3m and m; the claims at quarter 9, 115.4, 154.4, 85.0 and 16.9, exceed the room of 362 by 9.6, or of 270 by 101.6; keeping the pieces needs a $165m line and 5.634 quarters, $50.02m, and nothing keeps them without the sale; the program's claims 80.8, 154.4, 0 and 26.9 leave 100.0)
AXIOM Lab 2.16, step 1. Sign Chapter 5's plan and Volume I's package together, with the sale, on one account, and read the chance of a breach on the book's paths and the fresh ones. Each piece passed its own check on the whole room: the build keeps 5 percent alone, and Chapter 5's plan keeps its floor on an account where nothing else moves. Together they claim the same room (Theorem 16.1(i)). The joint check at the binding quarter adds the claims on the room above the floor: the build's draw, the rounds less their savings so far, the payouts already made, and the closure buffer the line leaves uncovered. For comparison, the program the Worked Example signs (rounds in years 1–3, payouts held; Panels 3–4 find it best) is checked the same way.
Python Code
SEP = {}
for G in (0.0, SALE):
SEP[G] = dict(chance=BOOK.chance(*PKG_VOL1, A5, G), fresh=FRESH.chance(*PKG_VOL1, A5, G),
no_levers=BOOK.chance(0.0, 0.0, A5, G), margins=margins(CH5, PAY5[0], PAY5[1], G, PKG_VOL1[1]),
cheapest=BOOK.cheapest(A5, G), claims=claims(CH5, PAY5[0], PAY5[1], *PKG_VOL1, G))
for G, lab in ((SALE, "with the sale"), (0.0, "without the sale")):
s = SEP[G]
print(f"pieces as certified, {lab:16s}: breach {100 * s['chance']:.2f}% (fresh {100 * s['fresh']:.2f}%), without "
f"levers {100 * s['no_levers']:.2f}%; least planned margin {s['margins'].min():6.1f} at quarter "
f"{int(np.argmin(s['margins'])) + 1}")
print("planned margin above the floor with the sale, by quarter: " + ", ".join(f"{x:.1f}" for x in SEP[SALE]["margins"]))
KEEP = SEP[SALE]["cheapest"]
print(f"keeping the pieces as certified, with the sale: line {KEEP[1]:.0f}, delay {KEEP[2]:.3f}, levers {KEEP[0]:.2f}, "
f"breach {100 * BOOK.chance(KEEP[1], KEEP[2], A5, SALE):.2f}%")
best_depth = max(BOOK.depth_for(l, A5, 0.0) for l in np.arange(0.0, 400.01, 5.0))
print(f"without the sale no package keeps them (cheapest package: {SEP[0.0]['cheapest']}): even with a $400m line the "
f"draw would have to be {best_depth:.2f} points deep, more than seven quarters of delay can do")
BEST_Z, BEST_P = (1, 1, 1, 0, 0, 0), (0.0, 0.0) # the program the Worked Example signs (Step 4)
A_BEST = automation_profile(BEST_Z, *BEST_P)
PKG_BEST = BOOK.cheapest(A_BEST, SALE)
CLAIMS = dict(pieces_no_sale=SEP[0.0]["claims"], pieces=SEP[SALE]["claims"],
program=claims(BEST_Z, *BEST_P, PKG_BEST[1], PKG_BEST[2], SALE))
print(f"\nthe joint check at the binding quarter (claims on the room above the floor):")
print(f" {'case':22s} {'quarter':>7s} {'build draw':>10s} {'rounds net':>10s} {'payouts':>8s} {'buffer':>7s} "
f"{'room':>6s} {'left':>7s}")
for key, lab in (("pieces_no_sale", "pieces, no sale"), ("pieces", "pieces, with sale"), ("program", "program")):
c = CLAIMS[key]
print(f" {lab:22s} {c['quarter']:7d} {c['build']:10.1f} {c['rounds']:10.1f} {c['payouts']:8.1f} {c['buffer']:7.1f} "
f"{c['room']:6.0f} {c['left']:7.1f}")
print(" with no deviations and no closures the plan itself keeps "
f"{SEP[SALE]['margins'][8]:.1f} above the floor at quarter 9; the closure buffer of {CLAIMS['pieces']['buffer']:.1f} "
f"is what takes the claims {-CLAIMS['pieces']['left']:.1f} past the room")
# Figure 16.1: liquidity on one account (plan and the level 5 percent of paths fall below), and the claims at quarter 9
def liquidity_band(z, p, line, phi, G):
A = automation_profile(z, *p)
L = BOOK.liquidity(line, phi, A, G)
return BASE - (DEPTH0 - DPQ * phi) * SHAPE + G + A, np.quantile(L, 0.05, axis=0)
BANDS = dict(pieces=liquidity_band(CH5, (PAY5[0], PAY5[1]), *PKG_VOL1, SALE),
program=liquidity_band(BEST_Z, BEST_P, PKG_BEST[1], PKG_BEST[2], SALE))
fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6), gridspec_kw={"width_ratios": [1, 1.05]})
q_ = np.arange(1, 13)
for key, col, lab in (("pieces", "#E65100", "pieces as certified"), ("program", "#1F4E79", "program")):
ax.plot(q_, BANDS[key][0], color=col, lw=1.6, label=f"{lab}: plan")
ax.plot(q_, BANDS[key][1], color=col, lw=1.3, ls="--", label=f"{lab}: 5% of paths below")
ax.axhline(FLOOR, color="#999999", lw=0.8, ls=":")
ax.text(12.3, 352, "floor", fontsize=8, color="#616161", ha="right", va="bottom")
ax.set(xlim=(1, 12.4), ylim=(150, 760), xticks=[1, 3, 5, 7, 9, 11], xlabel="quarter of the build",
ylabel="liquidity (\\$ million)")
ax.legend(frameon=False, fontsize=7, loc="upper right", ncol=1)
ax.set_title("(a) one account, with the sale", fontsize=9)
cases = (("pieces_no_sale", "pieces,\nno sale"), ("pieces", "pieces,\nwith sale"), ("program", "program"))
parts = (("build", "#1F4E79", "build's draw"), ("rounds", "#2E7D32", "rounds, net"), ("payouts", "#E65100", "payouts made"),
("buffer", "#9E9E9E", "closure buffer"))
x_, bottom = np.arange(3), np.zeros(3)
for key, col, lab in parts:
v = np.array([CLAIMS[c][key] for c, _ in cases])
bx.bar(x_, v, 0.55, bottom=bottom, color=col, alpha=0.85, label=lab, lw=0)
bottom += v
for room, lab, ls in ((ROOM, "room", ":"), (ROOM + SALE, "room with the sale", "--")):
bx.axhline(room, color="#333333", lw=0.9, ls=ls)
bx.text(2.75, room + 6, f"{lab}: {room:.0f}", fontsize=7.5, color="#333333", ha="right", va="bottom")
bx.set(xticks=x_, xlim=(-0.45, 2.8), ylim=(0, 560), ylabel="claims at quarter 9 (\\$ million)")
bx.set_xticklabels([lab for _, lab in cases], fontsize=8)
bx.legend(frameon=False, fontsize=7, loc="upper left", ncol=2, columnspacing=0.8, handlelength=1.0)
bx.set_title("(b) the joint check at quarter 9", fontsize=9)
fig.suptitle("The pieces fail together; the program fits (seed 26216)", fontsize=10.5)
plt.tight_layout(); plt.show()pieces as certified, with the sale : breach 74.33% (fresh 74.20%), without levers 87.29%; least planned margin 7.3 at quarter 9 pieces as certified, without the sale: breach 99.58% (fresh 99.57%), without levers 99.90%; least planned margin -84.7 at quarter 9 planned margin above the floor with the sale, by quarter: 218.6, 205.8, 201.7, 204.5, 16.8, 38.7, 64.1, 92.4, 7.3, 43.8, 81.4, 120.0 keeping the pieces as certified, with the sale: line 165, delay 5.634, levers 50.02, breach 5.00% without the sale no package keeps them (cheapest package: None): even with a $400m line the draw would have to be -9.68 points deep, more than seven quarters of delay can do the joint check at the binding quarter (claims on the room above the floor): case quarter build draw rounds net payouts buffer room left pieces, no sale 9 115.4 154.4 85.0 16.9 270 -101.6 pieces, with sale 9 115.4 154.4 85.0 16.9 362 -9.6 program 9 80.8 154.4 0.0 26.9 362 100.0 with no deviations and no closures the plan itself keeps 7.3 above the floor at quarter 9; the closure buffer of 16.9 is what takes the claims 9.6 past the room

Panel 3 — Order the moves (Theorem 16.2(i)–(ii); Worked Example 16.1, Step 3; Figure 16.2(a); Table 16.3; Online Appendix Example 16.B.2: rounds in years 1–3 $1,039.41m, years 1, 2, 4 $1,036.80m, 1, 3, 4 $1,022.57m, 1, 4, 5 $1,001.59m, 2–4 $953.58m, 2, 4, 5 $937.60m, 3–5 $883.16m, 4–6 $821.11m; no sale $938.95m with $52.71m of levers, the sale after the build $1,001.79m; the sale first is worth $100.5m, $69.1m paid out at the end of year 3 and $31.3m of levers, $37.6m more than after the build)
AXIOM Lab 2.16, step 2. The sale. Kept with its engineers, the sale only adds cash: capability stays at 58, above the 55 the build and the rounds need, and $92 million commutes with every other move's cash, so by Theorem 16.2(ii) it goes first. Sold with them it would take capability to 53 and its order would matter (Volume I, Worked Example 3.1). The three orders are priced on the book's paths: no sale, the sale after the build (its proceeds arrive in year 4, after the appetite's window), and the sale first. The rounds. For each timing of the three rounds the book's search re-optimizes the payouts of years 1–2 and the package; here each printed program is evaluated exactly at its printed payouts. After the build the payouts follow the war chest on the planned path, and each timing of the first three years is checked against all eight of its continuations in years 4–6: 64 schedules in all.
Python Code
DOMAIN = 55.0
print(f"capability after the sale: engineers kept 58 >= {DOMAIN:.0f}: {58 >= DOMAIN}; sold with them 53 >= {DOMAIN:.0f}: "
f"{53 >= DOMAIN} (Volume I, Worked Example 3.1)")
PRINTED = [((1, 1, 1, 0, 0, 0), 0.0, 0.0), ((1, 1, 0, 1, 0, 0), 0.0, 77.0), ((1, 0, 1, 1, 0, 0), 35.0, 0.0),
((1, 0, 0, 1, 1, 0), 61.0, 65.0), ((0, 1, 1, 1, 0, 0), 0.0, 0.0), ((0, 1, 0, 1, 1, 0), 0.0, 48.0),
((0, 0, 1, 1, 1, 0), 8.0, 0.0), ((0, 0, 0, 1, 1, 1), 64.0, 20.0)] # the printed programs: rounds, payouts y1-2
TAILS = list(itertools.product([0, 1], repeat=3))
PROGRAMS, GRID64 = [], []
for z, p1, p2 in PRINTED:
pk = BOOK.cheapest(automation_profile(z, p1, p2), SALE)
row = []
for zt in TAILS: # every continuation after the build, same package
v = value(tuple(z[:3]) + zt, p1, p2, pk[0], SALE)
row.append(None if v is None else v[0])
GRID64.append(row)
v, pays = value(z, p1, p2, pk[0], SALE)
PROGRAMS.append(dict(z=z, rounds=rounds_of(z), p1=p1, p2=p2, cost=pk[0], line=pk[1], phi=pk[2], value=v, payouts=pays,
best_tail=bool(max(x for x in row if x is not None) <= v + 1e-9)))
BEST = PROGRAMS[0]
print(f"\n{'rounds':10s} {'payouts y1, y2':>15s} {'line':>6s} {'delay':>7s} {'levers':>7s} {'value':>10s} {'below best':>11s}"
f" payouts in years 3-6")
for p in PROGRAMS:
print(f"{p['rounds']:10s} {p['p1']:7.0f} {p['p2']:7.0f} {p['line']:6.0f} {p['phi']:7.3f} {p['cost']:7.2f} "
f"{p['value']:10.2f} {BEST['value'] - p['value']:11.2f} " + ", ".join(f"{x:.1f}" for x in p["payouts"][2:]))
print("\nall 64 schedules at the printed payouts (value; '-' breaks a commitment after the build); rounds after the build:")
print(f"{'years 1-3':10s}" + "".join(f"{('none' if not any(t) else ', '.join(str(4 + i) for i in range(3) if t[i])):>10s}"
for t in TAILS))
for p, row in zip(PROGRAMS, GRID64):
print(f"{rounds_of(tuple(p['z'][:3]) + (0, 0, 0)) or 'none':10s}" + "".join(f"{x:10.2f}" if x is not None else f"{'-':>10s}"
for x in row))
print("each printed timing is the best continuation of its first three years:", all(p["best_tail"] for p in PROGRAMS))
PKG_NOSALE = BOOK.cheapest(A_BEST, 0.0)
NOSALE = value(BEST_Z, *BEST_P, PKG_NOSALE[0], 0.0)
LATE = value(BEST_Z, *BEST_P, PKG_NOSALE[0], 0.0, G_late=SALE)
print(f"\norder of the sale (rounds in years 1-3, payouts held): sale first {BEST['value']:,.2f}; sale after the build "
f"{LATE[0]:,.2f}; no sale {NOSALE[0]:,.2f} (line {PKG_NOSALE[1]:.0f}, delay {PKG_NOSALE[2]:.2f}, levers {PKG_NOSALE[0]:.2f})")
SALE_WORTH = BEST["value"] - NOSALE[0]
print(f"the sale first is worth {SALE_WORTH:.2f}: {SALE:.0f} beta^3 = {SALE * BY ** 3:.2f} paid out at the end of year 3, "
f"plus {PKG_NOSALE[0] - BEST['cost']:.2f} of levers it makes unnecessary; after the build it is worth "
f"{BEST['value'] - LATE[0]:.2f} less: paid out a year later ({SALE * (BY ** 3 - BY ** 4):.2f}) and no levers saved")
print(f"moving round 3 to year 4 costs {BEST['value'] - PROGRAMS[1]['value']:.2f}; starting the rounds in year 2 costs "
f"{BEST['value'] - PROGRAMS[4]['value']:.2f}")capability after the sale: engineers kept 58 >= 55: True; sold with them 53 >= 55: False (Volume I, Worked Example 3.1) rounds payouts y1, y2 line delay levers value below best payouts in years 3-6 1, 2, 3 0 0 160 2.071 21.37 1039.41 0.00 189.9, 160.4, 158.8, 32.7 1, 2, 4 0 77 160 1.477 16.62 1036.80 2.61 95.4, 160.4, 158.8, 32.7 1, 3, 4 35 0 140 0.012 4.29 1022.57 16.84 102.4, 160.4, 158.8, 32.7 1, 4, 5 61 65 140 0.000 4.20 1001.59 37.82 96.4, 22.9, 158.8, 32.7 2, 3, 4 0 0 170 1.259 15.17 953.58 85.83 67.4, 160.4, 158.8, 32.7 2, 4, 5 0 48 155 0.006 4.70 937.60 101.81 104.4, 22.9, 158.8, 32.7 3, 4, 5 8 0 140 0.000 4.20 883.16 156.25 74.4, 22.9, 158.8, 32.7 4, 5, 6 64 20 135 0.000 4.05 821.11 218.30 36.3, 0.0, 21.3, 32.7 all 64 schedules at the printed payouts (value; '-' breaks a commitment after the build); rounds after the build: years 1-3 none 6 5 5, 6 4 4, 6 4, 5 4, 5, 6 1, 2, 3 1039.41 1019.23 1017.21 969.86 1014.99 967.65 962.91 901.98 1, 2 995.48 1029.63 1033.04 1012.86 1036.80 1016.62 1014.60 967.26 1, 3 981.24 1015.39 1018.81 998.63 1022.57 1002.39 1000.37 953.02 1 790.10 933.18 947.49 981.64 964.03 998.18 1001.59 981.41 2, 3 912.25 946.40 949.82 929.64 953.58 933.40 931.38 884.03 2 726.11 869.19 883.50 917.65 900.03 934.18 937.60 917.42 3 671.67 814.76 829.06 863.21 845.60 879.75 883.16 862.98 none 185.47 543.03 584.35 726.49 629.57 772.65 786.96 821.11 each printed timing is the best continuation of its first three years: True order of the sale (rounds in years 1-3, payouts held): sale first 1,039.41; sale after the build 1,001.79; no sale 938.95 (line 165, delay 5.97, levers 52.71) the sale first is worth 100.46: 92 beta^3 = 69.12 paid out at the end of year 3, plus 31.34 of levers it makes unnecessary; after the build it is worth 37.62 less: paid out a year later (6.28) and no levers saved moving round 3 to year 4 costs 2.61; starting the rounds in year 2 costs 85.83
Panel 4 — Price and allocate (Theorem 16.1(iii); Proposition 16.3; Worked Example 16.1, Step 4; Figure 16.2; Table 16.3; Online Appendix Example 16.B.2: the best program buys a $160m line and 2.071 quarters, $21.37m, worth $1,039.41m at a breach chance of 5.00% (fresh 4.99%), payouts 0, 0, 189.9, 160.4, 158.8, 32.7; the appetite is worth $1.83m a point, 1,038.43 at 4.5% and 1,040.25 at 5.5%, against Volume I's $1.81m for the build alone; the line buys a point of chance for $1.76m and the delay for $2.29m, paying in year 1 earns $0.77m and in year 2 $0.67m a point; a dollar of room at the start is worth $1.088; the rounds' points of capability, at $3.90, are worth $10.67m for years 1–3 and $10.38m for years 1, 2, 4)
AXIOM Lab 2.16, step 3. At the best program, read the prices (Theorem 16.1(iii)). The appetite's price: re-optimize the program at 4.5 and 5.5 percent and divide the change in value by the point between them. Each lever's cost per point of chance: $5 million more line, or 0.05 quarter more delay, and the chance it buys. Holding the payouts: paying $5 million at the end of year 1 or 2 instead of year 3 earns or a dollar and spends chance; a payout is held while that earns less than the appetite's price (Proposition 16.3(iii)). A dollar of room: one more $1 million of sale proceeds, the program re-optimized (Proposition 16.3(i)). Before reading the prices, the cell confirms that the program is best nearby: payouts in years 1–2 within a few million, and lines $10 million either side of its own. Last, the lab's question: release Chapter 5's year-1 payout of $85 million instead of holding it.
Python Code
CH_BEST, CH_BEST_F = BOOK.chance(BEST["line"], BEST["phi"], A_BEST, SALE), FRESH.chance(BEST["line"], BEST["phi"], A_BEST, SALE)
POST = post_window(BEST_Z, *BEST_P, SALE)
PV_PAY = sum(BY ** (j + 1) * BEST["payouts"][j] for j in range(6))
PV_SAV = BY ** 6 * savings(BEST_Z)[-1] / R
print(f"best program: rounds in years {BEST['rounds']}, payouts held in years 1-2; line {BEST['line']:.0f}, delay "
f"{BEST['phi']:.3f}, levers {BEST['cost']:.2f}; breach {100 * CH_BEST:.2f}% (fresh {100 * CH_BEST_F:.2f}%)")
print(f" payouts " + ", ".join(f"{x:.1f}" for x in BEST["payouts"]) + "; planned year-end cash in years 3-6 "
+ ", ".join(f"{x:.0f}" for x in POST[1]) + "; war chest " + ", ".join(f"{x:.0f}" for x in POST[2][3:]))
print(f" value {BEST['value']:,.2f} = payouts {PV_PAY:.2f} + the year-6 savings forever {PV_SAV:.2f} - levers {BEST['cost']:.2f}")
NEAR = {}
for p1 in (0.0, 1.0, 2.0, 5.0):
for p2 in (0.0, 1.0, 2.0, 5.0):
pk = BOOK.cheapest(automation_profile(BEST_Z, p1, p2), SALE)
NEAR[(p1, p2)] = value(BEST_Z, p1, p2, pk[0], SALE)[0]
print("\npayouts in years 1-2 near the best (value less the best's):")
print(" year 2 -> " + "".join(f"{p2:8.0f}" for p2 in (0.0, 1.0, 2.0, 5.0)))
for p1 in (0.0, 1.0, 2.0, 5.0):
print(f" year 1 = {p1:3.0f} " + "".join(f"{NEAR[(p1, p2)] - BEST['value']:8.3f}" for p2 in (0.0, 1.0, 2.0, 5.0)))
LINE_NEAR = []
for line in np.arange(BEST["line"] - 10.0, BEST["line"] + 10.01, 5.0):
phi = (DEPTH0 - BOOK.depth_for(line, A_BEST, SALE)) / DPQ
LINE_NEAR.append((line, phi, cost(line, phi)))
print("lines within $10m: " + "; ".join(f"{l:.0f}: delay {ph:.3f}, {c:.2f}" for l, ph, c in LINE_NEAR))
LOCAL_BEST = all(v <= BEST["value"] + 1e-9 for v in NEAR.values()) and min(LINE_NEAR, key=lambda r: r[2])[0] == BEST["line"]
print("the best program is best nearby:", LOCAL_BEST)
# the appetite's price: the program re-optimized at 4.5 and 5.5 percent (its schedule held; payouts checked nearby)
def program_at(p=ALPHA, G=SALE):
out = {}
for pp in ((0.0, 0.0), (1.0, 0.0), (0.0, 1.0)):
pk = BOOK.cheapest(automation_profile(BEST_Z, *pp), G, p=p)
out[pp] = (value(BEST_Z, *pp, pk[0], G)[0], pk)
best_pp = max(out, key=lambda k: out[k][0])
return dict(value=out[best_pp][0], payouts=best_pp, cost=out[best_pp][1][0], line=out[best_pp][1][1],
phi=out[best_pp][1][2], held=best_pp == (0.0, 0.0))
APP_LO, APP_HI = program_at(0.045), program_at(0.055)
MU = (APP_HI["value"] - APP_LO["value"]) / 1.0
print(f"\nthe appetite: at 4.5% line {APP_LO['line']:.0f}, delay {APP_LO['phi']:.3f}, levers {APP_LO['cost']:.2f}, value "
f"{APP_LO['value']:,.2f}; at 5.5% line {APP_HI['line']:.0f}, delay {APP_HI['phi']:.3f}, levers {APP_HI['cost']:.2f}, "
f"value {APP_HI['value']:,.2f}; payouts held at both: {APP_LO['held'] and APP_HI['held']}")
print(f" the appetite's price: {MU:.3f} a percentage point")
def vol1_design(p, P=BOOK):
# Volume I's design for the build alone (Volume I, Worked Example 15.1): every line on the $5m grid
best = None
for line in LINES_ALL:
c = np.sort(P.crit(line, NO_CASH, 0.0))
d = min(DEPTH0, c[int(np.floor(p * N))])
if d >= 0 and (best is None or cost(line, (DEPTH0 - d) / DPQ) < best[2]):
best = (float(line), (DEPTH0 - d) / DPQ, cost(line, (DEPTH0 - d) / DPQ))
return best
LINES_ALL = np.arange(0.0, 400.01, 5.0)
V1_LO, V1_HI = vol1_design(0.045), vol1_design(0.055)
MU_VOL1 = V1_LO[2] - V1_HI[2]
print(f" Volume I's price for the build alone: {V1_LO[2]:.2f} at 4.5% less {V1_HI[2]:.2f} at 5.5% = {MU_VOL1:.3f} a point")
# each lever's cost per point of chance, and what paying early earns per point it spends
c0 = CH_BEST
dl, dphi, dp = 5.0, 0.05, 5.0
CHANCES = dict(c0=c0, line=BOOK.chance(BEST["line"] + dl, BEST["phi"], A_BEST, SALE),
delay=BOOK.chance(BEST["line"], BEST["phi"] + dphi, A_BEST, SALE),
pay1=BOOK.chance(BEST["line"], BEST["phi"], automation_profile(BEST_Z, dp, 0.0), SALE),
pay2=BOOK.chance(BEST["line"], BEST["phi"], automation_profile(BEST_Z, 0.0, dp), SALE))
LEVER = dict(line=FEE * dl / (100 * (c0 - CHANCES["line"])), delay=VQ * dphi / (100 * (c0 - CHANCES["delay"])),
pay1=dp * (BY - BY ** 3) / (100 * (CHANCES["pay1"] - c0)), pay2=dp * (BY ** 2 - BY ** 3) / (100 * (CHANCES["pay2"] - c0)))
print(f"\nlevers at the best program: $5m more line buys {100 * (c0 - CHANCES['line']):.3f} points of chance, "
f"{LEVER['line']:.3f} a point; 0.05 quarter more delay buys {100 * (c0 - CHANCES['delay']):.4f} points, "
f"{LEVER['delay']:.3f} a point")
print(f"paying early: a dollar in year 1 instead of year 3 earns beta - beta^3 = {BY - BY ** 3:.3f} and spends "
f"{100 * (CHANCES['pay1'] - c0) / dp:.3f} points of chance: {LEVER['pay1']:.3f} a point; in year 2, "
f"beta^2 - beta^3 = {BY ** 2 - BY ** 3:.3f} for {100 * (CHANCES['pay2'] - c0) / dp:.3f} points: {LEVER['pay2']:.3f} a point")
print(f" levers in use trade near the appetite's price ({LEVER['line']:.2f} and {LEVER['delay']:.2f} around {MU:.2f}: the "
f"line moves in $5m steps); early payouts earn less than it, so they wait")
# a dollar of room at the start: one more $1m of proceeds, re-optimized
ROOM1 = program_at(ALPHA, SALE + 1.0)
ROOM_DOLLAR = ROOM1["value"] - BEST["value"]
print(f"\na dollar of room at the start: {ROOM_DOLLAR:.3f} = {BY ** 3:.3f} paid out at the end of year 3 + "
f"{BEST['cost'] - ROOM1['cost']:.3f} of levers it makes unnecessary (line {ROOM1['line']:.0f}, delay {ROOM1['phi']:.3f})")
CAP_CREDIT = {p["rounds"]: sum(CAP_PRICE * BY ** k for k in range(6) if p["z"][k]) for p in PROGRAMS}
print(f"capability: each round adds a point, worth {CAP_PRICE:.2f} of hiring at Chapter 7's price on the floor; in present "
f"value {CAP_CREDIT['1, 2, 3']:.2f} for rounds in years 1-3 and {CAP_CREDIT['1, 2, 4']:.2f} for years 1, 2, 4")
# hold or release: Chapter 5 paid $85m at the end of year 1
A_REL = automation_profile(BEST_Z, PAY5[0], 0.0)
PKG_REL = BOOK.cheapest(A_REL, SALE)
REL = value(BEST_Z, PAY5[0], 0.0, PKG_REL[0], SALE)
print(f"\nrelease Chapter 5's year-1 payout of {PAY5[0]:.0f}: the appetite then needs line {PKG_REL[1]:.0f} and delay "
f"{PKG_REL[2]:.3f}, levers {PKG_REL[0]:.2f}; the program is worth {REL[0]:,.2f}, {BEST['value'] - REL[0]:.2f} less "
f"than holding it")
fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6))
short = [BEST["value"] - p["value"] for p in PROGRAMS]
cols = ["#1F4E79" if i == 0 else ("#2E7D32" if i == 1 else "#BDBDBD") for i in range(len(PROGRAMS))]
ax.bar(np.arange(len(PROGRAMS)), short, 0.6, color=cols, edgecolor="#616161", lw=0.4)
for i in (0, 1):
ax.text(i, short[i] + 5, f"{short[i]:.1f}", fontsize=8, ha="center", va="bottom")
ax.set_xticks(np.arange(len(PROGRAMS)), [p["rounds"] for p in PROGRAMS], fontsize=7.5, rotation=40, ha="right",
rotation_mode="anchor")
ax.set(ylim=(0, 240), xlabel="years of the three rounds", ylabel="value below the best (\\$ million)")
ax.set_title("(a) each timing of the rounds, re-optimized", fontsize=9)
names = ["line", "delay", "pay in\nyear 1", "pay in\nyear 2"]
vals = [LEVER["line"], LEVER["delay"], LEVER["pay1"], LEVER["pay2"]]
bx.bar(np.arange(4), vals, 0.6, color=["#1F4E79", "#1F4E79", "#E65100", "#E65100"], alpha=0.85, lw=0)
for i, v in enumerate(vals):
bx.text(i, v + 0.06, f"{v:.2f}", fontsize=8, ha="center", va="bottom")
bx.axhline(MU, color="#333333", lw=1.0, ls="--")
bx.text(3.45, MU + 0.07, f"appetite {MU:.2f}", fontsize=8, ha="right", va="bottom")
bx.set_xticks(np.arange(4), names, fontsize=8)
bx.set(xlim=(-0.5, 3.5), ylim=(0, 3.0), ylabel="\\$ million per point of chance")
bx.set_title("(b) buy a point (blue), spend a point (orange)", fontsize=9)
fig.suptitle("Rounds in years 1–3; levers at the appetite's price (seed 26216)", fontsize=10.5)
plt.tight_layout(); plt.show()best program: rounds in years 1, 2, 3, payouts held in years 1-2; line 160, delay 2.071, levers 21.37; breach 5.00% (fresh 4.99%) payouts 0.0, 0.0, 189.9, 160.4, 158.8, 32.7; planned year-end cash in years 3-6 350, 350, 350, 470; war chest 350, 350, 350, 470 value 1,039.41 = payouts 369.30 + the year-6 savings forever 691.48 - levers 21.37 payouts in years 1-2 near the best (value less the best's): year 2 -> 0 1 2 5 year 1 = 0 0.000 -0.099 -0.229 -0.590 year 1 = 1 -0.189 -0.283 -0.399 -0.772 year 1 = 2 -0.367 -0.462 -0.573 -0.956 year 1 = 5 -0.907 -1.002 -1.112 -1.476 lines within $10m: 150: delay 2.123, 21.49; 155: delay 2.101, 21.45; 160: delay 2.071, 21.37; 165: delay 2.056, 21.40; 170: delay 2.037, 21.39 the best program is best nearby: True the appetite: at 4.5% line 165, delay 2.176, levers 22.35, value 1,038.43; at 5.5% line 170, delay 1.928, levers 20.53, value 1,040.25; payouts held at both: True the appetite's price: 1.828 a percentage point Volume I's price for the build alone: 11.39 at 4.5% less 9.58 at 5.5% = 1.807 a point levers at the best program: $5m more line buys 0.085 points of chance, 1.765 a point; 0.05 quarter more delay buys 0.1750 points, 2.286 a point paying early: a dollar in year 1 instead of year 3 earns beta - beta^3 = 0.158 and spends 0.204 points of chance: 0.775 a point; in year 2, beta^2 - beta^3 = 0.075 for 0.112 points: 0.670 a point levers in use trade near the appetite's price (1.76 and 2.29 around 1.83: the line moves in $5m steps); early payouts earn less than it, so they wait a dollar of room at the start: 1.088 = 0.751 paid out at the end of year 3 + 0.337 of levers it makes unnecessary (line 160, delay 2.029) capability: each round adds a point, worth 3.90 of hiring at Chapter 7's price on the floor; in present value 10.67 for rounds in years 1-3 and 10.38 for years 1, 2, 4 release Chapter 5's year-1 payout of 85: the appetite then needs line 165 and delay 5.634, levers 50.02; the program is worth 1,024.17, 15.24 less than holding it

Panel 5 — Keep a choice open (Theorem 16.2(iii); Proposition 16.2; Worked Example 16.1, Step 5; Figure 16.3(b); Table 16.3; Online Appendix Example 16.B.2: round 3 in year 3 only if cash after the year-2 payout is at least $490m, on 83.0% of paths (fresh 83.0%), else in year 4, with a $155m line and 1.642 quarters, $17.79m: worth $1,040.76m, $1.35m more than committing it to year 3, at a breach chance of 5.00% (fresh 5.00%); Chapter 7's generic project is worth 5.00 started now and 22.73 if it waits)
AXIOM Lab 2.16, step 4. Round 3 is irreversible, and its best timing depends on how the build has gone. Put it on a trigger: at the end of year 2, after the year-2 payout (none at the best program), run round 3 in year 3 if cash is at least the trigger, and otherwise in year 4. On each path the reading is the cash at the end of quarter 8, so a path runs round 3 exactly when the draw is shallow enough; for each line on the $5 million grid from $100 million to $260 million, the least delay that keeps the appetite under the rule is found by bisection on the depth, and the rule's value is the share of paths that run round 3 in year 3 times that program's value, plus the rest times the year-4 program's, less the levers. Every trigger from $380 million to $700 million by $10 million is priced; only the paths whose critical depth under either timing is below 28 can breach, so the count runs over those (the result is the same as over all paths). Theorem 16.2(iii): the rule is worth at least the best committed timing, and more exactly when the best timing depends on the reading. Proposition 16.2's waiting formula, on Chapter 7's generic project, closes the panel.
Python Code
t0 = time.time()
Z_RUN, Z_WAIT = (1, 1, 1, 0, 0, 0), (1, 1, 0, 1, 0, 0)
P1_RULE, P2_RULE = 0.0, 0.0 # the best program's payouts in years 1-2
V_RUN = value(Z_RUN, P1_RULE, P2_RULE, 0.0, SALE)[0] # gross values of the two timings
V_WAIT = value(Z_WAIT, P1_RULE, P2_RULE, 0.0, SALE)[0]
LINES3 = np.arange(100.0, 260.01, 5.0)
def rule_paths(P):
# per line: the critical depths under both timings and the cash at the end of quarter 8 at depth 0 (paths that
# can breach at a depth of at most 28 are kept for the count; the reading is kept for every path)
A_run, A_wait = automation_profile(Z_RUN, P1_RULE, P2_RULE), automation_profile(Z_WAIT, P1_RULE, P2_RULE)
out = []
for line in LINES3:
r = P.ratio(line)
c_run = np.min(r + ((A_run + SALE) * INV_SHAPE)[None, :], axis=1)
c_wait = np.min(r + ((A_wait + SALE) * INV_SHAPE)[None, :], axis=1)
L8 = r[:, 7] * SHAPE[7] + FLOOR + SALE + A_run[7] - P2_RULE
near = np.minimum(c_run, c_wait) < DEPTH0
out.append((float(line), c_run[near], c_wait[near], L8[near], L8))
return out
def rule_at(T, pre, n=N, p=ALPHA):
# the best package for trigger T: round 3 in year 3 iff cash after the year-2 payout >= T, else in year 4
best = None
for line, cr, cw, l8, l8_all in pre:
dT = (l8 - T) / SHAPE[7] # the path runs round 3 iff the depth is at most dT
breach = lambda d: np.count_nonzero(np.where(d <= dT, cr < d, cw < d)) / n
lo, hi = 0.0, DEPTH0
if breach(lo) > p:
continue
if breach(hi) <= p:
d = hi
else:
for _ in range(50): # bisection on the depth, as the engine does
mid = 0.5 * (lo + hi)
if breach(mid) <= p:
lo = mid
else:
hi = mid
d = lo
share = float(np.mean(d <= (l8_all - T) / SHAPE[7]))
phi = (DEPTH0 - d) / DPQ
v = share * V_RUN + (1 - share) * V_WAIT - cost(line, phi)
if best is None or v > best["value"]:
best = dict(trigger=float(T), line=line, phi=phi, cost=cost(line, phi), chance=breach(d), share_run=share, value=v)
return best
PRE3 = rule_paths(BOOK)
TRIGGERS = np.arange(380.0, 700.01, 10.0)
RULE = [rule_at(T, PRE3) for T in TRIGGERS]
RB = max(RULE, key=lambda r: r["value"])
def rule_check(P, rb):
# the rule's chance of a breach and its share of paths running round 3 in year 3, on other paths
A_run, A_wait = automation_profile(Z_RUN, P1_RULE, P2_RULE), automation_profile(Z_WAIT, P1_RULE, P2_RULE)
d = DEPTH0 - DPQ * rb["phi"]
L8 = P.ratio(rb["line"])[:, 7] * SHAPE[7] + FLOOR + SALE + A_run[7] - P2_RULE
run = d <= (L8 - rb["trigger"]) / SHAPE[7]
hit = np.where(run, P.crit(rb["line"], A_run, SALE) < d, P.crit(rb["line"], A_wait, SALE) < d)
return float(hit.mean()), float(run.mean())
RB_FRESH = rule_check(FRESH, RB)
COMMIT3, COMMIT4 = PROGRAMS[0]["value"], PROGRAMS[1]["value"]
print(f"gross values: round 3 in year 3 {V_RUN:,.2f}, in year 4 {V_WAIT:,.2f} (payouts held in years 1-2); "
f"{len(TRIGGERS)} triggers priced in {time.time() - t0:.1f} s")
print(f"{'trigger':>8s} {'line':>6s} {'delay':>7s} {'levers':>7s} {'year 3 on':>10s} {'value':>10s}")
for r in RULE:
if r["trigger"] % 40 == 0 or 460 <= r["trigger"] <= 520:
print(f"{r['trigger']:8.0f} {r['line']:6.0f} {r['phi']:7.3f} {r['cost']:7.2f} {100 * r['share_run']:9.1f}% "
f"{r['value']:10.2f}" + (" <- best" if r is RB else ""))
print(f"best trigger {RB['trigger']:.0f}: round 3 in year 3 on {100 * RB['share_run']:.1f}% of paths (fresh "
f"{100 * RB_FRESH[1]:.1f}%), line {RB['line']:.0f}, delay {RB['phi']:.3f}, levers {RB['cost']:.2f}; breach "
f"{100 * RB['chance']:.2f}% (fresh {100 * RB_FRESH[0]:.2f}%)")
print(f"value {RB['value']:,.2f}: {RB['value'] - COMMIT3:.2f} more than committing round 3 to year 3 ({COMMIT3:,.2f}) and "
f"{RB['value'] - COMMIT4:.2f} more than committing it to year 4 ({COMMIT4:,.2f})")
print(f"Theorem 16.2(iii): the rule beats both committed timings ({RB['value'] > max(COMMIT3, COMMIT4)}), strictly, because "
f"the best timing depends on the reading: year 3 on {100 * RB['share_run']:.0f}% of paths, year 4 on the rest")
# Proposition 16.2 on Chapter 7's generic project (Online Appendix 7.B): costs 100, worth 150 or 60 after a year
c_, V_, beta_, d_ = 100.0, np.array([150.0, 60.0]), 1 / 1.1, 0.0
N0 = V_.mean() - c_
N1 = beta_ * np.maximum(V_ - c_, 0).mean() - d_
loss_avoided, wait_cost = np.maximum(c_ - V_, 0).mean(), (1 - beta_) * np.maximum(V_ - c_, 0).mean() + d_
print(f"\nProposition 16.2: started now {N0:.2f}; started next year only if it pays {N1:.2f}; the expected loss waiting "
f"avoids {loss_avoided:.2f} exceeds what waiting costs {wait_cost:.2f}, so it waits ({N1 > max(N0, 0.0)})")gross values: round 3 in year 3 1,060.78, in year 4 1,047.63 (payouts held in years 1-2); 33 triggers priced in 5.2 s
trigger line delay levers year 3 on value
400 165 2.015 21.07 99.4% 1039.63
440 150 1.957 20.15 96.8% 1040.20
460 150 1.854 19.33 93.2% 1040.56
470 155 1.783 18.91 90.7% 1040.65
480 150 1.736 18.39 87.4% 1040.73
490 155 1.642 17.79 83.0% 1040.76 <- best
500 155 1.584 17.32 78.1% 1040.58
510 150 1.534 16.77 72.4% 1040.37
520 150 1.477 16.31 66.1% 1040.01
560 145 1.342 15.08 39.2% 1037.71
600 150 1.271 14.67 17.3% 1035.24
640 150 1.256 14.55 5.6% 1033.81
680 150 1.254 14.53 1.3% 1033.27
best trigger 490: round 3 in year 3 on 83.0% of paths (fresh 83.0%), line 155, delay 1.642, levers 17.79; breach 5.00% (fresh 5.00%)
value 1,040.76: 1.35 more than committing round 3 to year 3 (1,039.41) and 3.95 more than committing it to year 4 (1,036.80)
Theorem 16.2(iii): the rule beats both committed timings (True), strictly, because the best timing depends on the reading: year 3 on 83% of paths, year 4 on the rest
Proposition 16.2: started now 5.00; started next year only if it pays 22.73; the expected loss waiting avoids 20.00 exceeds what waiting costs 2.27, so it waits (True)
Panel 6 — Certify (Theorem 16.3; Proposition 16.1; Worked Example 16.1, Step 6; Figure 16.3(a); Table 16.3; Online Appendix Example 16.B.2: at 5% the program certifies a closure rate of 0.100 and a spread of $50.0m, and breaches on 13.88% of paths at the records' corner; designed for 4.5%, 4, 3.5, 3, 2.5 and 2% it costs $22.35m, 23.44, 24.65, 26.02, 27.50 and 29.30m, keeps 5% for closure rates to 0.192, 0.298 and 0.40 or more, and spreads to $51.0m, 52.2, 53.5, 55.0, 56.5 and 58.4m; at the corner, rate 0.315 and spread $61.6m, the program needs a $200m line and 3.440 quarters, $33.52m, worth $1,027.26m; the core's radius 0.800 today, 1.025 with the new link, 0.841 with every link trimmed to 0.304, 0.609 if the trim comes first)
AXIOM Lab 2.16, step 5. No slack (Theorem 16.3(i)): the best program meets the appetite exactly at the declared law, so a closure rate or a spread any higher breaks it. A margin buys a region (Theorem 16.3(ii)): re-design the program for 4.5, 4, …, 2 percent, its schedule held and its payouts re-optimized, and find along Chapter 11's family the largest closure rate (0.10 to 0.40, the family's simulation ceiling) and the largest spread ($50 million to 1.5 times that) at which it keeps the board's 5 percent, each edge by bisection. Chapter 11's family: a higher rate adds the closures of an extra stream thinned by uniforms (seed 1108), and a wider spread scales every deviation. The records' corner: the treasury's and the engineering office's one-sided 95 percent bounds, a rate of 0.315 and a spread of $61.6 million; the program re-designed there, and the price of ambiguity. Triggers (Theorem 16.3(iii)): the region's edges, the twin's monitor, and Volume I's feedback core, whose phases (Proposition 16.1) are checked with Volume I's symmetric register. Last, new draws from the lab's seed, 26216: the signed program on 100,000 paths of its own.
Python Code
t0 = time.time()
def extra_stream(P, seed=EXTRA_SEED):
# Chapter 11 (Online Appendix Remark 11.B.1): each quarter, uniforms for the paths' own closures; then the extra
# stream at rate 0.40 - 0.10 (counts, gamma sizes, uniforms)
rng = np.random.default_rng(seed)
own, more = [], []
for k in range(Q):
path, size = P.events[k]
own.append(rng.random(len(path)))
count = rng.poisson((LAM_MAX - LAM) / 4.0, P.n)
jj = np.repeat(np.arange(P.n), count)
more.append((jj, rng.gamma(*GAMMA, len(jj)), rng.random(len(jj))))
return own, more
EXTRA = extra_stream(BOOK)
def law(P, lam=LAM, c=1.0):
# the law with closures at lam a year and the spread c x $50m, on P's paths
if abs(lam - LAM) < 1e-15:
return Paths(P.E * c, P.events, P.seed)
own, more = EXTRA
events = []
for k, (path, size) in enumerate(P.events):
if lam < LAM:
keep = own[k] < lam / LAM
events.append((path[keep], size[keep]))
else:
jj, sz, u = more[k]
add = u < (lam - LAM) / (LAM_MAX - LAM)
events.append((np.concatenate([path, jj[add]]), np.concatenate([size, sz[add]])))
return Paths(P.E * c, events, P.seed)
def boundary(f, lo, hi, p=ALPHA, iters=30):
# the largest x in [lo, hi] with f(x) <= p, for f nondecreasing (bisection)
if f(hi) <= p:
return hi
if f(lo) > p:
return lo
for _ in range(iters):
mid = 0.5 * (lo + hi)
if f(mid) <= p:
lo = mid
else:
hi = mid
return lo
LAM_U = stats.chi2.ppf(0.95, 6) / 40.0 # Chapter 11: two closures in twenty years, one-sided 95%
SIG_U = 50.0 * math.sqrt(39 / stats.chi2.ppf(0.05, 39)) # forty quarters of deviations, 39 innovations
SIG_U2 = 50.0 * math.sqrt(79 / stats.chi2.ppf(0.05, 79)) # a record twice as long
CORNER_C = 61.6 / 50.0 # the records' corner as the book prints it
print("no slack at the declared law: the best program's chance "
+ ", ".join(f"{lab} {100 * law(BOOK, lam, c).chance(BEST['line'], BEST['phi'], A_BEST, SALE):.2f}%"
for lab, lam, c in (("as declared", LAM, 1.0), ("rate 0.105", 0.105, 1.0), ("spread 50.5", LAM, 1.01))))
MARGINS = []
for a in (0.05, 0.045, 0.04, 0.035, 0.03, 0.025, 0.02):
d = dict(value=BEST["value"], cost=BEST["cost"], line=BEST["line"], phi=BEST["phi"], payouts=BEST_P) if a == ALPHA \
else program_at(a)
line, phi = d["line"], d["phi"]
lam_bar = boundary(lambda x: law(BOOK, x, 1.0).chance(line, phi, A_BEST, SALE), LAM, LAM_MAX)
c_bar = boundary(lambda x: law(BOOK, LAM, x).chance(line, phi, A_BEST, SALE), 1.0, 1.5)
MARGINS.append(dict(appetite=a, value=d["value"], extra=BEST["value"] - d["value"], cost=d["cost"], line=line, phi=phi,
held=d["payouts"] == BEST_P, chance=BOOK.chance(line, phi, A_BEST, SALE),
fresh=FRESH.chance(line, phi, A_BEST, SALE), lam_bar=lam_bar, capped=lam_bar >= LAM_MAX - 1e-9,
sigma_bar=50.0 * c_bar, corner=law(BOOK, LAM_U, CORNER_C).chance(line, phi, A_BEST, SALE)))
print(f"\n{'design':>6s} {'line':>5s} {'delay':>6s} {'levers':>7s} {'value':>9s} {'margin cost':>11s} {'breach':>7s} "
f"{'fresh':>6s} {'rate to':>8s} {'spread to':>9s} {'at the corner':>13s}")
for m in MARGINS:
rate = ">= 0.40" if m["capped"] else f"{m['lam_bar']:.3f}"
print(f"{100 * m['appetite']:5.1f}% {m['line']:5.0f} {m['phi']:6.3f} {m['cost']:7.2f} {m['value']:9.2f} {m['extra']:11.2f} "
f"{100 * m['chance']:6.2f}% {100 * m['fresh']:5.2f}% {rate:>8s} {m['sigma_bar']:9.1f} {100 * m['corner']:12.2f}%")
print(f"payouts held in years 1-2 at every design: {all(m['held'] for m in MARGINS)}; the spread is guarded worst: the "
f"4% design keeps 5% to {MARGINS[2]['sigma_bar']:.1f} against the record's bound {SIG_U:.1f}")
CORNER = law(BOOK, LAM_U, CORNER_C)
PKG_CORNER = CORNER.cheapest(A_BEST, SALE)
V_CORNER = value(BEST_Z, *BEST_P, PKG_CORNER[0], SALE)[0]
AMBIGUITY = PKG_CORNER[0] - BEST["cost"]
print(f"\nthe records' corner (rate {LAM_U:.4f}, spread {50 * CORNER_C:.1f}): the best program breaches on "
f"{100 * MARGINS[0]['corner']:.2f}% of paths; re-designed, line {PKG_CORNER[1]:.0f} and delay {PKG_CORNER[2]:.3f}, "
f"levers {PKG_CORNER[0]:.2f}, breach {100 * CORNER.chance(PKG_CORNER[1], PKG_CORNER[2], A_BEST, SALE):.2f}%, value "
f"{V_CORNER:,.2f}")
CORNER_RIVALS = []
for z, p1, p2 in PRINTED[1:4]:
pk = CORNER.cheapest(automation_profile(z, p1, p2), SALE)
CORNER_RIVALS.append((rounds_of(z), value(z, p1, p2, pk[0], SALE)[0]))
print(" rivals at the corner (printed payouts): " + "; ".join(f"years {r}: {v:,.2f}" for r, v in CORNER_RIVALS)
+ f" -> rounds in years 1-3 stay best: {all(v < V_CORNER for _, v in CORNER_RIVALS)}")
CH11 = law(BOOK, LAM_U, SIG_U / 50.0) # Chapter 11's corner for the build alone
best11 = None
for line in LINES_ALL:
d = CH11.depth_for(line, NO_CASH, 0.0)
if d >= 0 and (DEPTH0 - d) / DPQ <= DEPTH0 / DPQ + 1e-12:
if best11 is None or cost(line, (DEPTH0 - d) / DPQ) < best11[2]:
best11 = (float(line), (DEPTH0 - d) / DPQ, cost(line, (DEPTH0 - d) / DPQ))
AMBIGUITY11 = best11[2] - cost(*PKG_VOL1)
print(f"the program's price of ambiguity {PKG_CORNER[0]:.2f} - {BEST['cost']:.2f} = {AMBIGUITY:.3f}; Chapter 11's for the "
f"build alone {best11[2]:.2f} - {cost(*PKG_VOL1):.2f} = {AMBIGUITY11:.3f}")
print(f"the triggers: re-certify when the treasury's estimate of the closure rate passes {MARGINS[2]['lam_bar']:.2f}, or the "
f"engineering office's estimate of the spread passes {MARGINS[2]['sigma_bar']:.1f} (the 4% design), or the twin's "
f"monitor alarms; region and margins in {time.time() - t0:.1f} s")
# the feedback core's phases (Volume I, Worked Example 14.1): engineering links e, treasury links t, the new link h
RULE_RHO = 0.5 ** 0.25 # the board's rule: deviations halve within a year
def register(e, t, h):
M = np.zeros((4, 4)) # Industrial Systems, Digital, engineering, treasury
for a, b, w in ((0, 2, e), (1, 2, e), (0, 3, t), (1, 3, t), (0, 1, h)):
M[a, b] = M[b, a] = w
return M
rho_closed = lambda e, t, h: (h + math.sqrt(h * h + 8 * (e * e + t * t))) / 2
half_life = lambda r: math.log(2) / math.log(1 / r) if r < 1 else float("inf")
TRIM = math.sqrt((RULE_RHO ** 2 - 0.40 * RULE_RHO) / 4) # every existing link trimmed so that the radius is the rule
H_LIGHT = (RULE_RHO ** 2 - 2 * (0.40 ** 2 + 0.40 ** 2)) / RULE_RHO
CORE = [("today", 0.40, 0.40, 0.0), ("phase two: link added, not repaired", 0.40, 0.40, 0.40),
("phase two: link run light", 0.40, 0.40, H_LIGHT), ("phase two: every link trimmed", TRIM, TRIM, 0.40),
("trim first, link later: after the trim", TRIM, TRIM, 0.0)]
CORE_ROWS = []
print("\nthe feedback core (Volume I's register):")
for lab, e, t, h in CORE:
r = float(max(abs(np.linalg.eigvals(register(e, t, h)))))
CORE_ROWS.append(dict(label=lab, e=e, t=t, h=h, rho=r, closed=rho_closed(e, t, h), half_life=half_life(r)))
print(f" {lab:40s} e {e:.3f} t {t:.3f} h {h:.3f} radius {r:.3f} half-life "
+ (f"{half_life(r):.2f} quarters" if r < 1 else "none: deviations grow"))
print(f" the closed form (h + sqrt(h^2 + 8(e^2 + t^2)))/2 agrees: {all(abs(c['rho'] - c['closed']) < 1e-12 for c in CORE_ROWS)}; "
f"the board's rule {RULE_RHO:.4f}")
print(" Proposition 16.1(ii): trim first and the core passes through "
f"{CORE_ROWS[4]['rho']:.3f}; add the link first and it passes through {CORE_ROWS[1]['rho']:.3f}, though today and the "
f"end state are stable; (iii) the register is symmetric, so phases each below the rule stay stable however they alternate")
LAB = Paths.draw(SEED) # new draws: the lab's own seed
LAB_BEST = LAB.chance(BEST["line"], BEST["phi"], A_BEST, SALE)
LAB_RULE = rule_check(LAB, RB)
LAB_PIECES = LAB.chance(*PKG_VOL1, A5, SALE)
se = math.sqrt(ALPHA * (1 - ALPHA) / N)
print(f"\nnew draws (seed {SEED}), 100,000 paths of the same law: the signed program breaches on {100 * LAB_BEST:.2f}%, "
f"{(LAB_BEST - ALPHA) / se:.1f} standard errors from 5% (a standard error is {100 * se:.3f} points on 100,000 paths); "
f"round 3 on its trigger {100 * LAB_RULE[0]:.2f}%, run in year 3 on {100 * LAB_RULE[1]:.1f}%; the pieces as "
f"certified {100 * LAB_PIECES:.2f}%")
fig, (ax, bx) = plt.subplots(1, 2, figsize=(7.6, 3.6))
ax.plot([m["extra"] for m in MARGINS], [m["sigma_bar"] for m in MARGINS], color="#1F4E79", lw=1.6, marker="o", ms=4, zorder=5)
for m in MARGINS:
ax.text(m["extra"] + 0.25, m["sigma_bar"] - 0.3, f"{100 * m['appetite']:.1f}%", fontsize=7.5, color="#1F4E79", va="top")
for y, lab, xx, ha in ((50.0, "declared spread", 9.6, "right"), (SIG_U2, "twice the record", 0.0, "left"),
(SIG_U, "the record's bound", 0.0, "left")):
ax.axhline(y, color="#999999", lw=0.7, ls=":")
ax.text(xx, y + 0.25, lab, fontsize=7.5, color="#616161", ha=ha, va="bottom")
ax.set(xlim=(-0.3, 9.8), ylim=(49, 63), xlabel="cost of the margin (\\$ million)", ylabel="spread certified (\\$ million)")
ax.set_title("(a) what a margin of appetite certifies", fontsize=9)
bx.plot([r["trigger"] for r in RULE], [r["value"] for r in RULE], color="#1F4E79", lw=1.6, label="round 3 on a trigger")
bx.plot([RB["trigger"]], [RB["value"]], "o", color="#1F4E79", ms=4)
bx.text(RB["trigger"], RB["value"] + 0.5, f"{RB['trigger']:.0f}", fontsize=8, color="#1F4E79", ha="center", va="bottom")
bx.axhline(COMMIT3, color="#E65100", lw=1.2, ls="--", label="committed to year 3")
bx.axhline(COMMIT4, color="#2E7D32", lw=1.2, ls=":", label="committed to year 4")
bx.set(xlim=(380, 700), ylim=(1031.5, 1045.5), xlabel="trigger: cash after year 2 (\\$ million)",
ylabel="program value (\\$ million)")
bx.set_yticks([1032, 1035, 1038, 1041, 1044], ["1,032", "1,035", "1,038", "1,041", "1,044"])
bx.legend(frameon=False, fontsize=7.5, loc="upper right")
bx.set_title("(b) keeping round 3 open", fontsize=9)
fig.suptitle("A margin buys a region; a trigger beats both timings (seed 26216)", fontsize=10.5)
plt.tight_layout(); plt.show()no slack at the declared law: the best program's chance as declared 5.00%, rate 0.105 5.04%, spread 50.5 5.26% design line delay levers value margin cost breach fresh rate to spread to at the corner 5.0% 160 2.071 21.37 1039.41 0.00 5.00% 4.99% 0.100 50.0 13.88% 4.5% 165 2.176 22.35 1038.43 0.98 4.50% 4.47% 0.192 51.0 12.82% 4.0% 165 2.311 23.44 1037.34 2.07 4.00% 3.93% 0.298 52.2 11.85% 3.5% 165 2.462 24.65 1036.13 3.28 3.50% 3.45% >= 0.40 53.5 10.84% 3.0% 170 2.615 26.02 1034.76 4.65 3.00% 2.95% >= 0.40 55.0 9.69% 2.5% 170 2.800 27.50 1033.28 6.13 2.50% 2.47% >= 0.40 56.5 8.65% 2.0% 165 3.043 29.30 1031.48 7.93 2.00% 1.98% >= 0.40 58.4 7.58% payouts held in years 1-2 at every design: True; the spread is guarded worst: the 4% design keeps 5% to 52.2 against the record's bound 61.6 the records' corner (rate 0.3148, spread 61.6): the best program breaches on 13.88% of paths; re-designed, line 200 and delay 3.440, levers 33.52, breach 5.00%, value 1,027.26 rivals at the corner (printed payouts): years 1, 2, 4: 1,024.49; years 1, 3, 4: 1,010.62; years 1, 4, 5: 988.91 -> rounds in years 1-3 stay best: True the program's price of ambiguity 33.52 - 21.37 = 12.144; Chapter 11's for the build alone 24.00 - 10.44 = 13.563 the triggers: re-certify when the treasury's estimate of the closure rate passes 0.30, or the engineering office's estimate of the spread passes 52.2 (the 4% design), or the twin's monitor alarms; region and margins in 25.0 s the feedback core (Volume I's register): today e 0.400 t 0.400 h 0.000 radius 0.800 half-life 3.11 quarters phase two: link added, not repaired e 0.400 t 0.400 h 0.400 radius 1.025 half-life none: deviations grow phase two: link run light e 0.400 t 0.400 h 0.080 radius 0.841 half-life 4.00 quarters phase two: every link trimmed e 0.304 t 0.304 h 0.400 radius 0.841 half-life 4.00 quarters trim first, link later: after the trim e 0.304 t 0.304 h 0.000 radius 0.609 half-life 1.40 quarters the closed form (h + sqrt(h^2 + 8(e^2 + t^2)))/2 agrees: True; the board's rule 0.8409 Proposition 16.1(ii): trim first and the core passes through 0.609; add the link first and it passes through 1.025, though today and the end state are stable; (iii) the register is symmetric, so phases each below the rule stay stable however they alternate new draws (seed 26216), 100,000 paths of the same law: the signed program breaches on 5.14%, 2.1 standard errors from 5% (a standard error is 0.069 points on 100,000 paths); round 3 on its trigger 5.27%, run in year 3 on 82.6%; the pieces as certified 74.24%

Panel 7 — Programs on one account (Worked Example 16.1; Table 16.3)
Table 16.3's rows from the panels above. Levers: the line's fees and the delay's cost; value: payouts at 10 percent plus the year-6 savings forever, less the levers; breach: the chance of liquidity below $350 million in some quarter of the build, on the book's 100,000 paths. The pieces as certified keep Chapter 5's payouts and have no program value.
Python Code
M4 = MARGINS[2]
T163 = [("Pieces as certified", "1-3", PKG_VOL1[0], PKG_VOL1[1], cost(*PKG_VOL1), None, SEP[SALE]["chance"]),
(" levers to keep them", "1-3", KEEP[1], KEEP[2], KEEP[0], None, BOOK.chance(KEEP[1], KEEP[2], A5, SALE)),
("Best program", "1-3", BEST["line"], BEST["phi"], BEST["cost"], BEST["value"], CH_BEST),
("Round 3 in year 4", "1, 2, 4", PROGRAMS[1]["line"], PROGRAMS[1]["phi"], PROGRAMS[1]["cost"], PROGRAMS[1]["value"],
BOOK.chance(PROGRAMS[1]["line"], PROGRAMS[1]["phi"], automation_profile((1, 1, 0, 1, 0, 0), 0.0, 77.0), SALE)),
("Round 3 on a trigger", "1, 2, 3 or 4", RB["line"], RB["phi"], RB["cost"], RB["value"], RB["chance"]),
("Sale after the build", "1-3", PKG_NOSALE[1], PKG_NOSALE[2], PKG_NOSALE[0], LATE[0],
BOOK.chance(PKG_NOSALE[1], PKG_NOSALE[2], A_BEST, 0.0)),
("No sale", "1-3", PKG_NOSALE[1], PKG_NOSALE[2], PKG_NOSALE[0], NOSALE[0], BOOK.chance(PKG_NOSALE[1], PKG_NOSALE[2], A_BEST, 0.0)),
("Designed for 4%", "1-3", M4["line"], M4["phi"], M4["cost"], M4["value"], M4["chance"]),
("At the records' corner", "1-3", PKG_CORNER[1], PKG_CORNER[2], PKG_CORNER[0], V_CORNER,
CORNER.chance(PKG_CORNER[1], PKG_CORNER[2], A_BEST, SALE))]
print(f"{'Program':24s} {'Rounds (years)':>15s} {'Line':>6s} {'Delay (q)':>10s} {'Levers':>8s} {'Value':>10s} {'Breach (%)':>11s}")
for name, rounds, line, phi, lev, val, ch in T163:
print(f"{name:24s} {rounds:>15s} {line:6.0f} {phi:10.2f} {lev:8.2f} {('--' if val is None else f'{val:,.2f}'):>10s} "
f"{100 * ch:11.1f}")
print(f"\nthe notebook ran in {time.time() - T_START:.0f} s")Program Rounds (years) Line Delay (q) Levers Value Breach (%) Pieces as certified 1-3 170 0.67 10.44 -- 74.3 levers to keep them 1-3 165 5.63 50.02 -- 5.0 Best program 1-3 160 2.07 21.37 1,039.41 5.0 Round 3 in year 4 1, 2, 4 160 1.48 16.62 1,036.80 5.0 Round 3 on a trigger 1, 2, 3 or 4 155 1.64 17.79 1,040.76 5.0 Sale after the build 1-3 165 5.97 52.71 1,001.79 5.0 No sale 1-3 165 5.97 52.71 938.95 5.0 Designed for 4% 1-3 165 2.31 23.44 1,037.34 4.0 At the records' corner 1-3 200 3.44 33.52 1,027.26 5.0 the notebook ran in 61 s
Validation — the book's numbers, and agreement with DCT_V2_Ch16_Lab.xlsx
Each checkpoint is a number printed in Chapter 16 (the abstract, Sections 16.1–16.4, Worked Example 16.1, Table 16.3,
Figures 16.1–16.3, the Key Takeaways, the LOS Guidance) or in Online Appendix Remark 16.B.1, Propositions 16.1–16.3 and
Example 16.B.2, with a tolerance of half a unit in its last printed digit; a few check what a theorem or proposition
promises (1 = holds). Chances are in percent. The workbook recomputes the checkpoints marked workbook with
spreadsheet formulas and shows PASS against the same engine values on its Checks sheet.
Python Code
def bk(s):
# a number as the book prints it: its value and half a unit in its last printed digit
t = s.replace(",", "").replace("−", "-")
return float(t), 0.5 * 10.0 ** -(len(t.split(".")[1]) if "." in t else 0) + 1e-9
def c_(name, got, printed, tol=None):
v, half = bk(printed)
return (name, float(got), v, half if tol is None else tol)
def flag(name, ok):
return (name, float(bool(ok)), 1.0, 0.0)
def count(name, got, n):
return (name, float(got), float(n), 0.0)
pc = lambda x: 100.0 * x
P = {p["rounds"]: p for p in PROGRAMS}
SP, SN = SEP[SALE], SEP[0.0]
CP, CN, CG = CLAIMS["pieces"], CLAIMS["pieces_no_sale"], CLAIMS["program"]
MG = {round(100 * m["appetite"], 1): m for m in MARGINS}
CR = {r["label"]: r for r in CORE_ROWS}
checks = [
# Step 1: the declarations, Chapter 5's plan alone, the one account (Remark 16.B.1; Example 16.B.2)
c_("the sale's proceeds with the engineers kept (workbook)", SALE, "92"),
c_("a dollar a year of savings, beta^6/0.10 (workbook)", SAV_PRICE, "5.645"),
c_("Chapter 5's plan alone: value, Chapter 5 (workbook)", V5, "1021.93"),
] + [c_(f"Chapter 5's plan alone: payout in year {j + 1} (workbook)", PAY5[j], s)
for j, s in enumerate(("85", "0", "122.5", "122.5", "122.5", "2.5"))] + [
c_("the draw at its deepest, $m a point (workbook)", SHAPE.max(), "6.2"),
c_("the plan without the draw relaxes toward (workbook)", 1000 * 0.62 * 112 / 100, "694"),
c_("Volume I's package: line", PKG_VOL1[0], "170"),
c_("Volume I's package: delay (quarters)", PKG_VOL1[1], "0.668"),
c_("Volume I's package: levers, Table 16.3 (workbook)", cost(*PKG_VOL1), "10.44"),
c_("the build alone: draw at quarter 7 (workbook)", BUILD_ALONE["draw"], "121.6"),
c_("the build alone: closure buffer (workbook)", BUILD_ALONE["buffer"], "16.9"),
count("the build alone: its deepest quarter (workbook)", BUILD_ALONE["quarter"], 7),
# Step 2: check jointly (Theorem 16.1(i); Figure 16.1; Table 16.3; Example 16.B.2)
c_("pieces as certified, with the sale: breach, %", pc(SP["chance"]), "74.33"),
c_("pieces as certified, with the sale: breach, %, Step 2 and Table 16.3", pc(SP["chance"]), "74.3"),
c_("pieces as certified: breach, %, the abstract and Key Takeaways", pc(SP["chance"]), "74"),
c_("pieces as certified, with the sale: fresh paths, %", pc(SP["fresh"]), "74.20"),
c_("pieces as certified, with the sale: fresh paths, %, Step 2", pc(SP["fresh"]), "74.2"),
c_("pieces as certified, without the sale: breach, %", pc(SN["chance"]), "99.58"),
c_("pieces as certified, without the sale: breach, %, Step 2", pc(SN["chance"]), "99.6"),
c_("pieces as certified, without the sale: fresh paths, %", pc(SN["fresh"]), "99.57"),
c_("pieces as certified, no levers, without the sale, %", pc(SN["no_levers"]), "99.90"),
c_("pieces as certified, no levers, with the sale, %", pc(SP["no_levers"]), "87.29"),
c_("planned margin at quarter 9, without the sale (workbook)", SN["margins"][8], "-84.7"),
c_("planned margin at quarter 9, with the sale (workbook)", SP["margins"][8], "7.3"),
c_("planned margin at quarter 9, with the sale, Step 2 (workbook)", SP["margins"][8], "7"),
count("the binding quarter of the joint check (workbook)", CP["quarter"], 9),
c_("claims at quarter 9, pieces: the build's draw (workbook)", CP["build"], "115.4"),
c_("claims at quarter 9, pieces: the rounds less their savings (workbook)", CP["rounds"], "154.4"),
c_("claims at quarter 9, pieces: the payouts made (workbook)", CP["payouts"], "85.0"),
c_("claims at quarter 9, pieces: the closure buffer (workbook)", CP["buffer"], "16.9"),
c_("claims at quarter 9, pieces with the sale: left of 362 (workbook)", CP["left"], "-9.6"),
c_("claims at quarter 9, pieces without the sale: left of 270 (workbook)", CN["left"], "-101.6"),
c_("claims at quarter 9, program: the build's draw (workbook)", CG["build"], "80.8"),
c_("claims at quarter 9, program: the rounds less their savings (workbook)", CG["rounds"], "154.4"),
c_("claims at quarter 9, program: the payouts made (workbook)", CG["payouts"], "0"),
c_("claims at quarter 9, program: the closure buffer (workbook)", CG["buffer"], "26.9"),
c_("claims at quarter 9, program: left of 362 (workbook)", CG["left"], "100.0"),
c_("the room with the sale (workbook)", CP["room"], "362"),
c_("levers to keep the pieces: line", KEEP[1], "165"),
c_("levers to keep the pieces: delay", KEEP[2], "5.634"),
c_("levers to keep the pieces: delay, Table 16.3", KEEP[2], "5.63"),
c_("levers to keep the pieces: delay, Step 2", KEEP[2], "5.6"),
c_("levers to keep the pieces: cost (workbook)", KEEP[0], "50.02"),
c_("levers to keep the pieces: cost, Step 2 (workbook)", KEEP[0], "50.0"),
c_("levers to keep the pieces: breach, %, Table 16.3", pc(BOOK.chance(KEEP[1], KEEP[2], A5, SALE)), "5.0"),
flag("no package keeps the pieces without the sale", SEP[0.0]["cheapest"] is None and best_depth < 0),
# Step 3: order (Theorem 16.2; Figure 16.2(a); Table 16.3; Example 16.B.2)
] + [c_(f"rounds in years {r}: value (workbook)", P[r]["value"], s) for r, s in
(("1, 2, 3", "1039.41"), ("1, 2, 4", "1036.80"), ("1, 3, 4", "1022.57"), ("1, 4, 5", "1001.59"), ("2, 3, 4", "953.58"),
("2, 4, 5", "937.60"), ("3, 4, 5", "883.16"), ("4, 5, 6", "821.11"))] + [
c_("rounds in years 1, 2, 4: payout in year 2", P["1, 2, 4"]["p2"], "77"),
c_("rounds in years 1, 2, 4: line", P["1, 2, 4"]["line"], "160"),
c_("rounds in years 1, 2, 4: delay", P["1, 2, 4"]["phi"], "1.477"),
c_("rounds in years 1, 2, 4: delay, Table 16.3", P["1, 2, 4"]["phi"], "1.48"),
c_("rounds in years 1, 2, 4: levers (workbook)", P["1, 2, 4"]["cost"], "16.62"),
c_("rounds in years 1, 3, 4: payout in year 1", P["1, 3, 4"]["p1"], "35"),
c_("rounds in years 1, 3, 4: line", P["1, 3, 4"]["line"], "140"),
c_("rounds in years 1, 3, 4: delay", P["1, 3, 4"]["phi"], "0.012"),
c_("rounds in years 1, 3, 4: levers (workbook)", P["1, 3, 4"]["cost"], "4.29"),
flag("every printed timing is the best continuation of its first three years", all(p["best_tail"] for p in PROGRAMS)),
c_("round 3 moved to year 4 costs, Step 3 (workbook)", BEST["value"] - P["1, 2, 4"]["value"], "2.6"),
c_("rounds started in year 2 cost, Step 3 (workbook)", BEST["value"] - P["2, 3, 4"]["value"], "85.8"),
c_("no sale: line", PKG_NOSALE[1], "165"),
c_("no sale: delay", PKG_NOSALE[2], "5.97"),
c_("no sale: levers (workbook)", PKG_NOSALE[0], "52.71"),
c_("no sale: value (workbook)", NOSALE[0], "938.95"),
c_("sale after the build: value (workbook)", LATE[0], "1001.79"),
c_("the sale first is worth, Step 3 (workbook)", SALE_WORTH, "100.5"),
c_("the sale's proceeds paid out at the end of year 3 (workbook)", SALE * BY ** 3, "69.1"),
c_("the levers the sale makes unnecessary (workbook)", PKG_NOSALE[0] - BEST["cost"], "31.3"),
c_("the sale first beats the sale after the build by (workbook)", BEST["value"] - LATE[0], "37.6"),
# Step 4: price and allocate (Theorem 16.1(iii); Proposition 16.3; Figure 16.2(b); Example 16.B.2)
c_("best program: line", BEST["line"], "160"),
c_("best program: delay", BEST["phi"], "2.071"),
c_("best program: delay, Table 16.3", BEST["phi"], "2.07"),
c_("best program: levers (workbook)", BEST["cost"], "21.37"),
c_("best program: levers, the abstract (workbook)", BEST["cost"], "21.4"),
c_("best program: value, the abstract", BEST["value"], "1039.4"),
c_("best program: breach, %", pc(CH_BEST), "5.00"),
c_("best program: fresh paths, %", pc(CH_BEST_F), "4.99"),
c_("best program: payout in year 1", BEST["payouts"][0], "0"),
c_("best program: payout in year 2", BEST["payouts"][1], "0"),
] + [c_(f"best program: payout in year {j + 3} (workbook)", BEST["payouts"][j + 2], s)
for j, s in enumerate(("189.9", "160.4", "158.8", "32.7"))] + [
flag("the best program is best nearby: payouts and lines", LOCAL_BEST),
c_("the appetite at 4.5%: value (workbook)", APP_LO["value"], "1038.43"),
c_("the appetite at 5.5%: value (workbook)", APP_HI["value"], "1040.25"),
c_("the appetite's price, $m a point (workbook)", MU, "1.83"),
c_("the appetite's price, the board takeaway (workbook)", MU, "1.8"),
c_("Volume I's price for the build alone (workbook)", MU_VOL1, "1.81"),
flag("payouts held at 4.5% and 5.5%", APP_LO["held"] and APP_HI["held"]),
c_("the line buys a point of chance for (workbook)", LEVER["line"], "1.76"),
c_("the delay buys a point of chance for (workbook)", LEVER["delay"], "2.29"),
c_("paying in year 1 earns a point (workbook)", LEVER["pay1"], "0.77"),
c_("paying in year 2 earns a point (workbook)", LEVER["pay2"], "0.67"),
c_("beta - beta^3 (workbook)", BY - BY ** 3, "0.158"),
c_("points of chance a dollar paid in year 1 spends (workbook)", 100 * (CHANCES["pay1"] - c0) / dp, "0.204"),
c_("a dollar of room at the start (workbook)", ROOM_DOLLAR, "1.088"),
c_("a dollar of room, Section 16.3 (workbook)", ROOM_DOLLAR, "1.09"),
c_("a dollar of room: paid out at the end of year 3 (workbook)", BY ** 3, "0.75"),
c_("a dollar of room: levers made unnecessary (workbook)", BEST["cost"] - ROOM1["cost"], "0.34"),
c_("a point of capability at Chapter 7's price (workbook)", CAP_PRICE, "3.90"),
c_("capability of rounds in years 1-3 (workbook)", CAP_CREDIT["1, 2, 3"], "10.67"),
c_("capability of rounds in years 1-3, Section 16.3 (workbook)", CAP_CREDIT["1, 2, 3"], "10.7"),
c_("capability of rounds in years 1, 2, 4 (workbook)", CAP_CREDIT["1, 2, 4"], "10.38"),
flag("levers bought near the appetite's price, payouts below it", LEVER["pay1"] < MU < LEVER["delay"] and LEVER["pay2"] < MU),
# Step 5: keep a choice open (Theorem 16.2(iii); Proposition 16.2; Figure 16.3(b); Example 16.B.2)
c_("round 3 on a trigger: trigger (workbook)", RB["trigger"], "490"),
c_("round 3 on a trigger: line", RB["line"], "155"),
c_("round 3 on a trigger: delay", RB["phi"], "1.642"),
c_("round 3 on a trigger: delay, Step 5 and Table 16.3", RB["phi"], "1.64"),
c_("round 3 on a trigger: levers (workbook)", RB["cost"], "17.79"),
c_("round 3 on a trigger: year 3 on, % of paths", pc(RB["share_run"]), "83.0"),
c_("round 3 on a trigger: year 3 on, %, Step 5", pc(RB["share_run"]), "83"),
c_("round 3 on a trigger: year 3 on, fresh paths, %", pc(RB_FRESH[1]), "83.0"),
c_("round 3 on a trigger: value (workbook)", RB["value"], "1040.76"),
c_("round 3 on a trigger: more than committing it to year 3 (workbook)", RB["value"] - COMMIT3, "1.35"),
c_("round 3 on a trigger: breach, %", pc(RB["chance"]), "5.00"),
c_("round 3 on a trigger: fresh paths, %", pc(RB_FRESH[0]), "5.00"),
flag("Theorem 16.2(iii): the rule beats both committed timings (workbook)", RB["value"] > max(COMMIT3, COMMIT4)),
c_("Proposition 16.2: the project started now (workbook)", N0, "5.00"),
c_("Proposition 16.2: the project if it waits (workbook)", N1, "22.73"),
c_("Proposition 16.2: the expected loss waiting avoids (workbook)", loss_avoided, "20"),
c_("Proposition 16.2: what waiting costs (workbook)", wait_cost, "2.27"),
# Step 6: certify (Theorem 16.3; Proposition 16.1; Figure 16.3(a); Example 16.B.2)
c_("design for 5%: closure rate certified", MG[5.0]["lam_bar"], "0.100"),
c_("design for 5%: spread certified", MG[5.0]["sigma_bar"], "50.0"),
c_("design for 5%: breach at the records' corner, %", pc(MG[5.0]["corner"]), "13.88"),
c_("design for 5%: breach at the corner, %, Step 6", pc(MG[5.0]["corner"]), "13.9"),
flag("Theorem 16.3(i): no slack: a higher rate or spread breaks the appetite",
law(BOOK, 0.105, 1.0).chance(BEST["line"], BEST["phi"], A_BEST, SALE) > ALPHA
and law(BOOK, LAM, 1.01).chance(BEST["line"], BEST["phi"], A_BEST, SALE) > ALPHA),
] + [c_(f"design for {k:g}%: {lab}{' (workbook)' if lab in ('levers', 'value') else ''}",
pc(MG[k][key]) if key == "corner" else MG[k][key], s) for k, vals in
((4.5, ("22.35", "1038.43", "51.0", "12.82")), (4.0, ("23.44", "1037.34", "52.2", "11.85")),
(3.5, ("24.65", "1036.13", "53.5", "10.84")), (3.0, ("26.02", "1034.76", "55.0", "9.69")),
(2.5, ("27.50", "1033.28", "56.5", "8.65")), (2.0, ("29.30", "1031.48", "58.4", "7.58")))
for lab, key, s in zip(("levers", "value", "spread certified", "breach at the corner, %"),
("cost", "value", "sigma_bar", "corner"), vals)] + [
c_("design for 4.5%: closure rate certified", MG[4.5]["lam_bar"], "0.192"),
c_("design for 4%: closure rate certified", MG[4.0]["lam_bar"], "0.298"),
c_("design for 4%: closure rate, Step 6 and Section 16.4", MG[4.0]["lam_bar"], "0.30"),
flag("designs for 3.5% and below certify a closure rate of 0.40 or more", all(MG[k]["capped"] for k in (3.5, 3.0, 2.5, 2.0))),
c_("design for 4%: the margin's cost (workbook)", MG[4.0]["extra"], "2.07"),
c_("design for 4%: a point of margin, the board takeaway (workbook)", MG[4.0]["extra"], "2.1"),
c_("design for 3%: the margin's cost (workbook)", MG[3.0]["extra"], "4.65"),
c_("design for 4%: line, Table 16.3", MG[4.0]["line"], "165"),
c_("design for 4%: delay, Table 16.3", MG[4.0]["phi"], "2.31"),
c_("design for 4%: breach, %, Table 16.3", pc(MG[4.0]["chance"]), "4.0"),
c_("the records' corner: closure rate (workbook)", LAM_U, "0.315"),
c_("the records' corner: spread", 50 * CORNER_C, "61.6"),
c_("the record twice as long: spread bound, Figure 16.3(a) (workbook)", SIG_U2, "57.6"),
c_("at the corner: line", PKG_CORNER[1], "200"),
c_("at the corner: delay", PKG_CORNER[2], "3.440"),
c_("at the corner: delay, Step 6", PKG_CORNER[2], "3.44"),
c_("at the corner: levers (workbook)", PKG_CORNER[0], "33.52"),
c_("at the corner: value (workbook)", V_CORNER, "1027.26"),
c_("at the corner: breach, %, Table 16.3", pc(CORNER.chance(PKG_CORNER[1], PKG_CORNER[2], A_BEST, SALE)), "5.0"),
flag("at the corner, rounds in years 1-3 stay best", all(v < V_CORNER for _, v in CORNER_RIVALS)),
c_("the program's price of ambiguity, 33.52 less 21.37 (workbook)", AMBIGUITY, "12.14"),
c_("Chapter 11's price of ambiguity for the build alone (workbook)", AMBIGUITY11, "13.56"),
c_("the core today (workbook)", CR["today"]["rho"], "0.800"),
c_("the core with the new link at 0.40 (workbook)", CR["phase two: link added, not repaired"]["rho"], "1.025"),
c_("the core with every link trimmed (workbook)", CR["phase two: every link trimmed"]["rho"], "0.841"),
c_("every existing link trimmed to (workbook)", TRIM, "0.304"),
c_("trim first: the core passes through (workbook)", CR["trim first, link later: after the trim"]["rho"], "0.609"),
c_("trim first, Section 16.2 (workbook)", CR["trim first, link later: after the trim"]["rho"], "0.61"),
c_("trim first: half-life, quarters (workbook)", CR["trim first, link later: after the trim"]["half_life"], "1.40"),
c_("the link with the trim: half-life, quarters (workbook)", CR["phase two: every link trimmed"]["half_life"], "4.00"),
c_("the link run light (workbook)", H_LIGHT, "0.080"),
c_("the link run light keeps the radius at (workbook)", CR["phase two: link run light"]["rho"], "0.841"),
flag("Proposition 16.1(ii): stable start and end, an unstable phase between",
CR["today"]["rho"] < 1 < CR["phase two: link added, not repaired"]["rho"]
and CR["phase two: every link trimmed"]["rho"] < 1),
# Table 16.3 and the Key Takeaways
c_("Table 16.3: pieces as certified, delay", PKG_VOL1[1], "0.67"),
c_("Table 16.3: the best program's value, Key Takeaways", BEST["value"], "1039.41"),
c_("Table 16.3: the best program's levers, Key Takeaways", BEST["cost"], "21.37"),
c_("Table 16.3: round 3 on a trigger, breach, %", pc(RB["chance"]), "5.0"),
c_("Table 16.3: sale after the build, breach, %", pc(T163[5][6]), "5.0"),
c_("Table 16.3: no sale, breach, %", pc(T163[6][6]), "5.0"),
c_("Table 16.3: round 3 in year 4, breach, %", pc(T163[3][6]), "5.0"),
c_("Table 16.3: designed for 4%, value", M4["value"], "1037.34"),
]
ok = 0
for name, got, want, tol in checks:
status = "PASS" if abs(got - want) <= tol else "FAIL"
ok += status == "PASS"
print(f"{name:78s} {got:12.4f} book {want:10.4f} {status}")
print(f"\n{ok} of {len(checks)} checkpoints PASS")the sale's proceeds with the engineers kept (workbook) 92.0000 book 92.0000 PASS a dollar a year of savings, beta^6/0.10 (workbook) 5.6447 book 5.6450 PASS Chapter 5's plan alone: value, Chapter 5 (workbook) 1021.9325 book 1021.9300 PASS Chapter 5's plan alone: payout in year 1 (workbook) 85.0000 book 85.0000 PASS Chapter 5's plan alone: payout in year 2 (workbook) 0.0000 book 0.0000 PASS Chapter 5's plan alone: payout in year 3 (workbook) 122.5000 book 122.5000 PASS Chapter 5's plan alone: payout in year 4 (workbook) 122.5000 book 122.5000 PASS Chapter 5's plan alone: payout in year 5 (workbook) 122.5000 book 122.5000 PASS Chapter 5's plan alone: payout in year 6 (workbook) 2.5000 book 2.5000 PASS the draw at its deepest, $m a point (workbook) 6.2000 book 6.2000 PASS the plan without the draw relaxes toward (workbook) 694.4000 book 694.0000 PASS Volume I's package: line 170.0000 book 170.0000 PASS Volume I's package: delay (quarters) 0.6676 book 0.6680 PASS Volume I's package: levers, Table 16.3 (workbook) 10.4406 book 10.4400 PASS the build alone: draw at quarter 7 (workbook) 121.6344 book 121.6000 PASS the build alone: closure buffer (workbook) 16.8670 book 16.9000 PASS the build alone: its deepest quarter (workbook) 7.0000 book 7.0000 PASS pieces as certified, with the sale: breach, % 74.3310 book 74.3300 PASS pieces as certified, with the sale: breach, %, Step 2 and Table 16.3 74.3310 book 74.3000 PASS pieces as certified: breach, %, the abstract and Key Takeaways 74.3310 book 74.0000 PASS pieces as certified, with the sale: fresh paths, % 74.1980 book 74.2000 PASS pieces as certified, with the sale: fresh paths, %, Step 2 74.1980 book 74.2000 PASS pieces as certified, without the sale: breach, % 99.5770 book 99.5800 PASS pieces as certified, without the sale: breach, %, Step 2 99.5770 book 99.6000 PASS pieces as certified, without the sale: fresh paths, % 99.5680 book 99.5700 PASS pieces as certified, no levers, without the sale, % 99.8970 book 99.9000 PASS pieces as certified, no levers, with the sale, % 87.2870 book 87.2900 PASS planned margin at quarter 9, without the sale (workbook) -84.7404 book -84.7000 PASS planned margin at quarter 9, with the sale (workbook) 7.2596 book 7.3000 PASS planned margin at quarter 9, with the sale, Step 2 (workbook) 7.2596 book 7.0000 PASS the binding quarter of the joint check (workbook) 9.0000 book 9.0000 PASS claims at quarter 9, pieces: the build's draw (workbook) 115.3654 book 115.4000 PASS claims at quarter 9, pieces: the rounds less their savings (workbook) 154.3750 book 154.4000 PASS claims at quarter 9, pieces: the payouts made (workbook) 85.0000 book 85.0000 PASS claims at quarter 9, pieces: the closure buffer (workbook) 16.8670 book 16.9000 PASS claims at quarter 9, pieces with the sale: left of 362 (workbook) -9.6074 book -9.6000 PASS claims at quarter 9, pieces without the sale: left of 270 (workbook) -101.6074 book -101.6000 PASS claims at quarter 9, program: the build's draw (workbook) 80.7989 book 80.8000 PASS claims at quarter 9, program: the rounds less their savings (workbook) 154.3750 book 154.4000 PASS claims at quarter 9, program: the payouts made (workbook) 0.0000 book 0.0000 PASS claims at quarter 9, program: the closure buffer (workbook) 26.8670 book 26.9000 PASS claims at quarter 9, program: left of 362 (workbook) 99.9591 book 100.0000 PASS the room with the sale (workbook) 362.0000 book 362.0000 PASS levers to keep the pieces: line 165.0000 book 165.0000 PASS levers to keep the pieces: delay 5.6336 book 5.6340 PASS levers to keep the pieces: delay, Table 16.3 5.6336 book 5.6300 PASS levers to keep the pieces: delay, Step 2 5.6336 book 5.6000 PASS levers to keep the pieces: cost (workbook) 50.0190 book 50.0200 PASS levers to keep the pieces: cost, Step 2 (workbook) 50.0190 book 50.0000 PASS levers to keep the pieces: breach, %, Table 16.3 5.0000 book 5.0000 PASS no package keeps the pieces without the sale 1.0000 book 1.0000 PASS rounds in years 1, 2, 3: value (workbook) 1039.4082 book 1039.4100 PASS rounds in years 1, 2, 4: value (workbook) 1036.8009 book 1036.8000 PASS rounds in years 1, 3, 4: value (workbook) 1022.5659 book 1022.5700 PASS rounds in years 1, 4, 5: value (workbook) 1001.5913 book 1001.5900 PASS rounds in years 2, 3, 4: value (workbook) 953.5758 book 953.5800 PASS rounds in years 2, 4, 5: value (workbook) 937.5977 book 937.6000 PASS rounds in years 3, 4, 5: value (workbook) 883.1615 book 883.1600 PASS rounds in years 4, 5, 6: value (workbook) 821.1069 book 821.1100 PASS rounds in years 1, 2, 4: payout in year 2 77.0000 book 77.0000 PASS rounds in years 1, 2, 4: line 160.0000 book 160.0000 PASS rounds in years 1, 2, 4: delay 1.4770 book 1.4770 PASS rounds in years 1, 2, 4: delay, Table 16.3 1.4770 book 1.4800 PASS rounds in years 1, 2, 4: levers (workbook) 16.6162 book 16.6200 PASS rounds in years 1, 3, 4: payout in year 1 35.0000 book 35.0000 PASS rounds in years 1, 3, 4: line 140.0000 book 140.0000 PASS rounds in years 1, 3, 4: delay 0.0115 book 0.0120 PASS rounds in years 1, 3, 4: levers (workbook) 4.2923 book 4.2900 PASS every printed timing is the best continuation of its first three years 1.0000 book 1.0000 PASS round 3 moved to year 4 costs, Step 3 (workbook) 2.6072 book 2.6000 PASS rounds started in year 2 cost, Step 3 (workbook) 85.8324 book 85.8000 PASS no sale: line 165.0000 book 165.0000 PASS no sale: delay 5.9700 book 5.9700 PASS no sale: levers (workbook) 52.7101 book 52.7100 PASS no sale: value (workbook) 938.9489 book 938.9500 PASS sale after the build: value (workbook) 1001.7862 book 1001.7900 PASS the sale first is worth, Step 3 (workbook) 100.4592 book 100.5000 PASS the sale's proceeds paid out at the end of year 3 (workbook) 69.1210 book 69.1000 PASS the levers the sale makes unnecessary (workbook) 31.3383 book 31.3000 PASS the sale first beats the sale after the build by (workbook) 37.6220 book 37.6000 PASS best program: line 160.0000 book 160.0000 PASS best program: delay 2.0715 book 2.0710 PASS best program: delay, Table 16.3 2.0715 book 2.0700 PASS best program: levers (workbook) 21.3719 book 21.3700 PASS best program: levers, the abstract (workbook) 21.3719 book 21.4000 PASS best program: value, the abstract 1039.4082 book 1039.4000 PASS best program: breach, % 5.0000 book 5.0000 PASS best program: fresh paths, % 4.9940 book 4.9900 PASS best program: payout in year 1 0.0000 book 0.0000 PASS best program: payout in year 2 0.0000 book 0.0000 PASS best program: payout in year 3 (workbook) 189.9240 book 189.9000 PASS best program: payout in year 4 (workbook) 160.4014 book 160.4000 PASS best program: payout in year 5 (workbook) 158.8073 book 158.8000 PASS best program: payout in year 6 (workbook) 32.6739 book 32.7000 PASS the best program is best nearby: payouts and lines 1.0000 book 1.0000 PASS the appetite at 4.5%: value (workbook) 1038.4253 book 1038.4300 PASS the appetite at 5.5%: value (workbook) 1040.2533 book 1040.2500 PASS the appetite's price, $m a point (workbook) 1.8281 book 1.8300 PASS the appetite's price, the board takeaway (workbook) 1.8281 book 1.8000 PASS Volume I's price for the build alone (workbook) 1.8070 book 1.8100 PASS payouts held at 4.5% and 5.5% 1.0000 book 1.0000 PASS the line buys a point of chance for (workbook) 1.7647 book 1.7600 PASS the delay buys a point of chance for (workbook) 2.2857 book 2.2900 PASS paying in year 1 earns a point (workbook) 0.7749 book 0.7700 PASS paying in year 2 earns a point (workbook) 0.6696 book 0.6700 PASS beta - beta^3 (workbook) 0.1578 book 0.1580 PASS points of chance a dollar paid in year 1 spends (workbook) 0.2036 book 0.2040 PASS a dollar of room at the start (workbook) 1.0880 book 1.0880 PASS a dollar of room, Section 16.3 (workbook) 1.0880 book 1.0900 PASS a dollar of room: paid out at the end of year 3 (workbook) 0.7513 book 0.7500 PASS a dollar of room: levers made unnecessary (workbook) 0.3367 book 0.3400 PASS a point of capability at Chapter 7's price (workbook) 3.9000 book 3.9000 PASS capability of rounds in years 1-3 (workbook) 10.6686 book 10.6700 PASS capability of rounds in years 1-3, Section 16.3 (workbook) 10.6686 book 10.7000 PASS capability of rounds in years 1, 2, 4 (workbook) 10.3756 book 10.3800 PASS levers bought near the appetite's price, payouts below it 1.0000 book 1.0000 PASS round 3 on a trigger: trigger (workbook) 490.0000 book 490.0000 PASS round 3 on a trigger: line 155.0000 book 155.0000 PASS round 3 on a trigger: delay 1.6424 book 1.6420 PASS round 3 on a trigger: delay, Step 5 and Table 16.3 1.6424 book 1.6400 PASS round 3 on a trigger: levers (workbook) 17.7892 book 17.7900 PASS round 3 on a trigger: year 3 on, % of paths 83.0000 book 83.0000 PASS round 3 on a trigger: year 3 on, %, Step 5 83.0000 book 83.0000 PASS round 3 on a trigger: year 3 on, fresh paths, % 83.0180 book 83.0000 PASS round 3 on a trigger: value (workbook) 1040.7557 book 1040.7600 PASS round 3 on a trigger: more than committing it to year 3 (workbook) 1.3475 book 1.3500 PASS round 3 on a trigger: breach, % 5.0000 book 5.0000 PASS round 3 on a trigger: fresh paths, % 5.0030 book 5.0000 PASS Theorem 16.2(iii): the rule beats both committed timings (workbook) 1.0000 book 1.0000 PASS Proposition 16.2: the project started now (workbook) 5.0000 book 5.0000 PASS Proposition 16.2: the project if it waits (workbook) 22.7273 book 22.7300 PASS Proposition 16.2: the expected loss waiting avoids (workbook) 20.0000 book 20.0000 PASS Proposition 16.2: what waiting costs (workbook) 2.2727 book 2.2700 PASS design for 5%: closure rate certified 0.1001 book 0.1000 PASS design for 5%: spread certified 50.0000 book 50.0000 PASS design for 5%: breach at the records' corner, % 13.8780 book 13.8800 PASS design for 5%: breach at the corner, %, Step 6 13.8780 book 13.9000 PASS Theorem 16.3(i): no slack: a higher rate or spread breaks the appetite 1.0000 book 1.0000 PASS design for 4.5%: levers (workbook) 22.3548 book 22.3500 PASS design for 4.5%: value (workbook) 1038.4253 book 1038.4300 PASS design for 4.5%: spread certified 51.0494 book 51.0000 PASS design for 4.5%: breach at the corner, % 12.8210 book 12.8200 PASS design for 4%: levers (workbook) 23.4369 book 23.4400 PASS design for 4%: value (workbook) 1037.3431 book 1037.3400 PASS design for 4%: spread certified 52.1867 book 52.2000 PASS design for 4%: breach at the corner, % 11.8500 book 11.8500 PASS design for 3.5%: levers (workbook) 24.6483 book 24.6500 PASS design for 3.5%: value (workbook) 1036.1317 book 1036.1300 PASS design for 3.5%: spread certified 53.4878 book 53.5000 PASS design for 3.5%: breach at the corner, % 10.8360 book 10.8400 PASS design for 3%: levers (workbook) 26.0231 book 26.0200 PASS design for 3%: value (workbook) 1034.7569 book 1034.7600 PASS design for 3%: spread certified 54.9578 book 55.0000 PASS design for 3%: breach at the corner, % 9.6880 book 9.6900 PASS design for 2.5%: levers (workbook) 27.5039 book 27.5000 PASS design for 2.5%: value (workbook) 1033.2761 book 1033.2800 PASS design for 2.5%: spread certified 56.5446 book 56.5000 PASS design for 2.5%: breach at the corner, % 8.6460 book 8.6500 PASS design for 2%: levers (workbook) 29.2969 book 29.3000 PASS design for 2%: value (workbook) 1031.4831 book 1031.4800 PASS design for 2%: spread certified 58.4483 book 58.4000 PASS design for 2%: breach at the corner, % 7.5780 book 7.5800 PASS design for 4.5%: closure rate certified 0.1917 book 0.1920 PASS design for 4%: closure rate certified 0.2984 book 0.2980 PASS design for 4%: closure rate, Step 6 and Section 16.4 0.2984 book 0.3000 PASS designs for 3.5% and below certify a closure rate of 0.40 or more 1.0000 book 1.0000 PASS design for 4%: the margin's cost (workbook) 2.0650 book 2.0700 PASS design for 4%: a point of margin, the board takeaway (workbook) 2.0650 book 2.1000 PASS design for 3%: the margin's cost (workbook) 4.6512 book 4.6500 PASS design for 4%: line, Table 16.3 165.0000 book 165.0000 PASS design for 4%: delay, Table 16.3 2.3109 book 2.3100 PASS design for 4%: breach, %, Table 16.3 4.0000 book 4.0000 PASS the records' corner: closure rate (workbook) 0.3148 book 0.3150 PASS the records' corner: spread 61.6000 book 61.6000 PASS the record twice as long: spread bound, Figure 16.3(a) (workbook) 57.6028 book 57.6000 PASS at the corner: line 200.0000 book 200.0000 PASS at the corner: delay 3.4395 book 3.4400 PASS at the corner: delay, Step 6 3.4395 book 3.4400 PASS at the corner: levers (workbook) 33.5161 book 33.5200 PASS at the corner: value (workbook) 1027.2640 book 1027.2600 PASS at the corner: breach, %, Table 16.3 5.0000 book 5.0000 PASS at the corner, rounds in years 1-3 stay best 1.0000 book 1.0000 PASS the program's price of ambiguity, 33.52 less 21.37 (workbook) 12.1442 book 12.1400 PASS Chapter 11's price of ambiguity for the build alone (workbook) 13.5626 book 13.5600 PASS the core today (workbook) 0.8000 book 0.8000 PASS the core with the new link at 0.40 (workbook) 1.0246 book 1.0250 PASS the core with every link trimmed (workbook) 0.8409 book 0.8410 PASS every existing link trimmed to (workbook) 0.3044 book 0.3040 PASS trim first: the core passes through (workbook) 0.6089 book 0.6090 PASS trim first, Section 16.2 (workbook) 0.6089 book 0.6100 PASS trim first: half-life, quarters (workbook) 1.3971 book 1.4000 PASS the link with the trim: half-life, quarters (workbook) 4.0000 book 4.0000 PASS the link run light (workbook) 0.0798 book 0.0800 PASS the link run light keeps the radius at (workbook) 0.8409 book 0.8410 PASS Proposition 16.1(ii): stable start and end, an unstable phase between 1.0000 book 1.0000 PASS Table 16.3: pieces as certified, delay 0.6676 book 0.6700 PASS Table 16.3: the best program's value, Key Takeaways 1039.4082 book 1039.4100 PASS Table 16.3: the best program's levers, Key Takeaways 21.3719 book 21.3700 PASS Table 16.3: round 3 on a trigger, breach, % 5.0000 book 5.0000 PASS Table 16.3: sale after the build, breach, % 5.0000 book 5.0000 PASS Table 16.3: no sale, breach, % 5.0000 book 5.0000 PASS Table 16.3: round 3 in year 4, breach, % 5.0000 book 5.0000 PASS Table 16.3: designed for 4%, value 1037.3431 book 1037.3400 PASS 203 of 203 checkpoints PASS
Next. This is the last chapter of Volume II, and of the series. Volume I drew the map: the seven moves of DCT, from Represent to Adapt, run as a loop, and the gates that tell a board when it is ready to optimize. Volume II supplied the methods, each piece of Meridian's transformation optimized and certified on its own terms, and this chapter signed them as one program on one account, with its roadmap, its prices, its certificate chain, its region and its triggers. The program is not signed once: when an estimate leaves the region, a monitor alarms, or the board changes a declaration, the loop runs again, and the program is re-certified for the next cycle. AXIOM-16 runs the same program interactively (Lab 2.16); this notebook and the workbook are its reproducible record.
